Product Core Brief
- Model: DSTXW110
- Brand: ABB
- Series: S800 I/O Wiring Termination Bases
- Core Function: Translates S800 ribbon header signals to field screw terminals for simplified discrete and analog field wiring routing.
- Product Type: Ribbon Cable Wiring Terminal Base Unit
- Key Specs: 40-pin ribbon interface | Screw terminal field connections | 2.5 mm² max wire gauge Condition: New Original (New Surplus)
Product Introduction
The ABB is a passive wiring base built to mate ribbon-equipped S800 I/O modules and separate bundled internal bus signals to individual field terminal points.Well, technically it shares DIN rail footprint with TU810 standard termination units, yet the ABB relies on ribbon interconnection instead of direct module pin mating, cutting field rework time during module swaps by roughly 60%. Its terminal block layout supports mixed digital and analog signal routing without cross-talk above 0.1%.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Model Code | |
| Connection Interface to I/O Card | 40-pin flat ribbon cable header |
| Field Termination Type | Screw clamp terminal blocks |
| Maximum Conductor Gauge | 2.5 mm² solid copper wire |
| Signal Compatibility | Analog 4–20 mA / ±10 V, 24 V DC digital discrete signals |
| Dielectric Withstand Voltage | 500 V AC between adjacent signal channels |
| Operating Ambient Temperature | -20 °C to +60 °C cabinet mounted |
| Storage Temperature Range | -40 °C to +85 °C non-operating storage |
| Physical Mounting | Standard S800 DIN rail slot form factor |
| Unit Net Weight | 0.31 kg without ribbon cable |
| Enclosure Rating | IP20 indoor cabinet use only |
| Channel Isolation Layout | Grouped 8-channel signal partitions to reduce cross-talk |
| Compatible Ribbon Cables | TK801, TK802 series ribbon harnesses |
Quality Control Process
- Incoming Verification: Match serial batch codes to ABB wiring base production logs to filter counterfeit assemblies. Visual inspection checks for cracked terminal housings, bent ribbon header pins, or stripped screw clamp threads (—minor plastic molding flash does not trigger QA rejection).
- Live Functional Test: Attach a calibrated TK801 ribbon cable to the unit and mate with a reference DSAI130 analog module on an test backplane, supply regulated 24 V rack power, and run continuous signal injection for a 24-hour cycle with cross-talk voltage logging.
- Electrical Parameter Test: Use a Megger MIT300 at 500 V to measure channel-to-channel insulation resistance; all signal partitions must register above 10 MΩ. Verify DIN rail protective earth continuity via Fluke 115 multimeter across chassis ground lug.
- Firmware Verification: This passive wiring base contains no onboard firmware; photograph ribbon header pin labeling and terminal group divisions as field replacement reference records.
- Final QC & Packaging: Tighten all terminal screws to factory torque spec, cap unused terminal openings with plastic dust plugs, seal the unit inside anti-static shielding bag, and attach a dated QC Passed sticker with assigned test technician ID.
Replacement Pitfall Guide
- Firmware Mismatch: The itself holds no firmware, but paired I/O modules running outdated firmware v4.2 or older may misinterpret ribbon signal mapping when mated with newer ABB hardware. Update controller runtime to resolve channel offset faults.
- DIP Switch / Jumper Misconfiguration: The wiring base has no internal jumpers; mismatched ribbon cable pinout variants between ABB and TU-series direct-mate bases create reversed field signal polarity.
- Power Supply Mismatch: Undervoltage rack 24 V PSU output below 18 V amplifies minor cross-talk on analog channels routed through the terminal blocks. Calculate full rack load plus 20% headroom for stable signal levels.
- ESD Damage: Static discharge risk rises heavily at plant humidity below 30%. Place an anti-static mat under the DIN rail during base swaps; bare contact with ribbon header traces can create permanent high-resistance signal paths.
Keep these in mind and you’ll cut 90% of rework time.
Compatibility Matrix & Benchmarks
Compatibility Matrix
- → : Direct — Exact ribbon pin layout, terminal grouping, and DIN rail mounting drop-in replacement
- → TU810 : Needs Adaptation — No ribbon interface, full retermination of all field wiring required
- → DSTA131 : Incompatible — Analog dedicated termination base without 40-pin ribbon header hardware
- → DSSR122 : Incompatible — Relay output terminal unit does not support ribbon cable interconnection
Benchmarks
- Inter-channel signal cross-talk: <0.1% full scale (4–20 mA analog load)
- Ribbon signal propagation delay: 0.02 ms per 1 m TK801 cable run
