Product Core Brief
- Model: YOKOGAWA ADV151-P60/D5A00
- Brand: YOKOGAWA
- Series: CENTUM VP / ADV151 Digital Input Series
- Core Function: Reads 32 isolated 24 VDC digital inputs from switches, relays, and status contacts for CENTUM VP and CS 3000 DCS systems.
- Product Type: DCS Digital Input Module
- Key Specs: 32 channels | 24 VDC | isolated | status indication | KS cable interface
- Condition: New Original (New Surplus) / Factory Sealed
Product Introduction
A missed contact input can hide a pump trip, valve position fault, or permissive failure until the process is already upset. The YOKOGAWA ADV151-P60/D5A00 is a 32-channel isolated 24 VDC digital input module for CENTUM VP / CS 3000 DCS, used to monitor field contact status from relays, pushbuttons, limit switches, and auxiliary contacts.
The “-P” suffix indicates pushbutton/contact input type; “6” means the module has status indication with no explosion protection; “0” is the basic option; and “/D5A00” identifies the KS cable interface adapter for connection to the terminal board. This makes it a direct replacement for existing ADV151-P60/D5A00 slots where the wiring already uses KS-type cabling. Keeping one sealed spare available can prevent extended downtime when a DI card fails or shows intermittent channel faults.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Model | AWA 0 |
| Product Type | Digital Input Module (DCS) |
| Compatible System | CENTUM VP / CS 3000 series |
| Input Signal | 24 VDC digital input |
| Channels | 32 isolated channels |
| Input Type | Pushbutton/contact input (-P) |
| Status Indication | Yes, with status indication |
| Explosion Protection | No explosion protection |
| Interface Option | /D5A00 — KS cable interface adapter |
| Typical Application | Contact status monitoring, permissive inputs, relay feedback, switch status |
Key Selling Points & Differentiators
- 32-channel isolated 24 VDC digital input for CENTUM VP / CS 3000 systems.
- Status indication helps technicians verify field contact status during troubleshooting.
- /D5A00 KS cable interface matches existing terminal wiring without re-engineering.
- Direct replacement for ADV151-P60/D5A00 installations.
- Factory-sealed surplus inventory with visual QA and 12-month warranty.
- Not recommended for AC input applications; consider ADV141 or ADV142 for 100–120 VAC or 200–240 VAC inputs.
Quality Transparency SOP
- Visual inspection: Verify label, “ADV151-P60/D5A00,” connector pins, and housing for moisture, corrosion, or handling damage.
- Seal verification: Confirm original anti-static bag, desiccant, and factory labeling before opening.
- Backplane power check: Verify 5 VDC and 24 VDC rails before insertion to avoid unstable channel readings.
- Channel input test: Apply known 24 VDC signals to multiple channels and confirm ON/OFF status in the DCS.
- Isolation check: Verify channel isolation and insulation resistance per Yokogawa specifications.
- Interface check: Confirm the KS cable adapter mates correctly with the existing terminal board and cable type.
Technical Risk Avoidance
❗ Confirm the /D5A00 interface before ordering. This variant uses the KS cable interface; it may not match systems wired for /CCC01, /B5S00, or other terminal options.
❗ Verify the suffix code. ADV151-P60 is not the same as ADV151-P00, ADV151-E00, ADV151-P50, or ADV151-P63; differences affect status indication, environmental rating, and terminal options.
❗ Check input voltage compatibility. This module is specified for 24 VDC digital inputs; do not use it for AC or higher-voltage signals.
❗ In redundant or mixed-node configurations, ensure the replacement module matches the original suffix and interface code.
Buyer’s FAQ
Is the YOKOGAWA ADV151-P60/D5A00 a genuine OEM part?
Yes. It is an original Yokogawa ADV151 series digital input module supplied as new surplus, factory sealed when available. We do not rebrand or relabel third-party substitutes.
What does “P60/D5A00” mean?
“-P” means pushbutton/contact input type. “6” means status indication with no explosion protection. “0” is the basic option. “/D5A00” is the KS cable interface adapter option.
Can I replace an ADV151-P00/D5A00 with this module?
Functionally yes for 24 VDC digital input, but the P60 adds status indication. If your existing card is P00, P50, P63, or E-series, confirm the suffix and interface before substitution.
What systems is it compatible with?
It is designed for Yokogawa CENTUM VP and CS 3000 DCS systems using ADV151-series digital input slots.
What warranty do you offer?
A 12-month warranty against manufacturing defects and DOA issues. Damage from incorrect wiring, overvoltage, backplane faults, or mismatched terminal interface is not covered.
