Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | ABB CI860K01 3BSE032444R1 |
| Manufacturer | ABB |
| Product Category | PROFIBUS Communication Interface |
| Communication Protocol | PROFIBUS DP (IEC 61158/61784) |
| Data Transfer Rate | Up to 12 Mbps |
| Isolation Voltage | 500V AC (galvanic isolation) |
| Operating Temperature | -25°C to +70°C |
| Protection Rating | IP20 |
| Mounting Type | DIN Rail |
| Dimensions (W×H×D) | 45mm × 125mm × 117mm |
| Power Supply | 24V DC (±10%) |
| Compatibility | ABB AC 800M, 800xA DCS |
| Certifications | CE, UL, ATEX (optional) |
ABB CI860K01 3BSE032444R1
Product Introduction
The ABB CI860K01 3BSE032444R1 is a high-performance PROFIBUS DP communication interface module designed for seamless integration within ABB’s AC 800M controller and 800xA Distributed Control System (DCS). This module serves as a critical link between ABB’s automation systems and field devices, ensuring robust and high-speed data exchange in industrial environments.
Engineered for reliability, the CI860K01 supports PROFIBUS DP (Decentralized Periphery) communication at speeds up to 12 Mbps, making it ideal for real-time process control applications. Its rugged design ensures stable operation in harsh industrial conditions, including extreme temperatures and high electromagnetic interference (EMI) environments.
Core Advantages and Technical Highlights
High-Speed PROFIBUS DP Communication:
The ABB CI860K01 3BSE032444R1 enables fast and deterministic data transfer (up to 12 Mbps), ensuring real-time communication between PLCs, drives, and field devices.
Robust Industrial Design:
Wide operating temperature range (-25°C to +70°C) for harsh environments
500V AC galvanic isolation protects against electrical noise and ground loops
DIN rail mounting for easy installation in control cabinets
Seamless System Integration:
Fully compatible with ABB AC 800M controllers and 800xA DCS
Supports PROFIBUS DP-V0 and DP-V1 for cyclic and acyclic data exchange
Plug-and-play configuration via ABB Automation Builder software
Reliable Diagnostics & Redundancy Support:
Built-in LED indicators for real-time status monitoring
Supports PROFIBUS DP redundancy (when used with redundant controllers)
Advanced diagnostics for quick troubleshooting
Typical Application Scenarios
The ABB CI860K01 3BSE032444R1 is widely used in industries requiring high-speed and reliable PROFIBUS communication:
Power Plants: Integration of turbines, generators, and substation automation
Oil & Gas: Remote I/O communication for pumps, valves, and flow meters
Manufacturing: Machine control and production line automation
Chemical & Petrochemical: Safety-critical process control systems
Water & Wastewater: SCADA system integration for pump stations
Its high-speed data transfer and rugged design make it ideal for applications where real-time control and reliability are critical.
ABB CI860K01 3BSE032444R1
Related Model Recommendations
ABB CI854A – Redundant PROFIBUS DP communication module
ABB CI858K01 – PROFINET communication interface
ABB CI867 – Ethernet/IP communication module
ABB AC 800M PM864AK01 – High-performance controller compatible with CI860K01
ABB S800 I/O Modules – Field I/O expansion for AC 800M systems
Installation, Commissioning & Maintenance
Installation Preparation:
Ensure proper 24V DC power supply (±10%)
Verify DIN rail mounting space in control cabinet
Use shielded PROFIBUS cables for noise immunity
Maintenance Recommendations:
Regularly check LED status indicators for faults
Periodically inspect terminal connections for corrosion
Update firmware via ABB Automation Builder
Service & Warranty Commitment
ABB provides a 24-month warranty for the CI860K01 3BSE032444R1, covering manufacturing defects. Global technical support is available for troubleshooting, and replacement units can be sourced through ABB’s certified distributors.
