- Model: IOC16T — 200-565-000-013
- Brand: VIBRO-METER
- Series: VM600 / VM600 Mk2 Machine Monitoring System
- Core Function: Rear I/O module for VM600 condition monitoring cards, providing sensor inputs and data interface for vibration and speed monitoring.
- Product Type: VM600 I/O Module
- Key Specs: Supports 16 dynamic channels + 4 tachometer channels | Differential signal inputs | Designed for VibroSight software | Rear-mounted in VM600 rack
- Condition: New Surplus
Product Introduction
VIBRO-METER IOC16T 200-565-000-013 is an input/output module for the VM600 and VM600 Mk2 rack-based machinery monitoring systems. It serves as the I/O interface for VM600 condition monitoring cards such as CMC16, XMV16, and XMC16, providing differential signal inputs for vibration, speed, and process monitoring on turbines, compressors, generators, and other critical rotating equipment.
The IOC16T module is mounted in the rear of the VM600 rack and forms a card pair with the associated front monitoring module. It supports differential signal inputs for each dynamic and tachometer channel, and is designed for operation with VibroSight software. This module is commonly deployed in power generation, oil & gas, and petrochemical applications where high-density condition monitoring is required.
Note that Vibro-Meter documentation also references this family under the designation XIO16T; the IOC16T and XIO16T names are commonly used for the same or closely related VM600 16-channel I/O modules. The exact revision and compatibility for 200-565-000-013 should be confirmed against the module nameplate and official documentation.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Product Type | VM600 I/O Module |
| Brand | VIBRO-METER |
| System Compatibility | / Mk2 |
| Supported Channels | 16 dynamic + 4 tachometer |
| Signal Inputs | Differential per dynamic and tachometer channel |
| Compatible Front Cards | CMC16, XMV16, XMC16 |
| Software | VibroSight |
| Mounting | Rear-mounted in VM600 19″ rack |
| Typical Use | Vibration, speed, and combustion/process monitoring |
| Condition | New Surplus |
Note: Exact electrical ratings, connector types, and firmware level for 200-565-000-013 should be confirmed against the official Vibro-Meter datasheet and module nameplate.
Quality Control Process
Each unit begins with a visual inspection of the front panel, rear connectors, PCB, and backplane contacts for corrosion, bent pins, or thermal stress. The IOC16T is then seated into a compatible VM600 rack to verify mechanical fit and backplane engagement.
The module is paired with a compatible front monitoring card such as CMC16 or XMV16 to confirm proper card-pair recognition. Power is applied through the rack supply, and initialization indicators are checked for proper startup behavior. Channel integrity is verified with a precision signal source and Fluke multimeter to confirm input response, noise floor, and isolation. Communication with VibroSight software is tested where possible to confirm channel mapping and data acquisition. Final packing uses anti-static bags, foam inserts, and sealed cartons to protect the module during shipment.
Replacement Pitfall Guide
❗ Confirm the exact part number and revision. The IOC16T/XIO16T family includes multiple variants, and 200-565-000-013 may differ from other revisions in hardware, firmware, or connector configuration. Installing the wrong variant can prevent channel acquisition or cause signal faults.
❗ Verify the paired front monitoring card. The IOC16T cannot operate alone—it must be paired with a compatible front card such as CMC16, XMV16, or XMC16. Installing it behind an incompatible module will prevent proper operation.
❗ Revalidate channel mapping in VibroSight. After replacement, all dynamic and tachometer channels must be reconfirmed in the software. Wrong channel assignments can mask developing vibration issues or generate false alarms.
❗ Check sensor wiring and differential inputs. Each dynamic and tachometer channel uses differential signal inputs. Reversed polarity, poor shielding, or ground loops can introduce electrical noise that appears as mechanical vibration.
Keep these in mind and you’ll cut 90% of rework time.
Compatibility Matrix & Benchmarks
| Original Model | Replacement / Successor Model | Compatibility Level | Migration Notes |
|---|---|---|---|
| VIBRO-METER IOC16T 200-565-000-013 | VIBRO-METER IOC16T 200-565-000-013 | Direct | Same part number; verify rack compatibility and paired front card. |
| VIBRO-METER IOC16T 200-565-000-013 | VIBRO-METER XIO16T 620-002-000-113 / 620-003-111-112 | Needs Adaptation | Same I/O family; confirm revision, connector type, and paired card compatibility. |
| VIBRO-METER IOC16T 200-565-000-013 | VIBRO-METER IOC4T 200-560-000-016 / 200-560-101-015 | Not Compatible | IOC4T is for MPC4 protection cards, not 16-channel monitoring cards. |
| VIBRO-METER IOC16T 200-565-000-013 | VIBRO-METER IOCN 200-566-000-012 | Not Compatible | IOCN is a communication/network module for CPUM, not a monitoring I/O module. |
Benchmark notes:
- Supports 16 dynamic channels + 4 tachometer channels with differential signal inputs.
- Designed for pairing with CMC16, XMV16, and XMC16 monitoring cards in VM600 / VM600 Mk2 racks.
- Integrates with VibroSight software for vibration, speed, and combustion/process monitoring.
Always confirm the exact revision, paired front card, and VibroSight channel configuration against the original unit before installation.
