Description
Detailed Parameter Table
| Parameter Name | Specification |
| Product Model | ABB UFC760BE42 3BHE004573R1042 |
| Manufacturer | ABB |
| Product Category | Field Control Unit (FCU) |
| Input Voltage | 24V DC (±10%) |
| Communication Protocols | PROFIBUS DP, Modbus RTU |
| Operating Temperature | -25°C to +70°C |
| Protection Rating | IP20 |
| Mounting Type | DIN Rail |
| Dimensions (W×H×D) | 120 × 110 × 75 mm |
| Weight | 0.5 kg |
| I/O Capacity | Configurable up to 128 points |
| Redundancy Support | Yes (with redundant configuration) |
| Certifications | CE, UL, IEC 61131-2 |
ABB UFC760BE42 3BHE004573R1042
Product Introduction
The ABB UFC760BE42 3BHE004573R1042 is a high-performance Field Control Unit designed for demanding industrial automation applications. As part of ABB’s 800xA and AC 800M control system families, this advanced FCU provides reliable communication between field devices and control systems in harsh industrial environments.
Building upon the success of previous UFC models, the UFC760BE42 version features enhanced processing capabilities and improved communication performance. Its rugged design and wide operating temperature range make it particularly suitable for power generation, oil & gas, and process industry applications where reliability is critical.
Core Advantages and Technical Highlights
Enhanced Communication Performance:
The UFC760BE42 supports PROFIBUS DP at 12 Mbps and Modbus RTU simultaneously, with improved data throughput compared to previous models. The dual-protocol support enables seamless integration with both modern and legacy equipment.
Robust Industrial Design:
Operates reliably in temperatures from -25°C to +70°C
Metal housing provides superior EMI protection
DIN rail mounting for secure installation in vibration-prone environments
Advanced Diagnostics:
Comprehensive LED status indicators
Built-in self-diagnostics
Remote monitoring capability through ABB’s Control Builder software
Flexible Configuration:
Supports up to 128 I/O points
Modular design allows for various signal types (digital, analog, temperature)
Hot-swappable in redundant configurations
Seamless System Integration:
Fully compatible with ABB’s 800xA DCS
Works with AC 800M controllers
Plug-and-play operation within ABB’s automation ecosystem
Typical Application Scenarios
The ABB UFC760BE42 3BHE004573R1042 excels in various industrial automation applications:
Power Generation:
Turbine control systems
Excitation control
Substation automation
Oil & Gas:
Wellhead monitoring
Pipeline SCADA systems
Compressor control
Process Industries:
Batch process control
Safety interlocks
Distributed I/O collection
Water/Wastewater:
Pump station control
Filtration systems
Flow monitoring
Manufacturing:
Production line automation
Machine control
Quality monitoring systems
ABB UFC760BE42 3BHE004573R1042
Related Model Recommendations
ABB UFC760BE142: Enhanced version with additional features
ABB UFC762AE01: Version with Ethernet connectivity
ABB UFC719AE01: Basic version with reduced I/O capacity
ABB CI854A: Communication interface module
ABB AC 800M PM864AK01: High-performance controller
ABB S800 I/O modules: Field I/O expansion units
ABB UFC718AE01: Compact version for space-constrained applications
Installation, Commissioning and Maintenance Instructions
Installation Preparation:
Verify proper DIN rail space is available
Ensure 24V DC power supply meets specifications (±10%)
Use shielded communication cables
Ground the unit according to ABB guidelines
Commissioning:
Configure using ABB’s Control Builder software
Test all communication interfaces
Verify I/O functionality
Check redundancy features (if configured)
Maintenance:
Regularly inspect terminal connections
Clean ventilation openings annually
Monitor LED indicators for status
Perform firmware updates during maintenance windows
Keep spare units available for critical applications
Service and Guarantee Commitment
ABB provides a 24-month warranty for the UFC760BE42 3BHE004573R1042, covering manufacturing defects. Our global service network offers:
24/7 technical support
On-site commissioning assistance
Repair and replacement services
Firmware update support
Lifetime product support commitment
Extended service agreements are available, including:
Preventive maintenance programs
Priority spare parts access
System health monitoring
Emergency response services
