Product Core Brief

• Model: XIO16T (market listings sometimes label it as IOC16T; confirm on nameplate)
• Brand: VIBRO-METER
• Series: VM600
• Core Function: Rear I/O module that provides 16 dynamic channels and 4 tachometer channels for XMV16 or XMC16 condition monitoring modules in a VM600 ABE04x rack.
• Product Type: VM600 rear I/O / interface module
• Key Specs: 16 dynamic channels + 4 tachometer channels | differential inputs | RJ45 Ethernet for VibroSight | mounts at rear of ABE04x rack | forms a card pair with XMV16/XMC16
• Condition: New original / new surplus — verify exact PNR and revision

Product Introduction

The VIBRO-METER VM600 XIO16T is the rear input/output module used with XMV16 and XMC16 condition monitoring cards in VM600 Mk2 / VM600 rack-based machinery monitoring systems. It provides the physical sensor and speed interfaces required by the front-mounted processing module, while also carrying an Ethernet port for VibroSight communication.

Part numbers 200-565-101-013 and 200-565-000-013 both appear in surplus listings for this I/O module family. The “VMF-IOC16T” label is often a marketplace listing name rather than an official VIBRO-METER product series; the VM600 documentation and system diagrams typically refer to this card as XIO16T. Always confirm the exact model, revision, and Ethernet/VibroSight capability from the nameplate.

The XIO16T installs at the rear of a VM600 ABE040, ABE042, or ABE056 rack, directly behind the associated XMV16 or XMC16 module. The two modules operate as a matched card pair.

Key Technical Specifications

• Part numbers: 200-565-101-013 / 200-565-000-013
• Product family: VM600 XIO16T rear I/O module
• Compatible front modules: XMV16, XMC16
• Channel capacity: 16 dynamic channels + 4 tachometer channels
• Input type: Differential signal input per dynamic and tachometer channel
• Communication: RJ45 Ethernet connector for VibroSight software
• Mounting position: Rear of VM600 ABE04x system rack
• Rack compatibility: VM600 ABE040, ABE042, ABE056
• Configuration: Operates as a card pair with the front XMV16/XMC16 module
• Hot-swappable: Supported per VM600 module design; follow OEM procedure
• Operating temperature: Typically -20°C to +65°C for VM600 I/O modules — confirm per revision
• Humidity: Up to 95% non-condensing per VM600 rack family spec
• Protection rating: Typically IP20 when installed in a VM600 rack

Quality Control Process (Dynamic for Rear I/O Module)

• Nameplate verification: Confirm XIO16T vs. IOC16T labeling, exact PNR, and hardware revision.
• Connector inspection: Check rear sensor connectors, RJ45 port, and backplane contacts for damage.
• Backplane pin check: Inspect mating pins for bent contacts, corrosion, or misalignment.
• Pairing check: Confirm it is matched to the correct XMV16 or XMC16 front module.
• Ethernet function check: Verify VibroSight communication if the unit includes an RJ45 port.
• Channel integrity check: Test dynamic and tachometer channel continuity where test equipment is available.
• Packing: Protect rear connectors, use anti-static packaging, and secure with foam in a rigid carton.

Replacement Pitfall Guide

❗ Do not confuse XIO16T with IOC4T or IOCN. IOC4T serves MPC4, IOCN serves CPUM, and XIO16T serves XMV16/XMC16.

❗ Do not assume 200-565-101-013 and 200-565-000-013 are fully interchangeable. Revision differences may affect Ethernet behavior, firmware, or accessory configuration.

❗ Do not install XIO16T as a standalone front card. It is a rear I/O module and must mate with the correct XMV16 or XMC16 module.

❗ Verify VibroSight compatibility. If the system relies on Ethernet-based configuration or data access, confirm the RJ45 interface is present and functional.

❗ Check rack compatibility. XIO16T is designed for VM600 ABE040/ABE042/ABE056 racks; it is not a generic DIN-rail I/O card.

❗ Document slot pairing before removal. Swapping rear I/O modules without recording slot positions can cause channel mapping errors.

Keep these in mind and you’ll cut 90% of rework time.

Compatibility Matrix & Benchmarks

Benchmarks: VM600 rear I/O module for XMV16/XMC16; 16 dynamic + 4 tachometer channels; differential inputs; RJ45 Ethernet for VibroSight; mounts at rear of ABE04x rack; operates as a card pair; compatible with ABE040/ABE042/ABE056.

If you can share a nameplate photo, I can confirm whether your unit is officially labeled XIO16T or IOC16T and finalize the exact revision compatibility.
