Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product model | ABB CI858K01 3BSE018135R1 |
| Manufacturer | ABB |
| Product category | Communication Interface Module |
| Communication Protocol | DriveBus, PROFIBUS DP, Modbus RTU, Ethernet/IP, Modbus TCP |
| Data Transfer Rate | Up to 8 Mbit/s |
| Operating Voltage | 24V DC (18-56V DC range mentioned in some documents) |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Protection Rating | IP20 |
| Dimensions (W x H x D) | 59 mm x 185 mm x 127.5 mm |
| Weight | 0.55 kg |
| Installation Method | DIN rail installation |
| Redundancy Support | Yes (line redundancy) |
| Hot Swappable | Yes |
| Channels | 1 DriveBus interface, supports up to 24 ABB drives |
CI858K01 3BSE018135R1
Product Introduction
The ABB CI858K01 3BSE018135R1 is a high-performance DriveBus interface module designed for industrial automation systems. It is part of the ABB AC 800M series and is used to facilitate seamless communication between control systems and field devices. The CI858K01 supports multiple communication protocols, including DriveBus, PROFIBUS DP, Modbus RTU, Ethernet/IP, and Modbus TCP, ensuring compatibility with a wide range of industrial automation systems.
Core Advantages and Technical Highlights
Advanced Communication Capabilities: The CI858K01 supports multiple communication protocols, making it highly versatile for various industrial applications. It features high-speed data transfer rates up to 8 Mbit/s, ensuring fast and reliable communication.
Robust Design: Built for industrial environments, the CI858K01 operates efficiently within a wide temperature range of -40°C to +85°C and offers IP20 protection. It is designed with high-quality materials to withstand harsh conditions, ensuring long-term performance and minimizing maintenance requirements.
User-Friendly Configuration: The CI858K01 features built-in diagnostic tools and a user-friendly interface, simplifying maintenance and troubleshooting. It also supports various programming languages, including ladder logic and structured text.
Compact Size: With dimensions of 59 mm x 185 mm x 127.5 mm and a weight of 0.55 kg, the CI858K01 is compact and easy to integrate into existing systems.
CI858K01 3BSE018135R1
Typical Application Scenarios
The ABB CI858K01 3BSE018135R1 is widely used in various industrial sectors:
-
Manufacturing Plants: For real-time control and monitoring of production lines.
-
Power Generation Facilities: To monitor and control power plants and substations.
-
Process Control: In chemical, oil, and gas industries for process monitoring and regulation.
-
Water Treatment Plants: For controlling pumps and valves in water treatment processes.
-
Building Automation: For lighting, HVAC systems, and other automation equipment in large buildings.
Related Model Recommendations
-
ABB AC800M: A powerful PLC controller that integrates seamlessly with the CI858K01 for advanced automation control.
-
ABB AI810: An analog input module for precise data acquisition, suitable for monitoring drive systems.
-
ABB DI810: A digital input module that can be used alongside the CI858K01 to provide a complete I/O solution.
Installation, Commissioning and Maintenance Instructions
Installation Preparation: Ensure the environment meets the specified temperature and humidity requirements (-40°C to +85°C, 5% to 95% RH non-condensing). Use shielded cables and proper grounding to minimize electromagnetic interference. Follow ABB’s guidelines for DIN rail mounting, ensuring proper ventilation and protection from dust.
Maintenance Suggestions: Regularly inspect connections for wear and clean the module with a static-free cloth to ensure optimal heat dissipation. Use ABB’s dedicated software for module configuration and firmware updates. Follow ABB’s guidelines for handling sensitive components, including anti-static measures during maintenance.
Service and Guarantee Commitment
ABB stands behind the quality and reliability of the CI858K01 3BSE018135R1, offering a comprehensive warranty that covers manufacturing defects and performance issues for a specified period. Our dedicated after-sales support team is available to assist with technical inquiries and provide prompt solutions to ensure minimal disruption to your operations.
