Description
Honeywell SPS5710-2-LF (51198685-100) Pressure Sensor
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | Honeywell SPS5710-2-LF (51198685-100) |
| Manufacturer | Honeywell |
| Product Category | Industrial Pressure Sensor |
| Pressure Type | Gauge/Sealed Gauge |
| Pressure Range | 0-100 psi (custom ranges available) |
| Output Signal | 0.5-4.5V ratiometric (3-wire), 4-20mA (2-wire) |
| Accuracy | ±0.25% FS (typical), ±0.5% FS (max) |
| Long-Term Stability | ±0.2% FS/year |
| Operating Temp. | -40°C to +125°C |
| Media Compatibility | Non-corrosive gases & liquids (316L SS wetted parts) |
| Power Supply | 5V DC ±10% (ratiometric), 8-30V DC (4-20mA) |
| Response Time | <1ms (10-90% step change) |
| Electrical Connection | Integrated cable (IP67) or DIN 43650 connector |
| Process Connection | 1/4″ NPT male (G1/4 optional) |
| Certifications | CE, RoHS, REACH |
Honeywell SPS5710-2-LF 51198685-100
Product Introduction
The Honeywell SPS5710-2-LF (51198685-100) is a high-performance pressure sensor designed for demanding industrial applications requiring precise pressure monitoring. Built with 316L stainless steel wetted parts, it delivers reliable measurements in harsh environments, including hydraulic systems, industrial automation, and mobile equipment.
Featuring ratiometric (0.5-4.5V) and 4-20mA output options, this sensor provides flexibility for integration with PLCs, data loggers, and control systems. Its ±0.25% FS accuracy and <1ms response time make it ideal for dynamic pressure monitoring in real-time control applications.
Core Advantages & Technical Highlights
1. High Accuracy & Stability
±0.25% FS accuracy ensures precise pressure readings.
±0.2% FS/year long-term stability minimizes drift over time.
2. Rugged Industrial Design
316L stainless steel construction resists corrosion in harsh media.
-40°C to +125°C operating range for extreme environments.
IP67-rated cable/connector options for dust/water resistance.
3. Fast Dynamic Response
<1ms response time captures rapid pressure changes.
10kHz resonant frequency for vibration-resistant performance.
4. Flexible Output Options
0.5-4.5V ratiometric (3-wire) for low-power applications.
4-20mA (2-wire) loop-powered for long-distance signal transmission.
5. Easy Integration
1/4″ NPT or G1/4 process connection for standard installations.
DIN 43650 connector option for quick-disconnect applications.
Honeywell SPS5710-2-LF 51198685-100
Typical Application Scenarios
Hydraulic/Pneumatic Systems – Real-time pressure monitoring in industrial machinery.
Mobile Equipment – Construction/agricultural vehicle fluid pressure sensing.
Process Automation – Pump/compressor control in chemical plants.
HVAC/R Systems – Refrigerant pressure monitoring.
Test & Measurement – Lab equipment and data acquisition systems.
Related Model Recommendations
Honeywell SPS5710-1-LF – Lower range (0-30 psi).
Honeywell SPS5700-2-LF – Absolute pressure version.
Honeywell ASDX Series – Board-mount pressure sensors.
Honeywell TSC Series – High-temperature pressure transducers.
Honeywell PX3 Series – Digital output pressure sensors.
Installation & Commissioning
Wiring & Setup
Ratiometric (0.5-4.5V):
Red: +5V DC
Black: GND
White: Signal
4-20mA (2-wire):
Connect in series with power (8-30V DC) and load.
Calibration
Factory-calibrated; field recalibration possible via shunt resistor adjustment.
Maintenance
Inspect seals annually for leaks in high-vibration environments.
Clean process port if media contains particulates.
Service & Warranty
24-month warranty (defects in materials/workmanship).
Technical support via Honeywell’s global service network.
Custom calibration available upon request.
