Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | ABB PFTL301E-1.0KN |
| Manufacturer | ABB |
| Product Category | Force Transducer |
| Measurement Range | 0-1.0 kN |
| Accuracy | ±0.5% full scale |
| Output Signal | 4-20 mA / 0-10V DC |
| Supply Voltage | 10-30V DC |
| Operating Temperature | -20°C to +85°C |
| Protection Rating | IP67 |
| Electrical Connection | M12 connector |
| Material | Stainless steel (AISI 304) |
| Load Direction | Tension and compression |
| Safety Factor | 150% of rated capacity |
| Certifications | CE, RoHS |
ABB PFTL301E-1.0KN
Product Introduction
The ABB PFTL301E-1.0KN is a high-precision force transducer designed for industrial measurement and control applications. This robust device provides accurate force measurement up to 1.0 kilonewton with excellent linearity and repeatability. As part of ABB’s comprehensive measurement portfolio, the PFTL301E-1.0KN combines advanced strain gauge technology with rugged construction for reliable performance in demanding environments.Engineered for versatility, the ABB PFTL301E-1.0KN features both tension and compression measurement capabilities, making it suitable for diverse industrial applications. Its stainless steel construction and IP67 protection rating ensure long-term durability even in harsh conditions. The transducer’s standardized electrical interfaces simplify integration with PLCs, DCS systems, and data acquisition equipment across various automation platforms.
Core Advantages and Technical Highlights
Precision measurement: The ABB PFTL301E-1.0KN delivers ±0.5% accuracy across its full measurement range, providing reliable data for process control and quality assurance. Advanced temperature compensation ensures stable performance throughout the operating temperature range.Robust construction: Manufactured from AISI 304 stainless steel, the transducer withstands industrial environments while maintaining measurement integrity. The IP67-rated enclosure protects against dust ingress and temporary water immersion.Versatile installation: With its compact design and standardized M12 connector, the ABB PFTL301E-1.0KN can be easily integrated into existing systems. The device supports both tension and compression measurements, offering flexibility in application design.Reliable outputs: The transducer provides industry-standard 4-20 mA and 0-10V DC output signals, ensuring compatibility with most control and monitoring systems. Electrical isolation protects against ground loops and interference.
Typical Application Scenarios
The ABB PFTL301E-1.0KN is widely used in:
Manufacturing automation: Monitoring press forces in assembly operations and verifying proper clamping forces in production fixtures.Material testing: Providing precise force measurement for quality control in product testing applications.Process industries: Measuring tension in web handling systems and monitoring mechanical loads in industrial machinery.Robotics: Force feedback applications in robotic assembly and material handling systems.Packaging lines: Verifying proper sealing pressures and monitoring mechanical forces in packaging equipment.
Related Model Recommendations
ABB PFTL101E-0.5KN: Lower capacity model (0.5 kN) for light-duty applications
ABB PFTL501E-2.0KN: Higher capacity model (2.0 kN) for heavy-duty requirements
ABB PFTL301E-5.0KN: Extended range version for greater force measurement
ABB PFTL301E-1.0KN/IO: Version with integrated I/O module
ABB PFTL301E-1.0KN/ATEX: Explosion-proof certified variant
ABB CP600 HMI: Compatible operator interface for visualization
ABB AC500 PLC: Ideal control system for integration
ABB PFTL301E-1.0KN
Installation, Commissioning and Maintenance Instructions
Installation preparation: Ensure the mounting surface is clean and properly aligned to avoid side loads. Verify the load direction matches the application requirements (tension or compression). Check that all electrical connections comply with the specified voltage requirements.
Maintenance suggestions: Periodically inspect the transducer for physical damage or corrosion. Verify zero point calibration annually or as process requirements dictate. Keep electrical connections clean and protected from moisture. For optimal performance, avoid exceeding 150% of the rated capacity.
Service and Guarantee Commitment
ABB offers a 2-year warranty for the ABB PFTL301E-1.0KN, covering manufacturing defects and material faults. Global technical support is available through ABB’s network of service centers. Comprehensive documentation, including calibration certificates and installation guides, accompanies each unit. ABB provides traceable calibration services to ensure measurement accuracy throughout the product lifecycle.
