Product Core Brief
- Model:
- Brand: ABB
- Series: Symphony Plus SD HPC800 DCS Core Controller Hardware
- Core Function: High-performance dual-core central processing unit serving as the master logic core of HPC800 rack controllers; executes continuous, discrete, safety and turbine control strategies, communicates with SD I/O, HMI, fieldbus and peer controllers via redundant internal/plant networks.
- Product Type: Rack-Mount Main Control Processor Module
- Key Specs: 1.2 GHz dual-core CPU | Max 30,000 function blocks | 64 MB DRAM + 2 MB NVRAM | Full system-level redundancy support Condition: New Original (New Surplus)
Product Introduction
The ABB is the dedicated core processing module for ABB Symphony Plus HPC800 DIN rail controller racks, built for mission-critical power generation, water treatment and heavy chemical DCS applications with strict uptime requirements.Well, technically it shares the same twin redundant DIN rail housing as auxiliary communication cards, yet the ABB integrates high-speed real-time control logic and non-volatile backup memory absent from peripheral I/O or fieldbus modules. Its base control cycle reaches 0.08 ms for fast boiler/turbine closed-loop regulation, while supporting seamless bumpless switchover between primary and standby redundant pairs without process interruption.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Full Model Code | (HPC800 controller core processor) |
| Processing Hardware | Dual-core 1.2 GHz real-time industrial CPU |
| Maximum Function Block Capacity | Up to 30,000 standard Symphony control function blocks |
| Memory Configuration | 64 MB DRAM runtime memory, 4 MB firmware ROM, 2 MB NVRAM non-volatile backup |
| Redundancy Modes | CPU, power, HN800 I/O bus, CW800 peer controller bus, plant Ethernet full redundant support |
| Built-In Communication Ports | Dual RJ45 100 Mbps plant Ethernet, redundant HN800 internal I/O bus, redundant CW800 inter-controller bus, RS232 local console port |
| Supported Fieldbus Gateways | HAI805 HART, Profibus DP, Modbus TCP via expansion comms modules |
| Nominal Operating Supply | 24 V DC (21.6–26.4 V continuous tolerance) |
| Typical Power Draw | 12 W single fully loaded |
| Operating Cabinet Temperature | -25 °C to +60 °C non-condensing air |
| Storage / Transport Temp | -40 °C to +70 °C non-operating |
| Mechanical Mounting | Standard 35 mm top-hat DIN rail, twin redundant side-by-side installation |
| Unit Net Weight | 0.5 kg single module |
| Enclosure Protection Class | IP20 indoor control cabinet only |
| Compliance Certifications | IEC 62443 ISASecure, CE, UL, SIL 2 capable for safety interlock logic |
| Compatible I/O Series | Symphony Plus SD I/O (HAI805, HDO800 etc.) + legacy S800 I/O via adapters |
Quality Control Process
- Incoming Verification: Cross-reference serial numbers against ABB Symphony Plus factory batch manifests to reject counterfeit controller hardware. Visual inspection checks for cracked front panel Ethernet ports, tarnished rear bus gold pins, or swollen backup electrolytic capacitors (—minor chassis paint scuffs pass QA screening).
- Live Functional Test: Install a redundant pair into a calibrated HPC800 DIN rail test bench, feed regulated 24 V DC redundant rack power, and run full power-on self-diagnostics. Establish HN800 handshake with simulated HAI805 HART I/O, CW800 peer controller link and Ethernet HMI connection, then execute a 24-hour full control strategy cyclic load test with bumpless redundancy switchover logging every hour.
- Electrical Parameter Test: Use a Megger MIT300 at 500 V to validate cross-circuit insulation resistance between CPU logic and all communication port circuits; every isolation path must read above 10 MΩ. Confirm DIN rail protective earth continuity via Fluke 115 multimeter on the chassis ground lug.
- Firmware Verification: Read embedded real-time control firmware revision via Symphony Plus Engineering Tool, log version data to unit trace paperwork, photograph Ethernet IP address and bus termination jumper positions on the rear terminal header as field replacement reference records.
- Final QC & Packaging: Cap all RJ45 Ethernet and RS232 console ports with factory plastic dust plugs, wipe DIN rail mounting contacts with isopropyl alcohol, seal single modules or redundant pairs inside anti-static foam-lined transit packaging, and attach a dated QC Passed sticker with assigned test technician ID.
Replacement Pitfall Guide
- Firmware Mismatch: Symphony Plus runtime V5.0 or older cannot execute full 30,000 function block logic from newer ABB firmware V2.3. Upgrade control software or source vintage matching revisions to avoid partial control logic execution and unplanned process trips.
- DIP Switch / Jumper Misconfiguration: Factory bus jumpers enable 120 Ω termination for HN800/CW800 trunk ends; mid-rack units must disable termination jumpers. Enabled termination on non-end segments causes severe signal reflection and cyclic I/O value freezes on ABB controller pairs.
- Terminal / Cable Incompatibility: CW800 peer controller twisted-pair wiring pinouts differ from standard Profibus cables used with peripheral modules like HAI805. Route all communication cable shield drains directly to cabinet master earth bars, not local DIN rail ground terminals.
- Power Supply Mismatch: Calculate total rack DC draw of redundant pairs plus all SD I/O and communication modules, add 20% power headroom to the 24 V redundant PSU. Undervoltage supply below 21.6 V corrupts NVRAM backup memory and disables bumpless redundancy switchover of ABB units.
- ESD Damage: Static discharge risk spikes heavily at plant humidity below 30%. Place an anti-static mat under the DIN rail during CPU swaps; bare PCB contact with dual-core CPU memory traces erases control logic stored in NVRAM permanently.
Keep these in mind and you’ll cut 90% of rework time.
Compatibility Matrix & Benchmarks
Compatibility Matrix
- → : Direct — Exact CPU logic, bus port layout, DIN rail footprint and redundancy handshake drop-in replacement
- → HAI805 : Incompatible — HART analog I/O module lacks Symphony Plus real-time control processing core and peer bus hardware
- → FI830F : Incompatible — Freelance AC800F Profibus communication card cannot mount into DIN rail controller racks
- → GFD233A : Needs Adaptation — UNITROL excitation controller standalone unit, cannot replace Symphony Plus master logic core; full plant control topology reconfiguration required
Benchmarks
- Minimum real-time control cycle latency: 0.08 ms (simulated full 30,000 function block load)
- Redundancy switchover time: <10 ms bumpless transfer without process disturbance
- peer controller communication throughput: 100 Mbps redundant inter-controller bus
