Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product model | ICS TRIPLEX T8100 |
| Manufacturer | ICS TRIPLEX (now part of Rockwell Automation) |
| Product category | Trusted TMR Controller Chassis |
| Operating Voltage | 20 V DC to 32 V DC |
| Operating Temperature Range | -20°C to +60°C |
| Storage Temperature Range | -25°C to +70°C |
| Humidity Range | 10% to 95% RH (non-condensing) |
| Dimensions | 268 mm (H) × 483 mm (W) × 312 mm (D) |
| Weight | 5 kg |
| Certifications | IEC 61508 SIL 3, CE, UL, CSA |
| Communication Protocols | Ethernet, RS-232, RS-485 |
| Supported Modules | Up to two Trusted TMR Processor modules, up to eight Trusted TMR Interface modules |
| Cooling | Convection cooling for quiet operation |
| Mounting | 19″ rack-mount |
ICS TRIPLEX T8100
Product Introduction
The ICS TRIPLEX T8100 is a high-performance, fault-tolerant Trusted TMR (Triple Modular Redundancy) Controller Chassis designed for critical industrial automation and process control applications. It provides a robust platform for ensuring high availability and reliability in demanding environments.
Core Advantages and Technical Highlights
Triple Modular Redundancy (TMR)
The ICS TRIPLEX T8100 employs a TMR architecture, featuring three independent voting channels that execute the same program in parallel. This design ensures continuous operation even if one channel fails, enhancing system reliability.
High Reliability and Fault Tolerance
The chassis supports comprehensive diagnostics and self-testing capabilities, allowing for rapid fault identification and fail-safe operation. It continuously monitors itself for faults and can drive the system to a safe state if a failure is detected.
Scalable and Flexible Design
The ICS TRIPLEX T8100 supports a wide range of Trusted I/O and interface modules, making it highly versatile for various applications. It can accommodate up to two Trusted TMR Processor modules and up to eight Trusted TMR Interface modules.
Advanced Safety Features
Certified to IEC 61508 SIL 3 and EN 50128 TUV Rheinland safety standards, the T8100 ensures secure and reliable performance in safety-critical applications.
ICS TRIPLEX T8100
Typical Application Scenarios
The ICS TRIPLEX T8100 is widely used in industries where high reliability and safety are paramount, such as:
-
Oil & Gas: Monitoring and controlling critical processes in refineries and drilling operations.
-
Power Generation: Real-time monitoring and control of turbines and generating units.
-
Chemical Processing: Process control in reactors, mixers, and separation units.
-
Water Treatment and Utilities: Ensuring reliable communications between distributed sensors, controllers, and central monitoring systems.
