Product Core Brief
- Model: DSSR122 (48990001-NK)
- Brand: ABB
- Series: S800 I/O Advant Master DCS
- Core Function: Switches high voltage field loads via mechanical relay contacts for valve, alarm, and motor starter signaling.
- Product Type: 16-Channel Relay Output I/O Module
- Key Specs: 16 isolated relay contacts | 5 A max per channel | 250 V AC contact rating Condition: New Original (New Surplus)
Product Introduction
The ABB 48990001-NK is a mechanical relay output card engineered for S800 I/O DCS racks, designed to switch high-potential field equipment without solid-state limitation.Well, technically it matches the single-width rack footprint of DO910, yet the ABB 48990001-NK uses electromechanical relays with 2000 V isolation, far exceeding the low-voltage transistor outputs of digital card variants. Its relay mechanical lifespan hits 10 million switching cycles under nominal 3 A load.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Full Part Number | , 48990001-NK |
| Output Channel Count | 16 independent electromechanical relays |
| Contact Voltage Rating | Max 250 V AC, 125 V DC per channel |
| Continuous Contact Current | 5 A resistive load, 3 A inductive load |
| Dielectric Isolation | 2000 V AC between rack bus and field contacts |
| Mechanical Relay Lifespan | 10 million cycles at 3 A resistive load |
| Operating Temperature | 0 °C to 60 °C cabinet ambient |
| Storage Temperature | -40 °C to +85 °C non-operating |
| Backplane Communication | Profibus DP up to 12 Mbit/s baud rate |
| Form Factor | Single-width S800 I/O rack slot |
| Rack Supply Draw | 140 mA at 24 V DC backplane power |
| Terminal Wire Gauge Limit | 2.5 mm² solid copper conductors |
| Compatible Termination Units | TU810, TU812, TU830 series base units |
Quality Control Process
- Incoming Verification: Cross serial numbers against ABB S800 factory batch logs to reject counterfeit hardware. Visual scan checks for cracked relay housings, bent terminal pins, or discolored PCB traces (—minor factory mold marks do not trigger rejection).
- Live Functional Test: Mount the module to a calibrated S800 backplane, feed regulated 24 V rack supply, and run power-on self-test. Complete Profibus DP handshake with AC800M controller, then execute a 24-hour cyclic relay switching test with hourly temperature logging.
- Electrical Parameter Test: Use a Megger MIT300 at 500 V to measure isolation resistance; every relay group must register above 10 MΩ. Verify rack earth continuity via Fluke 115 multimeter across the chassis ground lug.
- Firmware Verification: Read onboard module firmware revision through Advant Engineering Workbench, log the value to unit trace sheets, and capture photos of Profibus termination DIP switches on the terminal header.
- Final QC & Packaging: Wipe terminal gold contacts with isopropyl alcohol, seal the unit inside anti-static shielding bag, and attach a dated QC Passed sticker with assigned test technician ID.
Replacement Pitfall Guide
- Firmware Mismatch: Older AC800M controllers running firmware v4.5 or older cannot register contact status data from newer ABB 48990001-NK firmware v2.5. Update controller runtime or source legacy module revisions.
- DIP Switch / Jumper Misconfiguration: Factory DIP defaults disable the 120 Ω bus termination resistor, but multi-slot I/O racks require this resistor on the final slot; missing it creates random relay chatter and comms loss.
- Terminal / Cable Incompatibility: Field contact pin layouts differ between ABB 48990001-NK and transistor-based DO910. Route shield drain wires directly to rack earth bars, not local device grounds.
- Power Supply Mismatch: Sum total backplane draw of all installed I/O cards and add 20% power headroom to the rack 24 V PSU. Undervoltage supply causes incomplete relay pull-in and intermittent load switching faults.
- ESD Damage: Static risk rises heavily when plant humidity sits below 30%. Place an anti-static mat under the rack during module swaps; bare PCB contact burns relay drive control circuits instantly.
Keep these in mind and you’ll cut 90% of rework time.
Compatibility Matrix & Benchmarks
Compatibility Matrix
- 48990001-NK → 48990001-NK : Direct — Exact pin, bus, and relay contact drop-in replacement
- 48990001-NK → DO910 : Needs Adaptation — Low voltage transistor outputs only, field wiring and load limits require full redesign
- 48990001-NK → DP840 : Incompatible — Pulse counter hardware lacks relay drive circuits
- 48990001-NK → DSPC174 : Incompatible — DSP processor board has no discrete output switching logic
Benchmarks
- I/O scan cycle: 0.5 ms (simulated load, all 16 relay channels cycled continuously)
- Comms throughput: 12 Mbit/s (Profibus DP fieldbus)
