Product Core Brief
- Model: 200-566-000-113
- Brand: VIBRO-METER
- Series: VM600 IOCN
- Core Function: Provides Ethernet and serial communication between the VM600 rack, VibroSight/MPSx software, and supervisory systems.
- Product Type: VM600 communication/network interface module
- Key Specs: 10/100Base-T Ethernet | RS-485 serial | 24 VDC rack-powered | 0 to +55°C
- Condition: New original / new surplus — verify on nameplate
Product Introduction
The VIBRO-METER IOCN 200-566-000-113 is a VM600 communication and network interface module. It sits in the VM600 rack and connects the machinery protection system to VibroSight, VM600 MPSx, Modbus TCP/PROFINET hosts, and RS-485 networks.
This card does not accept direct sensor inputs. It exchanges status, alarms, configuration, and diagnostic data over the VM600 backplane and external networks. Typical operating range is 0 to +55°C, with power drawn from the rack backplane, commonly 24 VDC.
Key Technical Specifications
- Part number: 200-566-000-113
- Product family: VM600 IOCN
- Module type: Communication/network interface card
- Ethernet: 10/100Base-T, RJ-45
- Serial: RS-485 network support
- Protocols: VibroSight / VM600 MPSx, Modbus TCP, PROFINET — confirm per firmware
- Power: Supplied via VM600 rack backplane, typically 24 VDC
- Operating temperature: 0 to +55°C (rack/environment dependent)
- Installation: 6U Eurocard plug-in module for 19-inch VM600 rack
- Depth: Approximately 160 mm
- I/O type: No direct sensor inputs; backplane and network communication only
- Indicators: Front-panel status LEDs, model/revision dependent
Quality Control Process (Dynamic for Communication Module)
- Nameplate and revision check: Confirm 200-566-000-113, hardware revision, and firmware compatibility with the installed VM600 rack.
- Connector inspection: Verify RJ-45 ports, serial connectors, backplane pins, and captive screws for damage or corrosion.
- Power-up test: Seat the module in a compatible VM600 rack and confirm normal LED behavior and backplane detection.
- Network validation: Test Ethernet link, IP assignment, and communication with VibroSight/MPSx or the intended host system.
- Packing: Place in an anti-static bag with connector protection, foam support, and rigid carton for shipment.
Replacement Pitfall Guide
❗ Do not assume all IOCN revisions are identical. The 200-566-000-113 may differ from 200-566-000-012 or 200-566-101-012 in firmware, protocol support, or LED mapping.
❗ Do not treat this card as a sensor input module. The IOCN handles communication and network gateway functions, not direct vibration or proximity probe signals.
❗ Verify rack firmware and CPUM/MPC4 compatibility before installation. A mismatched firmware level can block network visibility even if the card powers up.
❗ Check IP addressing and protocol licensing before site commissioning. Modbus TCP, PROFINET, and VibroSight connectivity often depend on configured parameters rather than hardware alone.
Keep these in mind and you’ll cut 90% of rework time.
Compatibility Matrix & Benchmarks
| Original Model | Replacement / Successor Model | Compatibility Level | Migration Notes |
|---|---|---|---|
| VIBRO-METER IOCN 200-566-000-113 | IOCN 200-566-000-113, matching revision | Direct | Match hardware/firmware revision |
| IOCN 200-566-000-012 / 200-566-101-012 | IOCN 200-566-000-113 | Revision-dependent | Verify protocol support and rack compatibility |
| IOCN 200-566-000-113 | Newer VM600 communication module | Pending OEM confirmation | Check Vibro-Meter/Parker Meggitt documentation |
Benchmarks: 10/100Base-T Ethernet with RS-485 serial; VM600 backplane communication; typically 0 to +55°C operating range and 24 VDC rack power.
