Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product model | ABB AO02 |
| Manufacturer | ABB |
| Product category | Analog Output Module |
| Input Channels | 8 digital inputs |
| Output Channels | 16 analog outputs |
| Signal Types | 4-20 mA, 1-5 VDC |
| Communication Protocol | Modbus TCP/IP, RS-485 |
| Operating Voltage | 24V DC |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Protection Rating | IP20 |
| Dimensions | 120 mm (W) x 90 mm (H) x 65 mm (D) |
| Weight | 0.5 kg |
ABB AO02
Product Introduction
The ABB AO02 is a high-performance analog output module designed for industrial automation applications. It provides precise control and reliable performance, making it ideal for various industrial environments. This module features 16 analog output channels that can be independently configured for 4-20 mA or 1-5 VDC signals, ensuring flexibility and adaptability to different control requirements. The AO02 supports HART protocol, enhancing its compatibility with a wide range of field devices.
Core Advantages and Technical Highlights
High Precision and Reliability: The ABB AO02 offers high-precision analog output with a 12-bit resolution, ensuring accurate signal transmission. Its robust design and high reliability make it suitable for critical industrial applications.
Advanced Communication: Supporting Modbus TCP/IP and RS-485 communication protocols, the AO02 can seamlessly integrate with existing automation systems, facilitating reliable data transfer and connectivity.
Robust Design: The module is designed to operate reliably within a wide temperature range of -20°C to +60°C and offers IP20 protection against dust and non-condensing moisture.
Easy Integration and Configuration: The AO02 integrates seamlessly with ABB’s Symphony Plus system and other industrial control systems. It features a compact form factor, making it easy to install in space-constrained environments.
Extended Diagnostics: The module includes advanced diagnostic features, such as short-circuit protection and open-loop detection, enhancing system maintenance and troubleshooting.
ABB AO02
Typical Application Scenarios
The ABB AO02 is widely used in industries where precise control and monitoring are essential. In manufacturing plants, it controls actuators and valves, ensuring efficient process control. In power generation facilities, the AO02 monitors and controls equipment, optimizing performance and reliability. It is also used in water treatment plants to control pumps and valves, ensuring optimal water management.
Related Model Recommendations
-
ABB AC800M: A powerful PLC controller that integrates seamlessly with the ABB AO02 for advanced automation control.
-
ABB AI810: A complementary analog input module for precise data acquisition.
-
ABB DI810: A digital input module that can be used alongside the ABB AO02 to provide a complete I/O solution.
-
ABB AC500: A versatile PLC platform that can be used in conjunction with the ABB AO02 for comprehensive control systems.
Installation, Commissioning and Maintenance Instructions
Installation Preparation: Before installing the ABB AO02, ensure the environment meets the specified temperature and humidity requirements (-20°C to +60°C, 5% to 95% RH non-condensing). Use shielded cables and proper grounding to minimize electromagnetic interference. Follow ABB’s guidelines for DIN rail mounting, ensuring proper ventilation and protection from dust.
Maintenance Suggestions: Regularly inspect connections for wear and clean the module with a static-free cloth to ensure optimal heat dissipation. Use ABB’s dedicated software for module configuration and firmware updates. Follow ABB’s guidelines for handling sensitive components, including anti-static measures during maintenance.
Service and Guarantee Commitment
ABB stands behind the quality and reliability of the ABB AO02, offering a comprehensive warranty that covers manufacturing defects and performance issues for a specified period. Our dedicated after-sales support team is available to assist with technical inquiries and provide prompt solutions to ensure minimal disruption to your operations. We also offer extensive training and technical support services to help customers fully leverage the capabilities of the module, ensuring optimal performance and efficiency in their industrial applications.
