Professional Product Description: GE IS200EDCFG1A
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product model | IS200EDCFG1A |
| Manufacturer | General Electric (GE) |
| Product category | Excitation System Configuration & Backup Module (Mark VIe EX2100e) |
| Storage capacity | 32 GB industrial-grade flash; microSD slot (up to 64 GB) |
| Supported data types | Excitation controller parameters, I/O configurations, protection settings, excitation curves |
| Communication interfaces | 1 x 10/100 Ethernet; 1 x USB 2.0; 1 x microSD; Mark VIe backplane |
| Programming/configuration | ToolboxST compatible; supports offline configuration management |
| Security features | Password protection; firmware integrity verification |
| Operating temperature | -40°C to +85°C |
| Power requirements | 24 VDC (±10%); 0.3 A max |
| Safety & EMC compliance | IEC 61010-1; EN 61326-1; UL 61010-1 |
| MTBF | 2,800,000 hours (at 40°C) |
IS200EDCFG1A
Product Introduction
The IS200EDCFG1A is a specialized configuration and backup module developed by GE for the Mark VIe EX2100e excitation control system. This module serves as the central repository for all critical excitation system parameters, including controller settings, protection thresholds, and operational curves.
Unlike general-purpose configuration modules, the IS200EDCFG1A is specifically designed to manage the unique requirements of generator excitation systems. It provides secure storage for excitation-specific parameters that define how the system regulates generator voltage, controls reactive power, and responds to grid disturbances.
The IS200EDCFG1A plays a vital role in ensuring excitation system reliability and consistency across multiple generating units. It enables rapid system recovery after failures, facilitates firmware updates, and maintains version control for all configuration parameters. Its rugged design ensures reliable operation in the harsh environments typical of power generation facilities.
Core Advantages and Technical Highlights
Excitation-Specific Configuration Management: The IS200EDCFG1A is purpose-built to handle the unique parameter sets required for generator excitation control. It stores excitation curves, PID gains, limit settings, and protection parameters that are critical to maintaining stable generator operation.
Secure Data Storage: With password protection and firmware integrity verification, the IS200EDCFG1A ensures that critical excitation parameters remain secure from unauthorized modification. This security is essential for maintaining system stability and complying with regulatory requirements.
Rapid System Recovery: The module enables quick restoration of excitation system parameters after a controller replacement or system upgrade. This capability minimizes downtime during maintenance or fault recovery scenarios.
Simplified Version Control: The IS200EDCFG1A maintains configuration version history, allowing operators to track changes over time and revert to previous settings if necessary. This feature is particularly valuable for troubleshooting performance issues or maintaining regulatory compliance.
Flexible Access Options: Supporting both local (USB) and network (Ethernet) access, the IS200EDCFG1A provides flexibility in how configuration changes are implemented. This allows for both local maintenance and remote system management.
Typical Application Scenarios
In large fossil-fuel power plants, the IS200EDCFG1A serves as the configuration hub for multiple generator excitation systems. It maintains standardized parameter sets across identical units, ensuring consistent performance and simplifying operator training.
For utilities operating mixed fleets of generators, the IS200EDCFG1A allows for unit-specific configuration profiles that can be quickly loaded when maintenance is performed or when units are repurposed. This capability reduces the risk of configuration errors during these transitions.
In renewable energy applications such as wind farms or solar power plants with synchronous generators, the IS200EDCFG1A manages the unique excitation requirements of these variable-output systems. It stores configuration parameters that optimize power factor control and grid support functions.
The IS200EDCFG1A is also invaluable during system upgrades or retrofits, where it preserves existing operational parameters while implementing new control strategies. This ensures a smooth transition with minimal disruption to plant operations.
Related Model Recommendations
IS200EAUXH1A – Excitation auxiliary I/O interface board whose configuration parameters are managed by the IS200EDCFG1A.
IS200ECTBG2A – Thyristor gate driver module that receives its operating parameters from the IS200EDCFG1A.
IS200ESELH1A – Excitation selector module whose operating mode parameters are stored in the IS200EDCFG1A.
IS200DSPXH2C – Digital signal processor whose excitation control algorithms are configured through the IS200EDCFG1A.
IS200IVFBG1A – Voltage/frequency feedback module whose measurement parameters are set via the IS200EDCFG1A.
IS200EHBQG2A – Backplane module that provides power and communication connectivity for the IS200EDCFG1A.
IS200EACFG2A – General system configuration module that can complement the IS200EDCFG1A in integrated turbine and excitation control systems.
IC698CPE030 – Mark VIe main controller that coordinates with the IS200EDCFG1A in comprehensive power plant control architectures.
IS200EDCFG1A
Installation, Commissioning and Maintenance Instructions
Installation preparation: Before installing the IS200EDCFG1A, ensure the Mark VIe backplane is powered down. Verify that the operating environment meets the module’s specifications (-40°C to +85°C). Use ESD-protective equipment during handling. Confirm that the backplane slot is compatible with configuration modules and that the 24 VDC power supply meets the required specifications (±10% tolerance). Prepare network connections according to the system design.
Commissioning: After physical installation, configure the IS200EDCFG1A using GE’s ToolboxST software. Establish baseline excitation parameters, including voltage regulation settings, reactive power controls, and protection thresholds. Perform an initial full system backup to establish a reference configuration. Verify communication with all excitation system components.
Maintenance suggestions: Implement a regular backup schedule for the IS200EDCFG1A and verify backup integrity periodically. Monitor module health through the system HMI and review error logs monthly. Keep firmware updated to the latest version recommended by GE. Before making configuration changes, create a backup and document the modifications. In case of module failure, use the most recent backup to restore configuration to a replacement IS200EDCFG1A module.
Service and Guarantee Commitment
The IS200EDCFG1A comes with a 2-year standard warranty from GE, covering defects in materials and workmanship. GE’s global service network provides comprehensive support for the IS200EDCFG1A, including technical assistance, repair services, and spare parts availability.
GE offers 24/7 technical support for the IS200EDCFG1A, with specialists available to assist with installation, configuration, and troubleshooting. Customers have access to GE’s extensive library of technical documentation, including user manuals, application notes, and best practices guides for excitation system configuration management.
For mission-critical applications, GE provides extended warranty options and preventive maintenance services to ensure the IS200EDCFG1A operates at peak performance throughout its service life. GE’s commitment to quality ensures that the IS200EDCFG1A will provide reliable configuration management in even the most demanding power generation environments.
