Product Core Brief
- Model: FAU810
- Brand: ABB
- Series: Uvisor SF810 Flame Monitoring Platform
- Core Function: Processes dual-wavelength UV/IR signals from SF810 flame scanners to detect flame presence, temperature, and loss for boiler safety interlocks.
- Product Type: DIN Rail Flame Analysis Processing Unit
- Key Specs: 24 V DC supply | 0.2–4 s adjustable flame failure response | Profibus DP + 4–20 mA outputs Condition: New Original (New Surplus)
Product Introduction
The ABB is a DIN rail-mounted signal processor built exclusively to pair with ABB SF810 series optical flame scanners for power and process boiler combustion safety. It converts raw optical sensor data into standardized analog and digital control signals.Well, technically it shares rail mounting dimensions with standard S800 I/O modules, yet the ABB integrates proprietary PYRO flame temperature calculation logic absent from generic discrete input cards. Its flame detection resolution delivers ±1.5% full-scale combustion stability tracking under full boiler load.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Full Model Code | (Uvisor SF810 flame processor) |
| Compatible Sensors | SF810 dual UV/IR optical flame scanners for gas, oil, coal, biomass fuels |
| Nominal Operating Supply | 24 V DC (18–29 V wide input tolerance) |
| Flame Failure Response Time (FFRT) | Programmable 0.2 s to 4.0 s in 0.1 s increments |
| Analog Output | Isolated 4–20 mA for flame intensity/temperature scaling |
| Digital Fieldbus | Profibus DP-V1, Modbus RTU optional expansion |
| Safety Relay Output | Form C contact for flame loss boiler trip interlock |
| Operating Ambient Temperature | -20 °C to +60 °C enclosed control cabinet |
| Storage Temperature Range | -40 °C to +85 °C non-operating transport |
| Mechanical Mounting | Standard 35 mm DIN rail footprint |
| Unit Net Weight | 1.38 kg fully assembled with terminal blocks |
| Enclosure Protection Class | IP20 indoor cabinet installation only |
| Dielectric Isolation Rating | 500 V AC between scanner inputs and fieldbus circuits |
| Max Scanner Cable Run | 30 m shielded twisted pair wiring |
| Supported Control Systems | System 800xA, Freelance AC800F, third-party PLC via Profibus |
Quality Control Process
- Incoming Verification: Cross-reference unit serial numbers against ABB Uvisor flame monitoring batch manifests to reject counterfeit processing hardware. Visual inspection checks for cracked front LCD lenses, bent terminal screw pins, or burnt relay contact traces (—minor chassis molding flash passes QA screening).
- Live Functional Test: Mount the to a calibrated DIN rail test bench, connect a calibrated flame scanner simulator, feed regulated 24 V DC rack power, and run power-on self-diagnostics. Establish Profibus DP handshake with an AC800M controller, then execute a 24-hour cyclic flame presence/loss simulation test with hourly temperature signal logging.
- Electrical Parameter Test: Use a Megger MIT300 at 500 V to validate cross-circuit insulation resistance; scanner input and fieldbus paths must register above 10 MΩ. Confirm DIN rail protective earth continuity via Fluke 115 multimeter across the chassis ground lug.
- Firmware Verification: Read embedded flame analysis firmware revision via Flame Explorer configuration software, log the version to unit trace paperwork, and photograph Profibus address DIP switches on the rear terminal header for field replacement reference.
- Final QC & Packaging: Tighten all terminal screws to factory torque values, cap unused scanner input ports with plastic dust plugs, seal the unit inside anti-static shielding bag, and attach a dated QC Passed sticker with assigned test technician ID.
Replacement Pitfall Guide
- Firmware Mismatch: Older System 800xA runtime v5.1 or older cannot decode high-resolution flame temperature data from newer ABB firmware v2.6. Upgrade DCS software or source legacy processor revisions to avoid unstable interlock behavior.
- DIP Switch / Jumper Misconfiguration: Factory DIP defaults set Profibus slave address 1 and FFRT of 2 s, but multi-scanner boiler racks require unique addresses and custom trip timing; duplicate bus addresses trigger continuous flame signal dropouts.
- Terminal / Cable Incompatibility: scanner shielded wiring pinouts differ between ABB and legacy FAU800 units. Route all scanner cable shield drains directly to cabinet master earth bars, not local DIN rail ground terminals.
- Power Supply Mismatch: Calculate total rack draw of all flame processors and I/O cards then add 20% power headroom to the 24 V PSU. Undervoltage supply below 18 V distorts UV/IR signal sampling and triggers false flame loss trip alarms.
- ESD Damage: Static discharge risk spikes heavily at plant humidity below 30%. Place an anti-static mat under the DIN rail during unit swaps; bare PCB contact with optical signal front-end traces permanently shifts flame intensity calibration offsets.
Keep these in mind and you’ll cut 90% of rework time.
Compatibility Matrix & Benchmarks
Compatibility Matrix
- → : Direct — Exact scanner input, bus logic, and DIN rail drop-in replacement
- → FAU800 : Needs Adaptation — Limited single-wavelength signal processing, full boiler interlock timing recalibration required
- → EI813F : Incompatible — Ethernet communication module lacks flame signal conditioning and safety relay hardware
- → DSTS105 : Incompatible — Intrinsically safe analog input card cannot interface with optical flame scanner sensors
Benchmarks
- Flame signal sampling cycle: 0.06 ms (simulated full-intensity scanner load)
- Profibus DP communication throughput: 12 Mbit/s (boiler control DCS network)
