Product Core Brief
- Model: VM600 XMV16 — 600-003 / 620-001-001-116
- Brand: VIBRO-METER
- Series: VM600 / VM600 Mk2 Machine Monitoring System
- Core Function: High-density vibration condition monitoring module with 16 dynamic channels and 4 tachometer channels.
- Product Type: VM600 Condition Monitoring Module
- Key Specs: 16 dynamic channels + 4 tach channels | 24-bit acquisition | Paired with XIO16T I/O module | VibroSight software support
- Condition: New Surplus
Product Introduction
VIBRO-METER VM600 XMV16 is a high-density condition monitoring module for the VM600 and VM600 Mk2 rack systems. It provides 16 dynamic measurement channels and 4 tachometer channels, all independently configurable, for vibration monitoring, speed sensing, and diagnostic analysis on critical rotating equipment.
The XMV16 processing module always operates as a paired card set with the XIO16T input/output module mounted directly behind it in the rack. It supports simultaneous asynchronous or synchronous sampling, 24-bit data acquisition, and high-resolution FFT up to 6400 lines every 500 ms. Designed for VibroSight software integration, it is commonly deployed on gas turbines, steam turbines, compressors, and large rotating machinery where high channel density and advanced diagnostics are required.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Product Type | VM600 Condition Monitoring Module |
| Brand | VIBRO-METER |
| System Compatibility | / Mk2 |
| Dynamic Channels | 16 channels |
| Tachometer Channels | 4 channels |
| Data Acquisition | 24-bit simultaneous sampling |
| FFT Resolution | Up to 6400 lines per 500 ms |
| Sampling Mode | Asynchronous (fixed frequency) or synchronous (order tracked) |
| Required Pairing | XIO16T I/O module (rear-mounted) |
| Software | VibroSight |
| Mounting | VM600 19″ rack module |
| Condition | New Surplus |
Note: Confirm the exact hardware revision and firmware level for 600-003 / 620-001-001-116 against the official Vibro-Meter documentation before installation.
Quality Control Process
Each unit begins with a visual inspection of the front panel, connectors, PCB, and rear mating contacts for corrosion, bent pins, or thermal stress. The XMV16 is then seated into a compatible VM600 rack with the paired XIO16T module to verify mechanical fit and backplane recognition.
Power is applied through the rack supply, and initialization LEDs are checked for proper startup behavior. Dynamic channel integrity is verified with a precision signal source and Fluke multimeter to confirm input response, noise floor, and isolation. Tachometer channels are exercised with simulated speed signals to confirm pulse detection and phase tracking. Communication with VibroSight software is tested where possible to confirm channel mapping, FFT output, and alarm configuration. Final packing uses anti-static bags, foam inserts, and sealed cartons to protect the module during shipment.
Replacement Pitfall Guide
❗ Confirm the exact part number and revision. The 600-003 and 620-001-001-116 variants may differ in firmware, hardware revision, or channel configuration. Installing the wrong variant can cause channel mapping errors or software incompatibility.
❗ Verify the XIO16T pairing. The XMV16 cannot operate alone—it must be paired with the correct XIO16T module mounted directly behind it in the rack. Installing it without the paired I/O module, or behind the wrong variant, will prevent channel acquisition.
❗ Revalidate channel mapping in VibroSight. After replacement, all 16 dynamic channels and 4 tachometer channels must be reconfirmed in the software. Wrong channel assignments can mask developing vibration issues or generate false alarms.
❗ Check sensor wiring and differential inputs. The XIO16T provides differential signal inputs for each dynamic and tachometer channel. Reversed polarity, poor shielding, or ground loops can introduce noise that looks like mechanical vibration but is actually an electrical artifact.
Keep these in mind and you’ll cut 90% of rework time.
Compatibility Matrix & Benchmarks
| Original Model | Replacement / Successor Model | Compatibility Level | Migration Notes |
|---|---|---|---|
| VIBRO-METER VM600 XMV16 600-003 / 620-001-001-116 | VIBRO-METER VM600 XMV16 600-003 / 620-001-001-116 | Direct | Same part number; verify XIO16T pairing and VibroSight configuration. |
| VIBRO-METER VM600 XMV16 | VIBRO-METER VM600 Mk2 XMV16 | Needs Adaptation | Same module family; confirm rack firmware and software compatibility. |
| VIBRO-METER VM600 XMV16 | VIBRO-METER VM600 MPC4 / MPC4 Mk2 | Needs Adaptation | MPC4 is a protection card (4 channels), not a direct 16-channel monitoring replacement. |
| VIBRO-METER VM600 XMV16 | VIBRO-METER VM600 XMC16 | Needs Adaptation | XMC16 is a related condition monitoring card; channel count and pairing must be verified. |
Benchmark notes:
- 16 dynamic channels + 4 tachometer channels with 24-bit simultaneous acquisition.
- FFT resolution up to 6400 lines per 500 ms with asynchronous or synchronous sampling.
Always confirm the exact revision, XIO16T pairing, and VibroSight channel configuration against the original unit before installation.
Do you need the XMV16/XIO16T pairing guide or the VM600 rack slot layout for this module?
