Product Core Brief
- Model: DSSB140
- Brand: ABB
- Series: DSS DCS Rack Chassis Series
- Core Function: Hosts S800 I/O modules, distributes rack bus power, and integrates DSSA backup battery modules for Advant Master systems.
- Product Type: 12-Slot DCS Rack Base Chassis with Backplane
- Key Specs: 12 S800 module slots | 20 A backplane bus capacity | 230 VAC main input Condition: New Original (New Surplus)
Product Introduction
The ABB is a 12-slot metal chassis built to mount all standard S800 I/O cards for Advant Master DCS installations. It routes ModuleBus communication and shared rack power across all installed hardware.Well, technically it shares DIN rail footprint with smaller DSSB120 racks, yet the ABB supports double the I/O slot count and accepts full-size DSSA backup power units. Its backplane bus scan latency holds 0.3 ms under maximum 12-card populated load.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Model Identifier | |
| Total I/O Module Slots | 12 standard single-width S800 positions |
| Rated Backplane Bus Current | 20 A total combined module draw |
| Supported Auxiliary Units | DSSA150, DSSA165 battery backup modules |
| Main Input Supply | 230 V AC single phase industrial mains |
| Operating Ambient Temperature | -20 °C to +60 °C enclosed cabinet |
| Storage Temperature Range | -40 °C to +70 °C non-operating |
| Backplane Isolation Rating | 500 V AC between field bus and mains circuits |
| Chassis Construction | Cold rolled steel, powder coated IP20 rating |
| Internal Bus Protocol | ModuleBus, Advant Fieldbus 100 |
| Maximum Installed Depth | 165 mm full assembled chassis depth |
| Protective Earth Terminal | M6 threaded lug for cabinet ground bonding |
| Certifications | CE, UL, IEC 61131-2 compliant rack hardware |
Quality Control Process
- Incoming Verification: Cross-reference chassis serial numbers against ABB DSS factory batch manifests to reject counterfeit frames. Visual inspection checks for bent backplane pins, cracked mounting rails, or chipped chassis coating (—minor surface scuffs from factory packaging pass QA).
- Live Functional Test: Populate the empty backplane with reference I/O modules, supply regulated 230 V AC mains power, and run rack power-on self-test. Establish stable ModuleBus communication with an AC450 controller for a continuous 24-hour load cycle with thermal logging.
- Electrical Parameter Test: Use a Megger MIT300 set to 500 V to validate cross-circuit insulation; all bus traces must register above 10 MΩ. Confirm chassis ground continuity via Fluke 115 across the M6 earth lug.
- Firmware Verification: Read backplane bus controller firmware revision through Advant Engineering Workbench, log the version to unit trace paperwork, and photograph bus termination DIP switches mounted on the far-right slot header.
- Final QC & Packaging: Remove all test I/O cards, cap unused backplane slot headers with plastic dust plugs, wrap the chassis in anti-static foam, seal inside heavy-duty industrial packaging, and attach a dated QC Passed sticker with assigned technician ID.
Replacement Pitfall Guide
- Firmware Mismatch: Legacy AC410 controllers running runtime v3.6 or older fail to poll full slot counts from newer ABB backplane firmware v2.8. Upgrade controller software or source older rack chassis revisions.
- DIP Switch / Jumper Misconfiguration: Factory DIP defaults disable end-of-rack bus termination, but multi-chassis linked DCS systems require 120 Ω resistors on the last rack; missing this setting triggers recurring bus timeout faults.
- Terminal / Cable Incompatibility: Main power terminal block pinouts differ between ABB and compact DSSB120 racks. Run main earth cables directly to cabinet master ground bar instead of local chassis lugs only.
- Power Supply Mismatch: Sum peak current draw of all 12 populated slots and add 20% power headroom to the 230 VAC cabinet feed. Undervoltage mains input reduces ModuleBus speed and creates random I/O communication drops.
- ESD Damage: Static risk rises sharply at relative humidity below 30% in dry processing facilities. Place an anti-static mat under the empty chassis during card swaps; bare contact with backplane gold traces corrupts bus communication instantly.
Keep these in mind and you’ll cut 90% of rework time.
Compatibility Matrix & Benchmarks
Compatibility Matrix
- → : Direct — Full slot, backplane bus, and battery unit mounting drop-in replacement
- → DSSB120 : Needs Adaptation — Only 6 I/O slots, system I/O mapping requires full reconfiguration
- → DSPC174 : Incompatible — DSP processor module cannot function as a rack chassis assembly
- → DSSA165 : Incompatible — Backup battery module is an auxiliary add-on, not a rack replacement
Benchmarks
- Full rack bus scan cycle: 0.3 ms (simulated load, all 12 I/O slots active)
- Max sustained backplane throughput: 10 Mbit/s (ModuleBus internal rack communication)
