Author Archives: rsmodules

Honeywell CC-TAIM01 | FTE 16 Channel Low Level mV Thermocouple RTD Analog Input Module Experion PKS C300 – Field Service Notes

Component Snapshot At-a-Glance Model: CC-TAIM01 Alt. P/N: CC-PAIM01 (standard non-FTE low level MUX, backplane/IOTA pinout incompatible); CC-TAID01 (FTE high level 4-20mA AI, cannot read mV thermocouple signals) Product Series: Honeywell Experion PKS Series C FTE Fault Tolerant Ethernet I/O, matched to C300 FTE controllers Hardware Type: Rack-mount 16-channel low-level millivolt multiplexer IOM, hot-swap capable, mates…

Honeywell CC-PDOB01 | 32 Channel 24VDC Bussed Sourcing Digital Output Module Experion PKS C300 Series C – Field Service Notes

Component Snapshot At-a-Glance Model: CC-PDOB01, factory P/N 51405043-175 Alt. P/N: CC-TDOB01 (FTE backplane DO variant, IOTA/backplane incompatible); CC-PDOX01 (16-channel isolated DO, lower density) Product Series: Honeywell Experion PKS Series C standard non-FTE I/O, paired with C300 process controllers Hardware Type: Rack-mount 32-channel bussed sourcing digital output module, hot-swap capable, requires CC-TDOB01 simplex / CC-TDOB11 redundant…

Honeywell CC-TCNT01 | FTE C300 Controller IOTA Termination Base for CC-TCNT01 CPU Experion PKS Series C – Field Service Notes

Component Snapshot At-a-Glance Model: CC-TCNT01, factory P/N 51304592-100 Alt. P/N: CC-TCNT00 (non-FTE controller IOTA for CC-PCNT01, pinout/port layout incompatible); CC-TDILxx (I/O module IOTA, cannot substitute controller base) Product Series: Honeywell Experion PKS Series C FTE Fault Tolerant Ethernet control platform, matches C300 FTE controller CPU CC-TCNT01 Hardware Type: Full-width passive controller termination IOTA base, hot-swap…

Honeywell CC-PDIL01 | 32 Channel 24VDC Sink Digital Input Module for Experion PKS C300 Series C I/O – Field Service Notes

Component Snapshot At-a-Glance Model: CC-PDIL01, factory P/N 51405040-175 Alt. P/N: CC-TDIL01 (non-redundant IOTA base); CC-TDIL11 (redundant IOTA); CC-PDIH01 (120VAC high voltage DI, non-interchangeable) Product Series: Honeywell Experion PKS Series C standard non-FTE I/O, paired with C300 process controllers Hardware Type: Rack-mount 32-channel 24VDC sink digital input module, hot-swap capable, requires dedicated TDIL IOTA terminal base…
