  • Model: IS420ESWBH3A (correct full part number)
  • Alt. P/N: ESWBH3A
  • Product Series: Speedtronic Mark VIe / Mark VIeS
  • Hardware Type: Unmanaged industrial IONet Ethernet switch
  • Key Feature: 16× 10/100Base-TX copper ports (copper-only, no fiber)
  • Primary Field Use: High-density local I/O networking for large Mark VIe turbine control systems
Get a Quote
In Stock
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide. Brand:
The listed price is not final; the actual selling price is negotiable based on current market conditions.

Description

Hard-Numbers: Technical Specifications

  • Standards: IEEE 802.3, 802.3u, 802.3x
  • Copper Ports: 16× RJ45, 10/100 Mbps, auto-negotiation, HP-MDIX
  • Fiber Ports: 0
  • Buffer Memory: 256 KB minimum
  • MAC Address Table: 4K entries
  • Operating Temperature: -40°C to +70°C
  • Power Input: 24–28 VDC (dual redundant, diode-OR’d)
  • Power Draw: 8 W typical, 12 W max
  • Isolation: 1500 Vrms port-to-backplane
  • Mounting: DIN-rail (BVP1/BVP4 clips) or panel-mount
  • Dimensions: 138 × 86 × 56 mm
  • Weight: 0.9 kg (2 lbs)
  • Environmental: G3 conformal coating, Class 1 Div 2 / Zone 2 hazardous location rated

The Real-World Problem It Solves

Large turbine control racks need more ports than 8-port switches provide, forcing daisy-chaining and added latency. This 16-port unit consolidates I/O connections into one module and cuts network complexity.

Where you’ll typically find it:

  • Large Mark VIe control cabinets in gas/steam turbine power plants
  • High-density I/O racks in refinery cogeneration facilities
  • Offshore platform turbine control systems with extensive local I/O

Bottom line: It delivers deterministic, low-latency switching for high-port-count industrial control networks.



Hardware Architecture & Under-the-Hood Logic

Unmanaged layer 2 switch with autonomous switching logic; no CPU or firmware required. Convection-cooled, no fans. Operates strictly on hardware-based packet forwarding.

  1. Receives Ethernet frames from controllers, I/O modules, and HMIs.
  2. Forwards packets via hardware MAC address lookup with <1 ms latency.
  3. Applies 802.3x flow control to prevent buffer overflow during traffic bursts.
  4. Transmits data to target nodes with full electrical isolation.
  5. Triggers bi-color LEDs (green/yellow) for link speed, activity, and duplex status.



Field Service Pitfalls: What Rookies Get Wrong

Redundant Power MiswiringRookies connect both power inputs to the same 24 VDC source. Eliminates redundancy; entire switch dies on single supply failure.

  • Field Rule: Feed TB1 and TB2 from separate 24 VDC sources; diode-OR design ensures true redundancy.

Unused Port Broadcast StormsLeaving unused 16 ports active creates uncontrolled broadcast traffic. Latency spikes lock IONet cycles and cause turbine trip faults.

  • Quick Fix: Disable all unused ports via DIP switch or Toolbox; enable storm filtering on active ports.

DIN-Rail Vibration FailureImproper mounting (perpendicular without BVP4 clips) causes chassis resonance. Vibration cracks solder joints and induces intermittent port faults.

  • Field Rule: Use BVP1 clips for parallel DIN-rail mounting; BVP4 clips only for perpendicular orientation.

Commercial Availability & Pricing Note

Please note: The listed price is for reference only and is not binding. Final pricing and terms are subject to negotiation based on current market conditions and availability.
