Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | YPC104B YT204001-BT |
| Manufacturer | ABB |
| Product Category | Compact HMI Panel (CP600 Series) |
| Display Size | 10.4″ TFT LCD |
| Resolution | 800 × 600 (SVGA) |
| Touch Technology | Analog Resistive (IP65-rated front) |
| Processor | ARM Cortex-A9 1.0 GHz |
| Memory | 512 MB RAM / 2 GB Flash |
| Communication Ports | 2× Ethernet, 2× USB 2.0, RS-232/485, Bluetooth 4.0 |
| Operating System | Linux RTOS |
| Power Supply | 24 VDC (±15%) |
| Operating Temperature | 0°C to +55°C |
| Certifications | CE, UL, cULus, IEC 62443-4-1 |
YPC104B YT204001-BT
Product Introduction
The ABB YPC104B YT204001-BT is a ruggedized compact Human-Machine Interface (HMI) panel from ABB’s CP600 Series, engineered for machine-level control visualization. Designed with integrated Bluetooth 4.0 technology, this 10.4-inch panel enables wireless data exchange with mobile devices, facilitating remote diagnostics and parameter adjustments without physical access. As a critical component of ABB’s automation ecosystem, the YPC104B connects seamlessly with AC500 PLCs and ABB drives via Ethernet/IP or Modbus RTU, providing real-time process visualization in harsh industrial environments.
Featuring an IP65-rated front panel, the YT204001-BT withstands dust, water jets, and chemical splashes – making it ideal for food processing, packaging, and outdoor applications. Its Linux-based runtime ensures deterministic performance for alarm management, trend logging, and recipe handling. The CP600 Series backbone guarantees interoperability with Panel Builder 800 engineering tools, allowing rapid deployment of customized operator interfaces with drag-and-drop functionality.
Core Advantages and Technical Highlights
Wireless Innovation:
Integrated Bluetooth 4.0 enables secure pairing with tablets/PDAs for mobile HMI access, reducing downtime during troubleshooting. Operators view live data or acknowledge alarms from up to 10m away, enhancing safety in hazardous zones.
Operational Durability:
The YPC104B’s stainless-steel housing and chemically hardened glass survive 50g shock/vibration (IEC 60068-2-6). Wide-temperature LCD (-20°C to +70°C storage) prevents fogging in cold startups.
Engineering Efficiency:
Panel Builder 800’s pre-configured faceplates and alarm templates cut development time by 40%. One-touch project transfer via USB supports field updates. Multi-language runtime (8 languages) simplifies global deployment.
Cybersecurity Compliance:
IEC 62443-4-1 certification provides defense-in-depth security: Role-based access control, encrypted Bluetooth pairing, and audit trails prevent unauthorized operations.
Typical Application Scenarios
In bottling plants, the ABB YPC104B YT204001-BT controls filler/capper machines – operators wirelessly monitor OEE via tablets while maintaining hygiene standards. For HVAC systems, its Bluetooth connectivity allows technicians to adjust setpoints in mechanical rooms without opening enclosures.
Water pumping stations deploy the YT204001-BT for remote pump control; maintenance teams diagnose faults via Bluetooth-enabled PDAs during flood events. In discrete manufacturing, the panel integrates with ABB ACS880 drives to visualize motor torque/energy consumption on extruder lines.
Related Model Recommendations
YPC101A (7″ display): Cost-optimized version for compact machinery
YPC115B (15″ display): Larger variant for central control rooms
CP635-T (Touch-only): Simplified model without Bluetooth
AC500-eCo PLC: Entry-level controller for YPC104B integration
PP825 (Power Panel 800): Advanced HMI with multi-touch support
CEX-BT01: Bluetooth adapter for legacy HMIs
YPC104B YT204001-BT
Installation, Commissioning and Maintenance Instructions
Installation Preparation:
Ensure ambient humidity <90% non-condensing and avoid direct sunlight. Mount using VESA 75×75 mm or panel-mount brackets. Maintain 100mm clearance for ventilation. Use shielded cables (24VDC power) grounded at one end.
Maintenance Suggestions:
Clean screen monthly with isopropyl alcohol (≤70%). Check Bluetooth pairing logs quarterly for unauthorized devices. Update firmware via Panel Builder 800 during planned shutdowns. Replace backlight after 50,000 hours (typical).
Service and Guarantee Commitment
ABB provides a 24-month warranty for the YPC104B YT204001-BT, covering hardware defects and display anomalies. Technical support includes:
Lifetime firmware updates through ABB MyControl System portal
24/7 phone assistance with <15 min response time for critical faults
On-site repair services within 48 hours in major industrial regions
All units undergo 500-hour accelerated aging tests (-30°C to +85°C thermal cycling). Extended support packages cover spare parts for 10+ years after discontinuation.
