Product Core Brief

• Model: JACP-317120
• Brand: YASKAWA
• Series: Yaskawa CP-317 System Power Supply
• Core Function: Power supply module for the Yaskawa CP-317 control system, designated as PS-01; provides system power to CP-317 racks and modules.
• Product Type: Power Supply Module
• Key Specs: CP-317 system | PS-01 type | JACP-317120 part number | Legacy control system spare
• Condition: New Original / New Surplus
• Status: Limited availability; confirm full model code, revision, rack type, and input voltage before ordering

Key Technical Specifications

• Product type: Yaskawa CP-317 system power supply module
• Part number:
• Module type: PS-01
• System platform: Yaskawa CP-317 control system
• Function: System power supply for CP-317 racks/modules
• Input voltage: To be confirmed from module nameplate or Yaskawa documentation
• Output rating: To be confirmed from nameplate or official specification sheet
• Mounting: Installed in compatible Yaskawa CP-317 rack or mounting base
• Typical applications: CP-317 system maintenance spares, legacy system support, retrofit projects, and plant turnaround replacements
• Handling: ESD-sensitive control module; verify model code, revision, rack compatibility, and wiring before installation

Note: Public spare-parts listings identify JACP-317120 as a Yaskawa CP-317 PS-01 power supply component. Detailed electrical ratings, input voltage, output capacity, and compatible rack models should be confirmed from the module nameplate or Yaskawa documentation.



Product Introduction

The JACP-317120 is a Yaskawa CP-317 system power supply module, commonly referenced as PS-01. It supplies power to the Yaskawa CP-317 control system and is used in legacy automation installations where reliable spare parts are required for ongoing operation.

This module is primarily relevant for maintenance teams, system integrators, and procurement specialists supporting existing Yaskawa CP-317 systems. Because CP-317 is a legacy platform, availability of original modules may be limited, and substitution should only be made after confirming full model code, revision, and rack compatibility.

For replacement projects, always compare the installed module nameplate with the replacement unit before procurement.

QA & Inspection SOP

Each unit is inspected before release:

1. Nameplate verification: Confirm part number JACP-317120 and PS-01 designation.
2. Visual inspection: Check housing, connectors, terminals, and PCB for damage, corrosion, or burn marks.
3. Connector check: Inspect backplane connectors and power terminals for bent pins, looseness, or oxidation.
4. Insulation check: Verify no visible short circuits between power terminals, connectors, and ground.
5. Label check: Confirm model code, revision, and serial information match the original module.
6. Power-on test: If testable, apply rated input power and verify normal power supply indicators.
7. Output check: Confirm stable output voltage under safe test conditions, if equipment is available.
8. Packaging: Protect connectors and terminals with anti-static packaging.

Full system validation requires installation in a compatible Yaskawa CP-317 rack with verified system configuration.

Installation Pitfalls & Guide

❗ Confirm the exact part number. JACP-317120 must match the original PS-01 module. Do not substitute with other CP-317 modules without verification.

❗ Verify rack compatibility. Ensure the target CP-317 rack or mounting base supports the PS-01 power supply module.

❗ Check input voltage. Confirm the module input voltage matches the site power supply before energizing.

❗ Inspect connectors and terminals. Power supply modules are sensitive to poor connections, corrosion, or loose terminals.

❗ Follow plant safety procedures. De-energize the rack before replacing power supply modules unless approved hot-swap procedures are in place.

Installation steps:

1. Pre-install: Record the original module part number, revision, slot position, and wiring labels.
2. Isolate power: De-energize the CP-317 rack according to site safety procedures.
3. Install: Seat the JACP-317120 firmly in the correct power supply slot.
4. Connect: Reconnect power and backplane connections according to the original configuration.
5. Power-up: Restore input power and check power supply status indicators.
6. Verify: Confirm normal CP-317 system operation and absence of power or communication alarms.



Technical FAQ

What is YASKAWA JACP-317120?
It is a Yaskawa CP-317 PS-01 power supply module used to provide system power for the CP-317 control system.

Which system does it belong to?
It belongs to the Yaskawa CP-317 control system platform.

Can it replace other CP-317 power supplies?
Not without verification. Only substitute with modules confirmed to have the same part number, revision, and electrical ratings.

What should I check before ordering?
Confirm the full part number JACP-317120, PS-01 designation, revision, input voltage, rack model, and original module nameplate. A nameplate photo is the most reliable way to verify compatibility.
