Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product Model | XVC770BE101 3BHE021083R0101 |
| Manufacturer | ABB |
| Product Category | Industrial Control Module |
| Input Voltage | 24V DC |
| Output Frequency | Up to 10 kHz |
| Communication Protocols | Modbus TCP/IP, EtherCAT |
| Power Consumption | ≤2W |
| Operating Temperature Range | -20°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Range | 0% to 95% RH non-condensing |
| Dimensions (L x W x H) | 115 mm x 82 mm x 26 mm |
| Weight | 180 g |
| Certifications | CE, RoHS |
XVC770BE101 3BHE021083R0101
Product Introduction
The ABB XVC770BE101 3BHE021083R0101 is a high-performance industrial control module designed for demanding industrial automation environments. It is part of ABB’s System 800xA control system family, known for its high performance, reliability, and scalability. This module is engineered to meet the demands of heavy-duty industrial environments, ensuring stable performance under various conditions.
Core Advantages and Technical Highlights
Robust Design: The XVC770BE101 3BHE021083R0101 features a compact and durable design, with dimensions of 115 mm x 82 mm x 26 mm and a weight of 180 g. It operates reliably within a wide temperature range of -20°C to +60°C.
Advanced Communication Capabilities: The module supports multiple communication protocols, including Modbus TCP/IP and EtherCAT, enabling seamless integration with various control systems. This versatility ensures compatibility with both legacy and modern industrial networks.
Energy Efficiency: With a power consumption of only 2W, the XVC770BE101 3BHE021083R0101 is highly energy-efficient, reducing operational costs.
Wide Operating Conditions: The module operates reliably within a temperature range of -20°C to +60°C and can be stored between -40°C and +85°C. It also features an IP20 protection rating, ensuring resistance to dust and water ingress.
High Reliability: The XVC770BE101 3BHE021083R0101 is designed with high-grade materials for durability and long-term reliability, even under extreme conditions.
XVC770BE101 3BHE021083R0101
Typical Application Scenarios
The ABB XVC770BE101 3BHE021083R0101 is widely used in various industrial sectors, including:
-
Manufacturing Automation: For precise control of robotic arms and assembly line machinery.
-
Energy Management: For monitoring and controlling critical processes in power plants.
-
Process Control: In petrochemical plants and food processing facilities, ensuring consistent quality and efficiency.
Related Model Recommendations
-
ACS880-04: A modular industrial drive for high-power motors.
-
CM-PFS: A power supply module for redundant configurations.
-
SA811: A safety relay for emergency stop circuits.
Installation, Commissioning, and Maintenance Instructions
Installation Preparation: Ensure the installation location meets the specified temperature and humidity requirements. Mount the module securely on a DIN rail or panel using the provided hardware. Use shielded cables for connections to minimize electrical interference.
Maintenance Suggestions: Perform regular visual inspections to check for dust accumulation, wear, or damage. Clean ventilation openings to ensure proper airflow and prevent overheating. Monitor diagnostic indicators for any abnormal conditions or warning messages.
Service and Guarantee Commitment
The ABB XVC770BE101 3BHE021083R0101 is backed by ABB’s comprehensive support and quality assurance. The module comes with a warranty that ensures protection against manufacturing defects. ABB’s global technical support network offers 24/7 assistance with guaranteed response times, ensuring minimal downtime and maximum efficiency.
