Product Core Brief
- Model: P0916XT
- Brand: Foxboro (Invensys / Schneider Electric)
- Series: I/A Series Distributed Control System (DCS)
- Core Function: Processes analog input signals from field sensors and converts them into digital data for the I/A Series control network.
- Product Type: Analog Input Field Bus Module (FBM)
- Key Specs: Analog Input | Sensor/Transmitter Interface | Part Number
- Condition: New Original (New Surplus) | Factory Sealed
Key Technical Specifications
| Parameter | Value |
|---|---|
| Module Type | Analog Input Field Bus Module (FBM) |
| System Platform | Foxboro I/A Series DCS |
| Primary Function | Analog Signal Processing & Conversion |
| Input Signal Types | 4-20mA, 1-5V (Verify via OEM Datasheet) |
| Manufacturer Part Number | |
| Mounting | Plug-in I/A Series FBM Baseplate |
| Application | Temperature, Pressure, Flow Monitoring |
| Environmental Rating | Industrial Grade, High Precision |
| Condition | New Original (New Surplus) |
| Warranty | 1-Year Functional Warranty |
FOXBORO P0916PW
Product Introduction
Reliable process control depends on accurate field data, and the serves as the critical interface for bringing that data into your I/A Series system. This analog input module is designed to receive signals from field sensors and transmitters, converting them into digital values the controller can use for regulation and monitoring.
Engineered for continuous industrial duty, the ensures high-fidelity signal conversion with robust electrical isolation to protect against ground loops and EMI. Whether tracking pressure, temperature, or flow in chemical or power generation applications, this module provides the deterministic performance required for closed-loop control.
Key Selling Points & Differentiators
- Precision Signal Conversion: Accurately translates analog field signals into digital process variables, ensuring reliable data for PID loops and sequential logic.
- I/A Series Integration: Seamlessly plugs into standard I/A Series FBM baseplates, automatically recognized by the node processor without manual slot configuration.
- Verified Functionality: Every undergoes a 24-hour live load test on a dedicated I/A Series test rack before shipping, complete with a signed test report.
- Not Recommended For: Do not use this module for discrete (on/off) signals or direct thermocouple/RTD inputs. Use FBM207 for discrete inputs or FBM202/FBM203 for direct temperature sensors.
- Stock Availability: Current inventory is factory-sealed new surplus with traceable lot numbers; typically ships within 48 hours of order confirmation.
- Warranty Backed: Includes a 1-year functional warranty covering manufacturing defects and DOA conditions, with no restocking fees for verified failures.
FOXBORO P0916PW
FAQ
Yes. All units in stock have passed our 24-hour live bench test and include a signed test report. We ship same-day for orders placed before 2 PM EST, so you’ll have tracking before end of day.
The is designed for standard I/A Series FBM baseplates. Verify your baseplate revision and node processor firmware first to ensure proper recognition. Send us your baseplate part number, and we’ll confirm compatibility within 30 minutes.
What signal types does this module support?
This module is designed for standard analog inputs (typically 4-20mA or 1-5V). Always verify the specific signal range against your OEM datasheet before installation to ensure it matches your field transmitter output.
Do I need to reconfigure the module after installation?
No. The retains its configuration in the I/A Series node processor. Simply plug it into the same slot, and the system will recognize it. However, always verify scaling, engineering units, and alarm limits in your DCS configuration tool after replacement.
What if the module fails within the warranty period?
We offer a no-questions-asked replacement for any verified manufacturing defect. Ship the failed unit back with your RMA number, and we’ll send a replacement within 24 hours of receipt. We also provide a loaner program for critical control loops to minimize downtime.
Can this module handle high-interference environments?
Yes. The features robust electrical isolation designed to combat ground loops and electrical noise. However, ensure your field wiring uses properly shielded twisted-pair cable with correct single-point grounding at the baseplate end.
Is this a refurbished or new surplus unit?
This is New Original (New Surplus) – factory sealed, never installed, with full traceability to the original manufacturing lot. It is not refurbished, repaired, or pulled from a decommissioned system. We provide the original manufacturer’s lot code upon request for your quality records.
Quality Transparency SOP
- Incoming Verification: Source traceability confirmed via lot code; anti-counterfeit visual inspection; serial number cross-referenced with OEM records; accessories verified.
- Live Bench Test: Dedicated I/A Series test rack; power-on self-check; analog input full-scale simulation; node communication handshake test; 24-hour continuous load test; signed test report generated.
- Electrical Tests: Insulation resistance verified at 500V megger (>10 MΩ); ground continuity confirmed; channel-to-channel isolation validated.
- Firmware Verification: Firmware version recorded; DIP/jumper configuration backed up and documented.
- Final QC & Packaging: QC sign-off; anti-static seal applied; shock protection installed; QC Passed label affixed with date and inspector ID.
Test photos and video available upon request. We never claim “100% failure-free” – we provide verified, tested units with documented performance.
Technical Risk Avoidance
- Signal Type Mismatch: Risk: Incorrect readings or module damage. Prevention: Verify field signals match the module’s analog input specification. Field Note: We’ve seen modules report saturated values because a technician wired a 0-10V signal to a 4-20mA configured channel. Always verify signal type.
- Baseplate Seating: Risk: Intermittent communication or channel dropouts. Prevention: Ensure the module is fully seated and locked onto the baseplate. Field Note: A partially seated FBM caused random analog spikes during plant vibration. Push firmly until the latch clicks.
- Node Processor Compatibility: Risk: Module not recognized. Prevention: Verify the node processor firmware supports the revision. Field Note: Integrators waste hours troubleshooting when the real issue is a firmware gap. Check the revision first.
- Scaling Configuration Errors: Risk: Process control failure. Prevention: Verify engineering units and scaling in the DCS match the field transmitter. Field Note: A pressure transmitter reading 100 PSI showed as 10 PSI because the DCS scaling was never updated after replacement. Always verify scaling.
- ESD Damage: Risk: Silent channel failure. Prevention: Use grounded wrist strap and anti-static mat during handling. Field Note: We’ve tested modules that passed power-on but had dead input channels after 48 hours due to ESD. Handle with care.
