Product Core Brief
- Model: 200-582-915-032
- Brand: VIBRO / Vibro-Meter
- Series: VM600 Machine Protection System
- Core Function: Input/output module for VM600 machine protection and condition monitoring racks.
- Product Type: VM600 I/O Module
- Key Specs: VM600 19″ rack-compatible | Backplane communication | Discrete/analog I/O support
- Condition: New Surplus
Product Introduction
VIBRO 200-582-915-032 is a VM600 input/output module used in Vibro-Meter machine protection and condition monitoring systems. It handles discrete and/or analog signals between field devices and the VM600 rack, supporting alarm routing, status feedback, and process interfacing.
This module is typically installed in VM600 19″ racks alongside MPC4, CMC16, CPUM, RLC16, and related cards. Exact I/O count, voltage levels, and relay configuration depend on the specific revision, so always verify the nameplate and datasheet before wiring.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Product Type | VM600 I/O Module |
| Brand | VIBRO / Vibro-Meter |
| System Compatibility | VM600 Machine Protection System |
| Function | Discrete/analog I/O interfacing |
| Mounting | VM600 19″ rack module |
| Communication | VM600 backplane integration |
| Typical Use | Alarm signaling, status I/O, process interfacing |
| Condition | New Surplus |
Note: Detailed channel count, voltage ratings, and relay specifications should be confirmed against the official Vibro-Meter datasheet for this exact part number.
Quality Control Process
Each unit starts with a visual inspection of the front panel, connectors, terminal blocks, and PCB for corrosion, heat marks, or bent pins. The module is then seated into a compatible VM600 rack to verify mechanical fit and backplane recognition.
Power is applied through the rack supply, and the module is checked for proper initialization and diagnostic LED behavior. I/O channels are exercised with a precision signal source and Fluke multimeter to verify analog accuracy and discrete switching. Relay outputs, if present, are load-tested to confirm contact operation and isolation. Final packing uses anti-static bags, foam inserts, and sealed cartons to protect the module during shipment.
Replacement Pitfall Guide
❗ Confirm the exact part number and revision. VM600 I/O modules share similar housings, but channel counts, voltage levels, and relay configurations can differ. Installing the wrong variant can cause missed alarms or incorrect trip behavior.
❗ Verify rack slot assignment and backplane recognition. VM600 modules must be configured in the correct slot. A card that powers up but is not recognized by the CPUM will not participate in protection logic.
❗ Recheck I/O scaling and alarm setpoints. Analog ranges, engineering units, and trip thresholds may not carry over automatically. Wrong scaling on vibration, temperature, or speed signals can force unsafe operating conditions.
❗ Inspect terminal wiring before energizing. Loose terminals, reversed polarity, or shared grounds can create false trips. Keep field wiring separated from sensor cables and confirm shield termination at one end only.
Keep these in mind and you’ll cut 90% of rework time.
Compatibility Matrix & Benchmarks
| Original Model | Replacement / Successor Model | Compatibility Level | Migration Notes |
|---|---|---|---|
| VIBRO 200-582-915-032 | VIBRO 200-582-915-032 | Direct | Same part number; verify rack firmware and I/O configuration. |
| VIBRO 200-582-915-032 | VIBRO VM600 IOC4T / IOC16T | Needs Adaptation | Similar I/O family; channel count and wiring must be verified. |
| VIBRO 200-582-915-032 | VIBRO VM600 RLC16 Relay Module | Needs Adaptation | Relay output module; not a direct I/O replacement without reconfiguration. |
Benchmark notes:
- Integrates with VM600 19″ racks for machine protection and condition monitoring.
- Supports discrete and/or analog I/O depending on module revision.
Always confirm the exact I/O map, firmware revision, and terminal wiring against the original unit before installation.
