Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product Model | ABB 57310001-PK |
| Manufacturer | ABB |
| Product Category | Power Supply Module |
| Input Voltage Range | 85-264 V AC / 120-300 V DC |
| Output Voltage | 24 V DC (±0.5%) |
| Output Current | 20 A (480 W) |
| Efficiency | >93% (typical at full load) |
| Protection Features | Overload, overvoltage, short-circuit, overtemperature |
| Cooling Method | Forced air (integrated fan) |
| Operating Temperature | -25°C to +70°C |
| Relative Humidity | 5-95% (non-condensing) |
| Safety Certifications | UL 508, CE, IEC 61131-2 |
| Mounting | DIN rail (TS 35/7.5/15) |
| Dimensions (W×H×D) | 125 × 145 × 125 mm |
| Communication | PMU interface for monitoring |
ABB 57310001-PK
Product Introduction
The ABB 57310001-PK is a high-performance industrial power supply module designed specifically for critical automation systems requiring robust and stable DC power distribution. Engineered as part of ABB’s premium power solutions portfolio, this 480W unit delivers precisely regulated 24V DC power to PLC racks, I/O systems, and field devices in demanding industrial environments. The ABB 57310001-PK serves as the central power backbone for ABB AC500 PLC systems and other automation platforms, ensuring uninterrupted operation of control components even during voltage fluctuations.
With its wide input voltage range (85-264V AC/120-300V DC), the ABB 57310001-PK provides exceptional flexibility for global installations, automatically adapting to different mains voltages without manual reconfiguration. Its primary technical value lies in delivering clean, stable power with less than 0.5% voltage deviation – crucial for sensitive electronic controls and measurement devices. The module integrates seamlessly into ABB’s automation ecosystem, featuring a dedicated PMU interface for real-time monitoring of operational parameters through control systems. For mission-critical applications, the ABB 57310001-PK ensures power integrity that directly impacts system reliability and process continuity.
Core Advantages and Technical Highlights
Ultra-High Efficiency & Thermal Management: The ABB 57310001-PK achieves >93% energy conversion efficiency, significantly reducing heat generation and operating costs. Its advanced thermal design combines optimized internal airflow with a temperature-controlled fan, enabling full-load operation at 70°C ambient temperature. This thermal resilience prevents derating in hot industrial environments like boiler rooms or foundries.
Multi-Layered Protection System: Incorporating comprehensive safeguard mechanisms, the module features redundant protection against all critical electrical faults. Its current-limiting design handles short-circuits without component damage, while the “hiccup mode” during overloads allows automatic recovery when normal conditions resume. The overtemperature protection includes both thermal shutdown and pre-alarm signaling through the PMU interface.
Industrial-Grade Robustness: Built to withstand harsh conditions, the ABB 57310001-PK features 6kV surge protection on AC inputs and 4kV isolation between input/output circuits. Its conformally coated PCB resists humidity, dust, and corrosive atmospheres, validated by extended testing at 95% humidity. The unit withstands 5g vibration and 50g shock impacts.
Intelligent Monitoring Capabilities: Beyond basic power conversion, the module provides real-time status data via its PMU port, including output voltage/current readings, temperature, load percentage, and fault diagnostics. This predictive maintenance capability allows early intervention before power issues escalate, minimizing unplanned downtime.
Typical Application Scenarios
The ABB 57310001-PK is indispensable in heavy industries where power stability directly impacts safety and productivity. In automotive manufacturing, it powers robotic cell controllers and welding control systems where voltage sags could cause costly production halts or quality defects. Its immunity to electromagnetic interference ensures reliable operation near high-frequency welding equipment and variable speed drives.
For water treatment plants, the module provides clean power for PLC-controlled chemical dosing systems and turbidity analyzers where voltage fluctuations could cause measurement errors affecting water quality. Its wide temperature range allows deployment in unheated pump stations during winter. In oil & gas applications, the ABB 57310001-PK powers wellhead safety systems and compressor control panels, where its surge protection guards against lightning strikes common in remote installations.
The power supply is equally critical in food processing facilities, where it drives sanitary I/O systems in washdown areas. Here, the unit’s sealed design withstands high-pressure cleaning while maintaining stable power for hygienic process controls. In material handling, multiple ABB 57310001-PK units often power distributed control nodes along conveyor systems, with the DIN-rail mounting enabling compact installation in electrical cabinets.
ABB 57310001-PK
Related Model Recommendations
ABB 57310001-H: Higher-capacity sibling (720W) for expanded systems requiring greater power
ABB 57310001-L: Compact version (240W) for space-constrained installations
ABB CP605-ETH: AC500 PLC CPU module powered by the 57310001-PK
ABB TB521: Terminal base for simplified wiring to AC500 PLC racks
ABB SD560: Digital input module powered by the 57310001-PK
ABB PM573: Redundant power module for critical parallel operation
ABB CEX-B01: Expansion interface enabling multiple 57310001-PK synchronization
ABB 1SBP260100R1001: Redundancy module for fail-safe power configurations
Installation, Commissioning and Maintenance Instructions
Installation Preparation: Before installing the ABB 57310001-PK, verify cabinet clearance (minimum 50mm above/below for airflow) and ensure DIN rail integrity. Prepare appropriate wire gauges (input: 14-18 AWG, output: 10-14 AWG). Confirm input voltage compatibility and disconnect mains power. Use torque-controlled tools for terminal connections (1.2 N·m for output terminals). Ground the unit directly to cabinet earth using the designated 4mm² grounding terminal.
Maintenance Suggestions: Quarterly inspection should include checking air vents for dust accumulation and verifying fan operation (audible start at ~50°C). Monitor temperature and load metrics via PMU interface monthly. Replace cooling fans proactively every 5 years or 50,000 operating hours. During electrical storms in vulnerable locations, temporarily increase monitoring frequency. If output voltage drifts beyond ±1%, perform calibration using ABB service tools. Always keep spare units available for critical processes – hot-swap replacement requires proper busbar configuration.
Service and Guarantee Commitment
ABB provides a 36-month warranty for the 57310001-PK power supply module, covering all manufacturing defects and premature failures under normal operating conditions. Our global technical support network offers 24/7 assistance through ABB’s Customer Care Line, with field service engineers available for on-site troubleshooting within 24 hours for critical failures. Extended product lifecycle commitment guarantees spare parts availability for 15 years after discontinuation.
Comprehensive support includes free access to ABB’s PowerAssist web portal featuring installation videos, wiring diagrams, and diagnostic calculators. Registered users receive firmware updates enhancing protection algorithms and monitoring capabilities. ABB’s “PowerExchange” program allows advance replacement for warranty claims to minimize downtime. All ABB 57310001-PK units undergo 100% full-load burn-in testing before shipment, demonstrating our commitment to reliability in your mission-critical applications.
