Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | ABB CI547 |
| Manufacturer | ABB |
| Product Category | Communication Interface Module |
| Series | 800xA System |
| Interface Type | Redundant Ethernet |
| Protocols Supported | IEC 61850, Modbus TCP/IP, OPC UA |
| Data Transfer Rate | 100/1000 Mbps |
| Power Supply | 24V DC (±10%) |
| Operating Temperature | 0°C to +60°C |
| Protection Rating | IP20 |
| Dimensions (W×H×D) | 45×130×115 mm |
| Redundancy Support | Yes (HSR/PRP) |
| Certifications | CE, UL, IEC 61850-3 |
ABB CI547
Product Introduction
The ABB CI547 is a high-performance communication interface module designed for ABB’s 800xA distributed control system. This versatile module serves as a critical gateway between field devices and control systems, supporting multiple industrial protocols including IEC 61850 for power automation applications. The CI547 enables seamless data exchange in complex automation architectures, providing reliable connectivity for mission-critical operations.
As part of ABB’s 800xA ecosystem, the CI547 module offers redundant Ethernet interfaces with HSR/PRP support, ensuring continuous communication availability in demanding industrial environments. Its compact design and flexible configuration options make it suitable for both greenfield installations and system upgrades across various industries, from power generation to process manufacturing.
Core Advantages and Technical Highlights
High-availability communication: The ABB CI547 features redundant power and network interfaces with zero-recovery-time switching, maintaining uninterrupted data flow even during network disturbances. The module’s HSR/PRP support enables seamless redundancy for critical applications.
Multi-protocol capability: Supporting IEC 61850 (Edition 2), Modbus TCP/IP, and OPC UA, the CI547 serves as a universal communication hub in heterogeneous automation environments. Its protocol conversion capabilities reduce integration complexity.
Cybersecurity features: Built-in security functions including role-based access control, encrypted communication, and secure boot ensure protection against cyber threats. The module supports network segmentation and firewall functionality.
Advanced diagnostics: Comprehensive monitoring capabilities provide real-time status information and detailed event logging. The module’s web interface allows remote configuration and troubleshooting, reducing maintenance downtime.
Typical Application Scenarios
The ABB CI547 is extensively used in:
Power utility automation: Serving as IEC 61850 gateway in substation automation systems, connecting protection relays and intelligent electronic devices (IEDs) to SCADA systems.
Oil and gas facilities: Integrating field instruments and safety systems with distributed control systems in upstream and downstream operations.
Pharmaceutical manufacturing: Enabling data exchange between process equipment and MES systems while maintaining strict compliance with regulatory requirements.
Water treatment plants: Connecting PLCs and RTUs across distributed sites to central monitoring systems for efficient process control.
Marine automation: Providing robust communication in shipboard control systems where reliability is critical.
ABB CI547
Related Model Recommendations
ABB CI546: Previous generation interface with similar functionality
ABB CI548: Advanced version with additional protocol support
ABB COM600: Communication gateway for network integration
ABB S800 I/O: Remote I/O modules for field connection
ABB AC500 PLC: Programmable controller for automation tasks
ABB PPC900: Operator panels for visualization
ABB Advant OCS: Legacy system integration modules
Installation, Commissioning and Maintenance Instructions
Installation preparation: Mount the ABB CI547 in a well-ventilated control cabinet with proper grounding. Ensure adequate clearance for heat dissipation and cable routing. Verify network infrastructure meets technical requirements before installation.
Commissioning steps: Configure network parameters using the module’s web interface. Set up protocol-specific parameters and test communication with connected devices. Verify redundancy functionality through controlled failover tests. Document all configuration settings for future reference.
Maintenance suggestions: Regularly check firmware versions and apply updates as recommended by ABB. Monitor communication performance statistics for early detection of potential issues. Keep backup copies of configuration files. Periodically inspect physical connections and clean ventilation openings.
Service and Guarantee Commitment
ABB provides a standard 3-year warranty for the ABB CI547, covering manufacturing defects and component failures. Extended warranty options are available for critical infrastructure applications. ABB’s global technical support network offers 24/7 assistance, with firmware updates and security patches regularly released through ABB’s service portal. On-site support and training services are available to ensure optimal system performance throughout the product lifecycle.
