Product Core Brief
- Model: 3BHE003604R0102 (UFC765AE102)
- Brand: ABB
- Series: ABB AC 800M DCS / Industrial Automation I/O Series
- Integration Role: Input/Output signal interface module for connecting field devices with control systems, enabling data transmission and signal conversion.
- Product Type: I/O Module / Control Board
- Key Specs: IP65 Protection | -40°C to 80°C Operating Range | Multi-Protocol Support
- Note: Condition: New Original (New Surplus).
Key Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer Part Number | 3BHE003604R0102 |
| Device Model | |
| Functional Type | Input/Output Module / Control Board |
| Protection Rating | IP65 (Dust-tight & Water-resistant) |
| Operating Temperature | -40°C to +80°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | 150mm × 100mm × 50mm |
| Weight | 250g |
| Housing Material | Aluminum Alloy |
| Application Field | Industrial Automation, Robotics, Process Control |
| Condition | New Original (New Surplus) |
Product Introduction
The ABB 3BHE003604R0102 (UFC765AE102) is a robust input/output module designed for industrial automation and process control applications. It serves as a critical interface between field devices (sensors, actuators) and higher-level control systems, handling signal acquisition, processing, and output control.
For system integrators, this module offers reliable operation in harsh industrial environments thanks to its IP65 protection rating and wide operating temperature range (-40°C to +80°C). Its aluminum alloy housing provides excellent mechanical strength and heat dissipation. The module supports multiple logic value processing capabilities, handling both boolean (true/false) and analog range inputs/outputs, making it suitable for complex control logic in applications ranging from robotics to process automation.
Integration & Application Notes
As an I/O interface module, proper integration focuses on signal compatibility and environmental considerations.
- System Compatibility: This module is designed for ABB automation platforms. Verify your host controller’s backplane compatibility and communication protocol requirements before installation.
- Signal Configuration: The module supports various logic value processing, including boolean states and analog ranges. Ensure your control program correctly maps the I/O addresses and data types to match the field device specifications.
- Environmental Protection: With an IP65 rating, this module is suitable for outdoor or dusty/wet industrial environments (e.g., wind power, port machinery). Ensure all cable glands and connectors are properly sealed to maintain the protection rating.
- Thermal Management: The aluminum housing provides passive heat dissipation. Ensure adequate airflow around the module, especially in high-temperature environments approaching the 80°C upper limit.
- Power Supply: Verify the input voltage requirements match your system’s power distribution. Incorrect voltage can damage the module or connected field devices.
Integrator’s FAQ
1. What types of signals can this I/O module handle? The UFC765AE102 supports multiple signal types, including digital (boolean true/false) and analog (numerical range) inputs and outputs. This flexibility allows it to interface with a wide variety of field devices, from simple limit switches to analog sensors like pressure transmitters or temperature probes.
2. Can this module be used in outdoor or harsh environments? Yes. With an IP65 protection rating, this module is dust-tight and protected against water jets from any direction. Combined with its wide operating temperature range (-40°C to +80°C), it is well-suited for outdoor installations such as wind turbines, port cranes, or other exposed industrial equipment.
3. Is this module compatible with non-ABB control systems? While designed for ABB platforms, the module’s I/O functionality is based on standard signal types. However, integration with non-ABB systems would require verifying physical connector compatibility, communication protocol support, and proper configuration through the host system’s engineering tools. Consult your system integrator for cross-platform integration guidance.
4. What is the warranty difference between New Surplus and Refurbished? We supply this unit as New Original (New Surplus), meaning it is unused, original factory stock, typically still in its anti-static packaging. This comes with a standard 12-month warranty. “Refurbished” I/O modules carry risks including aged components, worn connectors, or potential damage from previous installations. Refurbished units often come with short, limited warranties (30-90 days) that do not cover latent defects.
5. Why is the pricing lower than direct OEM but higher than used parts? Our pricing reflects the value of guaranteed, unused condition. Unlike used parts from general marketplaces—which may have unknown operational hours, hidden damage, or corroded contacts—our New Surplus inventory is verified for authenticity and condition. You avoid the premium of custom OEM manufacturing for legacy parts while securing a component that performs like new, minimizing the risk of unplanned downtime in critical automation applications.
