Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | ABB 3BHB009884R5211 |
| Manufacturer | ABB |
| Product Category | Control Module for AC 800M Controller |
| Input Voltage | 24V DC (±10%) |
| Power Consumption | 8W typical |
| Operating Temp | -25°C to +60°C |
| Communication | PROFIBUS DP, Modbus RTU |
| Memory Capacity | 16MB Flash, 8MB RAM |
| I/O Capacity | Supports up to 1024 I/O points |
| Mounting | DIN Rail (35mm) |
| Dimensions | 110 × 75 × 65 mm |
| Weight | 450g |
| Certifications | CE, UL, IEC 61131-2 |
ABB 3BHB009884R5211
Product Introduction
The ABB 3BHB009884R5211 is a high-performance control module designed for ABB’s AC 800M programmable automation controller series. This advanced module serves as the processing core for industrial automation systems, delivering reliable control for complex manufacturing processes and critical infrastructure applications.
As part of ABB’s Industrial Automation portfolio, the ABB 3BHB009884R5211 combines robust hardware with sophisticated control algorithms. Its modular design allows seamless integration with ABB’s extensive I/O systems and third-party devices through standard fieldbus protocols. The module is particularly valued in industries requiring precise process control and high availability.
Core Advantages and Technical Highlights
High-Speed Processing:
The ABB 3BHB009884R5211 features a powerful 32-bit RISC processor capable of executing control algorithms with scan times as fast as 1ms, ensuring responsive system performance.
Flexible Connectivity:
With dual PROFIBUS DP ports and Modbus RTU support, the module easily interfaces with drives, instruments, and other field devices from multiple vendors.
Robust Design:
Engineered for industrial environments, the module operates reliably across a wide temperature range and withstands vibration up to 1g (9.8 m/s²).
Advanced Diagnostics:
Comprehensive self-diagnostics and status monitoring capabilities enable predictive maintenance and quick troubleshooting.
Scalable Architecture:
The module’s design supports incremental system expansion, allowing users to start with basic configurations and add functionality as needed.
ABB 3BHB009884R5211
Typical Application Scenarios
Chemical Processing:
Precise batch control and recipe management in continuous production environments.
Power Generation:
Turbine control and balance-of-plant automation in thermal power stations.
Oil & Gas:
Safety instrumented systems for offshore platforms and pipeline operations.
Water Treatment:
Plant-wide automation for large-scale filtration and distribution systems.
Pharmaceuticals:
GMP-compliant process control in sterile manufacturing environments.
Related Model Recommendations
ABB 3BHB005243R0001 – Base unit for AC 800M controller
ABB 3BSE018105R1 – Power supply module
ABB 3BSE008514R1 – PROFIBUS communication interface
ABB 3BSE003127R1 – Ethernet communication module
ABB 3BSE008516R1 – Redundancy module
ABB 3BSE030220R1 – Digital input module
ABB 3BSE008517R1 – Analog output module
Installation, Commissioning and Maintenance
Installation Guidelines:
Mount the ABB 3BHB009884R5211 on a standard 35mm DIN rail in a well-ventilated control cabinet. Maintain minimum clearance of 50mm above and below the module for proper airflow. Use shielded cables for all communication connections.
Commissioning:
Configure the module using ABB’s Automation Builder engineering tool. The software provides intuitive wizards for parameter setting and I/O mapping. Verify all fieldbus connections before powering up the system.
Maintenance:
Regularly check the module’s status LEDs and clean ventilation openings. Update firmware during planned maintenance windows using ABB’s maintenance tools.
Service and Guarantee Commitment
ABB provides a standard 36-month warranty for the 3BHB009884R5211 module. Comprehensive support services include:
24/7 technical assistance through ABB’s global support network
On-site commissioning and troubleshooting services
Firmware updates and security patches
Repair and exchange programs
Training courses for operations and maintenance personnel
