Product Core Brief
- Model: 136180-01
- Brand: BENTLY NEVADA
- Series: 3500/92
- Core Function: Bridges 3500 rack monitoring data to external SCADA and DCS networks.
- Product Type: Communication Gateway I/O Module
- Key Specs: Ethernet TCP/IP | Serial RS232/RS485 | Modbus Protocol
- Condition: New Original / New Surplus
BENTLY NEVADA 136180-01
Product Introduction
BENTLY 136180-01 is a 3500/92 communication gateway module for industrial machinery protection systems. It translates all rack monitoring values and status flags for external process control integration.
This industrial automation unit supports both Ethernet TCP/IP and serial communication simultaneously. It handles Modbus TCP and native Bently protocols to feed critical data to your asset management software.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Module Type | 3500/92 Communication Gateway |
| Ethernet Protocol | TCP/IP, Modbus/TCP |
| Serial Protocol | RS232, RS422, RS485 |
| Supported Protocols | Modicon Modbus, Bently Native |
| Rack Compatibility | 3500 Series Framework |
| Hot-Swap Capability | Yes |
| Software Support | 3500 Configuration & Data Acquisition |
| Operating Temp | -30°C to +65°C |
| Mounting | 3500 Backplane Slot |
| Data Scope | Full Rack Monitoring Values & Status |
Quality Control Process
We validate every BENTLY 136180-01 before it leaves our facility. First, we perform a live network ping and port scan to verify both Ethernet and serial interface integrity.
Next, we simulate Modbus TCP requests using a network analyzer to confirm accurate data mapping and polling response times. We also verify the module’s ability to handshake with standard 3500 configuration software.
Finally, each replacement module ships in anti-static shielding with desiccant packs. This prevents moisture ingress during transit.
Replacement Pitfall Guide
❗ Network Segregation: Never connect this gateway directly to a corporate IT network without a firewall. Industrial Modbus traffic is unencrypted and can expose your control layer to cyber threats.
❗ Baud Rate Mismatches: When using the serial RS485 ports, verify the baud rate matches your legacy SCADA system exactly. A mismatch here causes silent data drops that mimic sensor failures.
❗ Backplane Slot Limits: Communication gateways have dedicated slot restrictions in the 3500 rack. Forcing this module into a standard I/O slot will damage the backplane connectors.
❗ Software Configuration Lock: Swapping a gateway requires importing the exact rack configuration file. Missing a single parameter can disable critical alarm routing to your control room.
Keep these in mind and you’ll cut 90% of rework time.
BENTLY 3500/92 136180-01
Compatibility Matrix & Benchmarks
| Original Model | Replacement / Successor Model | Compatibility Level | Migration Notes |
|---|---|---|---|
| 136180-01 | 3500/92-01-00-00 | Direct | Current production equivalent |
| 136180-01 | 3500/92-02-00-00 | Direct | Verify firmware revision |
| 136180-01 | 3500/92M | Direct | Enhanced diagnostic version |
- Data Polling Rate: < 100ms for full rack status
- Max Network Nodes: Supports up to 32 serial drops
