Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product model | REXROTH VEP40.3CEN-256NN-MAD-128-NN-FW |
| Manufacturer | Bosch Rexroth |
| Product category | Industrial Control Module |
| Operating Voltage | 24 V DC |
| Output Current | 2 A |
| Operating Temperature Range | -20°C to +85°C |
| Response Time | < 1 ms |
| Mounting Configuration | DIN Rail Mount |
| Protection Rating | IP67 |
| Weight | 0.5 kg |
| Dimensions (W x H x D) | 120 mm x 70 mm x 50 mm |
| Certifications | CE, RoHS compliant |
REXROTH VEP40.3CEN-256NN-MAD-128-NN-FW
Product Introduction
The REXROTH VEP40.3CEN-256NN-MAD-128-NN-FW is a high-performance control valve designed for precision regulation in industrial automation systems. It is part of the IndraControl VEP40 series by Bosch Rexroth, known for its robustness and reliability. This control valve is ideal for applications requiring precise flow control, such as in hydraulic systems.
Core Advantages and Technical Highlights
High Precision and Reliability:
The REXROTH VEP40.3CEN-256NN-MAD-128-NN-FW offers high-precision control with an encoder resolution of 2560000 ppr, allowing for extremely precise position control with an accuracy of up to ±0.001°.
Robust Industrial Design:
The module features an IP67 protection rating, safeguarding it from dust and water ingress, making it suitable for harsh industrial conditions.
Versatile Applications:
The REXROTH VEP40.3CEN-256NN-MAD-128-NN-FW is suitable for a wide range of applications, including manufacturing, energy, material handling, and robotics.
Easy Integration:
The module supports a wide range of input voltages (24 V DC) and features multiple digital inputs and outputs, ensuring seamless integration with existing systems.
Advanced Safety Features:
The module includes integrated diagnostic functions, which help in early detection and resolution of issues, enhancing system reliability.
REXROTH VEP40.3CEN-256NN-MAD-128-NN-FW
Typical Application Scenarios
The REXROTH VEP40.3CEN-256NN-MAD-128-NN-FW is widely used in various industrial sectors:
Manufacturing: For precise control in assembly lines and machine tools.
Energy: For monitoring and control in power plants and substations.
Material Handling: For conveyor speed control in automotive assembly lines.
Food and Beverage Production: For controlling motion equipment on production lines.
Related Model Recommendations
REXROTH VEP40.3CEU-256NA-MAD-128-NN-FW: A similar model with additional PROFIBUS DP interface, suitable for more advanced control tasks.
REXROTH VEP40.4DBN-512NN-MAD-1G0-NN-FW: A model with higher power capacity, suitable for applications requiring higher current ratings.
Installation, Commissioning, and Maintenance Instructions
Installation Preparation:
Ensure the installation environment meets the specified temperature and humidity requirements. The module should be installed in a location with adequate ventilation to dissipate heat. Verify that the power supply voltage is within the specified range (24 V DC) to avoid damage to the module.
Maintenance Suggestions:
Regularly inspect the installation to ensure the module is securely mounted and all connections are tight. Monitor the operational status of the module to detect any signs of malfunction early. Conduct functional testing on the module at least once a year to ensure optimal performance.
Service and Guarantee Commitment
Bosch Rexroth provides comprehensive support for the REXROTH VEP40.3CEN-256NN-MAD-128-NN-FW, including a robust warranty that ensures product quality and reliability. The company offers extensive after-sales services such as technical support, repair services, and spare part supply. Bosch Rexroth’s global network of service centers ensures prompt assistance and expert guidance, demonstrating the company’s commitment to customer satisfaction and product excellence.
