Description
Product Core Brief
- Model: 5X00301G01
- Brand: Emerson (Westinghouse legacy)
- Series: Ovation DCS
- Core Function: 16‑channel relay output electronic module (EMOD) for on/off field device control
- Type: Digital output relay module (requires PMOD)
- Key Specs: 16 channels, 2 A contact rating, 24 V DC backplane power
- Condition: New Original (New Surplus)
- Stock: In stock (9 units)
- Lead Time: 1–3 days
- Warranty: 18‑month manufacturer
5X00301G01
Key Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Emerson |
| Model | 5X00301G01 |
| Series | Ovation Distributed Control System (DCS) |
| Product Type | Relay Output Electronic Module (EMOD) |
| Channel Count | 16 (dry contact outputs) |
| Contact Rating | 24–125 VDC / 120–240 VAC, 2 A max (resistive) |
| Power Supply | 24 V DC ±10% (backplane‑fed), 4 W max |
| Operating Temperature | –20°C to +70°C |
| Humidity | 5%–95% RH (non‑condensing) |
| Dimensions | 55.7 × 180.1 × 58.0 mm |
| Weight | 0.63 kg |
| Certifications | CE, UL, IEC 61131 |
| Origin | USA |
| Compatibility | Pairs with 5X00327G01 personality module (PMOD) |
Product Introduction
The Emerson 5X00301G01 is a 16‑channel relay output electronic module built for the Ovation DCS, deployed in power generation, petrochemical, and water treatment plants. It converts digital control signals into dry‑contact relay outputs to drive valves, motors, and solenoids.
Engineered for reliable on/off control, the 5X00301G01 supports 2 A resistive loads and operates across –20°C to +70°C. It requires a matching 5X00327G01 personality module for full functionality, ensuring seamless integration with Ovation I/O bases.
5X00301G01
