Component Snapshot At-a-Glance

• Model: CS513
• Alt. P/N: 3BSE000435R1; drop-in upgraded variants CS513AK01 / CS513AK02
• Product Series: ABB Advant Master (AC410, AC450, AC460 legacy DCS platform)
• Hardware Type: IEEE 802.3 LAN communication board for MasterBus 300 rack backplane
• Key Feature: DIP switch selectable Standard/Extended MB300 bus mode, galvanic isolation between backplane and Ethernet circuit
• Primary Field Use: Connect legacy Advant controllers to plant TCP/IP Ethernet for HMI, historian and third-party SCADA data exchange
