Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product Model | EI813F |
| Manufacturer | ABB |
| Product Category | Ethernet Communication Module |
| Series | ABB EI813 Series |
| Interface Type | 10BaseT Ethernet |
| Data Rate | 10 Mbps |
| Operating Voltage | 24V DC |
| Operating Temperature Range | -20°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Dimensions (L×W×H) | 125 mm × 28 mm × 155 mm |
| Weight | 0.15 kg |
| Certifications | CE, UL, RoHS |
| Communication Protocols | TCP/IP, UDP/IP, Modbus TCP, EtherNet/IP |
| Protection Level | IP20 |
ABB EI813F
Product Introduction
The ABB EI813F is a high-performance Ethernet communication module designed for industrial automation systems. It is part of the ABB EI813 series and is known for its robustness, reliability, and efficiency in harsh industrial environments.
Core Advantages and Technical Highlights
High-Speed Communication: The EI813F supports IEEE 802.3 standard, providing fast data transmission rates up to 10 Mbps, ensuring efficient real-time communication.
Direct Memory Access: The module features direct memory access, reducing CPU overhead and enhancing system performance.
Battery Backup (Optional): The EI813F can be equipped with a battery backup to ensure data persistence during power failures, enhancing system reliability.
Easy Integration: The module is designed for easy integration with ABB PLCs and other compatible devices, simplifying installation and maintenance.
State Indicators: The module includes LED indicators for monitoring communication status, facilitating quick troubleshooting.
High Compatibility: The EI813F supports multiple communication protocols, including Modbus TCP and EtherNet/IP, ensuring seamless integration with various industrial systems.
ABB EI813F
Typical Application Scenarios
The ABB EI813F is widely used in various industrial sectors, including:
-
Industrial Automation: For data communication and control in manufacturing plants.
-
Power Systems: For monitoring and controlling power generation processes.
-
Building Automation: For managing building facilities such as lighting and HVAC systems.
-
Energy Management: For controlling and monitoring energy equipment to improve efficiency.
Related Model Recommendations
-
ABB 70BV05A-ES: Known for its robust I/O capabilities.
-
ABB 70EA2a-ES: A reliable choice for general control tasks.
-
ABB 70EA01B-ES: Ideal for communication-intensive applications.
-
ABB 70EB0lb-E: Designed for motion control.
Installation, Commissioning, and Maintenance Instructions
Installation Preparation: Ensure the installation environment is clean and free of interference. Prepare the necessary tools and follow the installation manual carefully.
Maintenance Suggestions: Regularly inspect the module for physical damage, monitor output voltages using a multimeter, and check for abnormal heat generation or noises. Clean the module’s surface periodically to prevent dust accumulation, which can affect heat dissipation.
Service and Guarantee Commitment
The ABB EI813F comes with a comprehensive warranty, ensuring customer satisfaction and peace of mind. ABB provides technical support and service to assist with installation, troubleshooting, and maintenance.
