Product Core Brief
- Model: RPS6U — 200-582-200-011
- Brand: VIBRO-METER
- Series: VM600 / VM600 Mk2 Machine Monitoring System
- Core Function: Front-mounted rack power supply that delivers +5 V and ±12 V to all cards in a VM600 ABE04X rack, with optional redundant operation.
- Product Type: VM600 Rack Power Supply Module
- Key Specs: +5 V and ±12 V outputs | AC or DC input versions | Redundant operation supported | Overvoltage, short-circuit, and overload protection | Front-mounted in 6U VM600 rack
- Condition: New Surplus
Product Introduction
VIBRO-METER RPS6U 200-582-200-011 is a rack power supply module for the VM600 and VM600 Mk2 machinery protection and condition monitoring systems. It is installed in the front of the VM600 ABE04X 19-inch rack and connects directly to the backplane to supply power to all installed monitoring, protection, I/O, relay, and communication cards.
The RPS6U provides +5 V and ±12 V DC outputs to the rack backplane and includes overvoltage, short-circuit, and overload protection. A single RPS6U can power a full rack, and two units can be installed for redundant operation with automatic switchover. It is commonly used in turbine, compressor, generator, pump, and rotating equipment monitoring systems across power generation, oil & gas, and petrochemical facilities.
The RPS6U family includes multiple part-number variants for different input voltage ranges and hardware revisions. The exact input type, voltage range, and revision for 200-582-200-011 should be confirmed against the module nameplate and official Vibro-Meter documentation before installation.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Product Type | VM600 Rack Power Supply Module |
| Brand | VIBRO-METER |
| System Compatibility | / Mk2 |
| Compatible Rack | VM600 ABE04X 19-inch, 6U |
| Mounting Position | Front slot |
| Output Voltages | +5 V DC and ±12 V DC |
| Input Type | AC or DC input versions available |
| Redundancy | Supported with dual RPS6U modules |
| Protection | Overvoltage, short-circuit, overload |
| Condition | New Surplus |
Note: Exact input voltage range, revision level, and allowable input interruption time for 200-582-200-011 should be verified from the module nameplate and official Vibro-Meter documentation.
Quality Control Process
Each unit begins with a visual inspection of the front panel, input connector, PCB, backplane contacts, and status indicators for corrosion, burnt traces, loose terminals, or mechanical damage. The RPS6U is then seated into a compatible VM600 ABE04X rack to verify mechanical fit and backplane engagement.
Input power is applied according to the module rating, and output voltages are measured on the backplane to confirm +5 V and ±12 V stability. Overvoltage, short-circuit, and overload protection behavior are checked where testable. Status LEDs are verified for proper power-on indication. Where possible, the module is tested with a loaded VM600 rack to confirm stable operation with installed monitoring and I/O cards. Final packing uses anti-static bags, foam inserts, and sealed cartons to protect the module during shipment.
Replacement Pitfall Guide
❗ Confirm the exact part number and input type. The RPS6U family includes AC and DC input variants. Installing a module with the wrong input rating can prevent startup or damage the power supply.
❗ Verify redundant configuration before removal. If the rack uses dual RPS6U modules, confirm that the remaining unit is healthy before removing the faulty one. Removing both units simultaneously will shut down the entire rack.
❗ Recheck backplane voltage after installation. After replacement, measure +5 V and ±12 V at the rack backplane. Incorrect output can cause erratic behavior in MPC4, CMC16, IOC4T, RLC16, and other installed cards.
❗ Confirm revision compatibility. Hardware revisions may differ in input range, connector type, or protection behavior. Always compare the replacement module against the original nameplate and official documentation.
❗ Monitor power interruption time. If external power is interrupted beyond the allowed duration, VM600 cards may reset. This must be considered during power source switching or maintenance.
Keep these in mind and you’ll cut 90% of rework time.
Compatibility Matrix & Benchmarks
| Original Model | Replacement / Successor Model | Compatibility Level | Migration Notes |
|---|---|---|---|
| VIBRO-METER RPS6U 200-582-200-011 | VIBRO-METER RPS6U 200-582-200-011 | Direct | Same part number; verify input type and revision. |
| VIBRO-METER RPS6U 200-582-200-011 | VIBRO-METER RPS6U 200-582-600-013 | Needs Adaptation | Same RPS6U family; confirm input voltage, revision, and rack compatibility. |
| VIBRO-METER RPS6U 200-582-200-011 | VIBRO-METER RPS1U | Needs Adaptation | Different power supply series; confirm frame type and output compatibility. |
| VIBRO-METER RPS6U 200-582-200-011 | VIBRO-METER MPC4 / CMC16 / IOC4T | Not Compatible | These are monitoring, protection, and I/O cards, not rack power supplies. |
Benchmark notes:
- Front-mounted 6U power supply for VM600 and VM600 Mk2 ABE04X racks.
- Supplies +5 V and ±12 V to all installed rack modules through the backplane.
- Supports single-unit or dual-unit redundant operation with automatic switchover.
Always confirm the exact input voltage, revision, and redundancy configuration against the original unit before installation.
