Product Core Brief
- Model: YOKOGAWA ADV551-P60/D5A00
- Brand: YOKOGAWA
- Series: CENTUM VP / ADV551 Digital Output Series
- Core Function: Drives 32 isolated 24 VDC digital outputs for solenoid valves, relays, motor starters, and indicator circuits in CENTUM VP / CS 3000 DCS.
- Product Type: DCS Digital Output Module
- Key Specs: 32 channels | 24 VDC | isolated | status display | KS cable interface
- Condition: New Original (New Surplus) / Factory Sealed
Product Introduction
A failed digital output card can leave solenoid valves, relays, or permissive circuits stuck in an unsafe state. The YOKOGAWA ADV551-P60/D5A00 is a 32-channel isolated 24 VDC digital output module for CENTUM VP and CS 3000 DCS, used to command field devices such as solenoid valves, relays, motor starters, and status indicators.
The “-P” suffix indicates pulse-width output / time-proportional output capability; “6” means the module has status display with no explosion protection; “0” is the basic option; and “/D5A00” identifies the KS cable interface adapter ATD5A-00 for connection to the terminal board. This makes it a direct replacement for existing ADV551-P60/D5A00 slots where the wiring already uses KS-type cabling. Keeping one sealed spare available can prevent extended downtime when a DO card fails or shows intermittent channel faults.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Model | AWA 0 |
| Product Type | Digital Output Module (DCS) |
| Compatible System | CENTUM VP / CS 3000 series |
| Output Signal | 24 VDC digital output |
| Channels | 32 isolated channels |
| Output Type | Pulse-width / time-proportional output capable (-P) |
| Status Display | Yes, with status display |
| Explosion Protection | No explosion protection |
| Interface Option | /D5A00 — KS cable interface adapter ATD5A-00 |
| Typical Application | Solenoid valves, relays, motor starters, permissive outputs, indicator circuits |
Key Selling Points & Differentiators
- 32-channel isolated 24 VDC digital output for CENTUM VP / CS 3000 systems.
- Status display helps technicians verify output status during troubleshooting.
- /D5A00 KS cable interface matches existing terminal wiring without re-engineering.
- Supports pulse-width and time-proportional output functions for advanced control tasks.
- Direct replacement for ADV551-P60/D5A00 installations.
- Factory-sealed surplus inventory with visual QA and 12-month warranty.
- Not recommended for relay-output or AC-output applications; consider ADR541 for relay outputs or ADV557/ADV561 for other DO configurations.
Quality Transparency SOP
- Visual inspection: Verify label, “ADV551-P60/D5A00,” connector pins, and housing for moisture, corrosion, or handling damage.
- Seal verification: Confirm original anti-static bag, desiccant, and factory labeling before opening.
- Backplane power check: Verify 5 VDC and 24 VDC rails before insertion to avoid unstable channel behavior.
- Channel output test: Command multiple channels ON/OFF and verify 24 VDC presence at the terminal block.
- Isolation check: Verify channel isolation and insulation resistance per Yokogawa specifications.
- Interface check: Confirm the KS cable adapter ATD5A-00 mates correctly with the existing terminal board and cable type.
Technical Risk Avoidance
❗ Confirm the /D5A00 interface before ordering. This variant uses the KS cable interface adapter ATD5A-00; it may not match systems wired for /D5S00, /D5D00, /CCC01, or other terminal options.
❗ Verify the suffix code. ADV551-P60 is not the same as ADV551-P50, ADV551-PE0, ADV551-PF0, or ADV551-P63; differences affect status display, environmental rating, and explosion protection.
❗ Check output load compatibility. This module is specified for 24 VDC digital outputs; do not use it for AC or relay-output applications.
❗ In redundant or mixed-node configurations, ensure the replacement module matches the original suffix and interface code.
Buyer’s FAQ
Is the YOKOGAWA ADV551-P60/D5A00 a genuine OEM part?
Yes. It is an original Yokogawa ADV551 series digital output module supplied as new surplus, factory sealed when available. We do not rebrand or relabel third-party substitutes.
What does “P60/D5A00” mean?
“-P” means pulse-width / time-proportional output capability. “6” means status display with no explosion protection. “0” is the basic option. “/D5A00” is the KS cable interface adapter ATD5A-00.
Can I replace an ADV551-P50/D5A00 with this module?
Functionally yes for 24 VDC digital output, but the P60 adds status display. If your existing card is P50, PE0, PF0, or P63, confirm the suffix and interface before substitution.
What systems is it compatible with?
It is designed for Yokogawa CENTUM VP and CS 3000 DCS systems using ADV551-series digital output slots.
What warranty do you offer?
A 12-month warranty against manufacturing defects and DOA issues. Damage from incorrect wiring, overvoltage, backplane faults, or mismatched terminal interface is not covered.
