Description
Detailed Parameter Table
| Parameter Name | Specification |
| Product Model | ABB UNS0867A-P,V2 HIEE405246R0002 |
| Manufacturer | ABB |
| Product Category | System Control Module |
| Processor Type | Dual-core PowerPC |
| Clock Speed | 1.2 GHz |
| Memory Capacity | 2GB DDR3 RAM |
| Flash Storage | 8GB |
| Communication Interfaces | 2x Ethernet (10/100/1000), 4x RS-485 |
| Operating Temperature | -40°C to +70°C |
| Power Supply | 24V DC (±10%) |
| Power Consumption | 15W typical |
| Protection Rating | IP20 |
| Dimensions | 200 × 150 × 80 mm |
| Certifications | CE, UL, IEC 61850-3 |
UNS0867A-P,V2 HIEE405246R0002
Product Introduction
The ABB UNS0867A-P,V2 HIEE405246R0002 represents ABB’s cutting-edge control module technology, designed for mission-critical automation applications. This high-performance module serves as the brain of complex control systems, delivering exceptional processing power and reliability in demanding industrial environments.
As part of ABB’s System 800xA platform, this V2 revision module features enhanced processing capabilities and expanded memory resources compared to previous versions. The UNS0867A-P,V2 is engineered to handle complex control algorithms, data processing, and communication tasks simultaneously, making it ideal for power generation, oil & gas, and large-scale process automation applications where system availability and performance are paramount.
Core Advantages and Technical Highlights
Computational Power:
The dual-core PowerPC architecture running at 1.2 GHz provides ample processing capacity for demanding control applications. The module executes complex control algorithms with deterministic performance, ensuring precise timing for critical processes.
Enhanced Connectivity:
With dual Gigabit Ethernet ports and four RS-485 serial interfaces, the UNS0867A-P,V2 supports simultaneous communication with multiple field devices, subsystems, and enterprise networks. The Ethernet interfaces support both copper and fiber optic connections (with appropriate transceivers).
Rugged Industrial Design:
Operating reliably from -40°C to +70°C, the module withstands extreme environmental conditions. The robust metal enclosure provides excellent EMI protection and heat dissipation for continuous operation.
Advanced Diagnostics:
Comprehensive self-diagnostics and status monitoring capabilities enable predictive maintenance. The module provides detailed system health information through ABB’s Control Builder engineering tool.
Future-Proof Architecture:
With 2GB RAM and 8GB flash storage, the module has sufficient resources for current and future application requirements. The design supports firmware updates for feature enhancements and security patches.
Redundancy Support:
The UNS0867A-P,V2 can be configured in redundant pairs for mission-critical applications, with automatic failover capability to ensure continuous operation.
Typical Application Scenarios
The ABB UNS0867A-P,V2 HIEE405246R0002 excels in:
Power Generation:
Turbine control systems
Plant-wide DCS implementations
Smart grid integration
Oil & Gas:
Offshore platform control
Pipeline SCADA systems
Refinery process control
Chemical Processing:
Batch process automation
Safety instrumented systems
Distributed control architectures
Water Management:
Large-scale water treatment plants
Pumping station networks
Flood control systems
Infrastructure:
Tunnel control systems
Airport baggage handling
Metro train control
UNS0867A-P,V2 HIEE405246R0002
Related Model Recommendations
ABB UNS0867A-P,V1: Previous version with reduced performance
ABB UNS0880A-P: Higher-performance model with quad-core processor
ABB UNS0821A: Compact version for space-constrained applications
ABB CI867: Communication interface module
ABB PM864AK01: Processor unit for AC 800M
ABB S800 I/O: Fieldbus modules for system expansion
ABB UNS0886A: Advanced version with enhanced security features
Installation, Commissioning and Maintenance Instructions
Installation Preparation:
Ensure proper rack space and cooling provisions are available. Verify the 24V DC power supply meets specifications (±10%). Have appropriate network cables and tools ready for connections. Ground the module according to ABB guidelines for optimal noise immunity.
Commissioning:
Use ABB’s Control Builder software for module configuration. Verify firmware version and update if necessary. Perform comprehensive system diagnostics before putting into operation. Test all communication interfaces and redundancy features (if configured).
Maintenance:
Monitor module temperature and performance through system diagnostics. Keep firmware updated to latest stable version. Maintain adequate ventilation and clean air filters regularly. In redundant configurations, test failover functionality during maintenance windows.
Service and Guarantee Commitment
ABB provides a 60-month warranty for the UNS0867A-P,V2 HIEE405246R0002, demonstrating exceptional confidence in product reliability. Our global support network offers:
24/7 technical support
On-site commissioning assistance
Firmware update services
Repair and replacement programs
Lifetime product support commitment
Extended service agreements include:
Preventive maintenance programs
Emergency response services
System health monitoring
Cybersecurity updates
