Component Snapshot At-a-Glance Model: Triconex 4107 Alt. P/N: None Product Series: Tricon Classic / Trident TMR SIS Platform Hardware Type: AC to DC Power Supply Module Key Feature: Hot-swap capable, N+1 redundant operation with overvoltage/overcurrent protection Primary Field Use: Converts mains AC to regulated 24VDC to power Tricon chassis, I/O and processor modules. Hard-Numbers:…
DetailsComponent Snapshot At-a-Glance Model: Triconex 2553-8 Alt. P/N: 7400056-380 Product Series: Tricon Classic TMR SIS Platform Hardware Type: Digital Input (DI) External Termination Board Key Feature: Direct field wiring termination, 24VDC, screw-clamp terminals Primary Field Use: Provides physical termination and isolation for 24VDC digital input signals between field devices and Tricon DI modules.
DetailsComponent Snapshot At-a-Glance Model: Triconex ICM4101 Alt. P/N: None Product Series: Tricon Classic / Trident TMR SIS Platform Hardware Type: Inter-Cabinet Communication Module Key Feature: Dual redundant highway ports with full TMR data voting and error checking Primary Field Use: Establishes reliable communication between main chassis and remote I/O cabinets across distributed SIS layouts. …
DetailsComponent Snapshot At-a-Glance Model: Triconex 2660-63 Alt. P/N: None Product Series: Trident (Legacy Triconex SIS) Hardware Type: Digital Output (DO) Module, Full-Height Key Feature: 32 channels, TMR voting, 2A per channel, hot-swap capable Primary Field Use: Drives 24VDC solenoids, relays, and ESD/F&G field devices in safety loops.
DetailsComponent Snapshot At-a-Glance Model: Triconex 2752 Alt. P/N: None Product Series: Trident (Triconex legacy SIS) Hardware Type: Highway Interface Communication Module Key Feature: Dual redundant highway ports, TMR voting, onboard diagnostics Primary Field Use: Connects Trident controllers to peer nodes and I/O highways in safety systems.
DetailsComponent Snapshot At-a-Glance Model: Triconex 2752 Alt. P/N: None Product Series: Trident (Triconex legacy SIS) Hardware Type: Highway Interface Communication Module Key Feature: Dual redundant highway ports, TMR voting, onboard diagnostics Primary Field Use: Connects Trident controllers to peer nodes and I/O highways in safety systems.
DetailsComponent Snapshot At-a-Glance Model: Triconex 3000120-380 Alt. P/N: None Product Series: Tricon 3000/3002 Safety Instrumented System (SIS) Hardware Type: Digital Input (DI) External Termination Module Key Feature: 100Ω precision termination + LED per-channel diagnostics for 24VDC DI loops Primary Field Use: Eliminates signal reflection and false trips on long DI wiring runs in SIS/ESD systems.
DetailsComponent Snapshot At-a-Glance Model: Triconex NCM4320 Alt. P/N: None Product Series: Tricon CX Compact SIS Hardware Type: Network Communication Module (NCM) Key Feature: Dual independent 10/100 Ethernet ports with TMR voting and full diagnostics Primary Field Use: Handles network data exchange, peer controller communication and time sync for Tricon CX safety systems. Hard-Numbers: Technical…
DetailsComponent Snapshot At-a-Glance Model: Triconex 7400028-100 Alt. P/N: 8110 Low‑Density Chassis, 7300028-001-C Product Series: Tricon V7 TMR SIS Platform Hardware Type: Passive Backplane / Main Chassis Key Feature: 15‑slot, fully triplicated TriBus/I/O/comm bus layers Primary Field Use: Houses and interconnects Tricon main processors, I/O, and comm modules in safety systems. Hard-Numbers: Technical Specifications Slot…
DetailsComponent Snapshot At-a-Glance Model: Triconex 3003-EMPII Alt. P/N: 3003, 3003EMPII Product Series: Tricon V7 EMPII, TMR SIS Platform Hardware Type: Main Processor (MP) Module Key Feature: TMR triple‑core architecture, SIL3/TÜV/nuclear safety approved Primary Field Use: Executes safety logic, I/O voting, and diagnostics in Tricon SIS/ESD systems.
Details
