Product Core Brief

• Model: 3500/15-04-00-00 (Part Number: 133300-01)
• Brand: Bently Nevada (Baker Hughes / GE)
• Series: 3500 Machinery Protection System
• Core Function: Low Voltage Direct Current (LVDC) power supply and Power Input Module (PIM) providing clean, converted internal power for 3500 rack modules.
• Product Type: LVDC Power Supply & PIM Assembly
• Key Specs: 20-30 VDC Input | Half-Height | Hot-Swap Capable
• Condition: New Surplus / OEM Original

BENTLY 3500/15 127610-01

Key Technical Specifications

• Module Type: 3500/15 Low Voltage DC Power Supply & PIM
• Part Number: 133300-01
• Input Voltage Range: 20 to 30 Vdc
• Mounting Position: Left-side designated half-height slot in 3500/05 Frame
• Redundancy: Supports dual power supply configuration (Main/Backup)
• Hot-Swap Capability: Yes (when redundant power is installed)
• Operating Temperature: -30°C to +65°C
• Storage Temperature: -40°C to +85°C
• Humidity Tolerance: Up to 95% (Non-condensing)
• Compliance: FCC Rule Part 15
• System Compatibility: 3500/05 Rack, 3500/22 TDI

Product Introduction

Serving as the reliable power heart of the 3500 Machinery Protection System, this Bently Nevada 3500/15-04-00-00 assembly includes the 133300-01 Low Voltage DC Power Input Module (PIM). Engineered for industrial environments utilizing 24VDC control power, it accepts 20-30 VDC input and converts it to the precise internal DC bus voltages required by all 3500 monitoring modules.

Designed for continuous operation and maximum uptime, this half-height module installs in the left-side power slots of the 3500/05 frame. When paired with a second power supply, it provides seamless redundant power distribution, allowing maintenance personnel to safely remove or replace a failed power module without interrupting critical machinery protection.

QA & Testing SOP

Power supplies dictate system reliability. We rigorously verify voltage conversion, load capacity, and redundancy logic.

1. Anti-Counterfeit & Visual Audit: We inspect the Bently Nevada silkscreen, verify the 133300-01 part number, and check the PIM rear connectors and front panel for physical damage or oxidation.
2. Voltage Conversion Test: We apply 24 VDC to the PIM and measure the internal backplane outputs to verify they meet exact OEM tolerances.
3. Load & Ripple Check: We apply a simulated full-rack load to ensure the power supply maintains stable voltage without excessive ripple or thermal throttling.
4. Redundancy Failover Validation: Installed in a dual-power test rack, we verify that removing the primary power module results in zero interruption to the backplane.
5. ESD Safe Packaging: High-current power conversion ICs are sensitive to electrostatic discharge. We pack in anti-static shielding bags with desiccant to prevent latent semiconductor damage.

Installation Pitfalls & Guide

❗ Slot Position & Redundancy Hierarchy: The 3500/15 modules must be installed in the left-most designated half-height slots. When installing dual power supplies for redundancy, the lower slot acts as the primary power source, and the upper slot acts as the backup. Misconfiguring this physical hierarchy can compromise hot-swap functionality.

❗ PIM Compatibility: The 133300-01 is specifically the Low Voltage DC PIM. It is not interchangeable with legacy high-voltage or low-voltage AC PIMs. Always match the exact part number to your system’s DC power infrastructure.

❗ Input Voltage Verification: Before connecting, verify your field power supply is strictly regulated within the 20-30 Vdc range. Over-voltage can instantly destroy the internal conversion circuitry, while under-voltage can cause intermittent module resets.

Replacement SOP:

1. Pre-Install: Verify the presence of a redundant secondary power supply; place the machine in bypass/maintenance mode.
2. Removal: Disconnect the 24 VDC input wiring; release the locking mechanism and extract the 3500/15 module.
3. Install: Slide the new 3500/15-04-00-00 into the correct half-height slot; ensure firm backplane seating; reconnect the LVDC wiring.
4. Power-On Test: Verify the module status LEDs indicate healthy input; confirm backplane voltage stability before removing maintenance bypass.


   BENTLY 3500/15 127610-01

Technical FAQ

What does the “-04” in 3500/15-04-00-00 mean?
The “-04” designates the Low Voltage DC (20-30 Vdc) power configuration. Other common variants include “-01” (Low Voltage AC), “-02” (High Voltage AC), “-03” (High Voltage DC), and “-05” (Universal AC).

Is 133300-01 just the PIM or the whole power supply?
133300-01 is specifically the Power Input Module (PIM) that connects directly to the rear of the 3500/15 power supply. In many surplus listings, the part number refers to the PIM component, but it is designed to mate seamlessly with the corresponding 3500/15 LVDC power supply assembly.

Can I mix AC and DC power supplies in the same rack?
Yes. The 3500/05 frame supports mixing different power types (e.g., one Universal AC and one LVDC) for redundancy. However, always ensure the primary and backup supplies are configured correctly in the 3500 Configuration Software.

Can I hot-swap this power supply while the turbine is running?
Yes, but only if a second (redundant) power supply is installed and active. With dual power supplies, removing or inserting one module will not interrupt rack operation. Hot-swapping a single power supply will cause a complete rack power loss and trigger a fail-safe machine trip.

Why is this sold as new surplus?
This unit was pulled from sealed OEM overstock or an unfulfilled project before installation. We test it on our OEM 3500 test racks to verify voltage conversion and redundancy, but we aren’t replacing internal components. You’re getting unused factory hardware with original manufacturing tolerances at a fraction of the active OEM list price.
