Product Core Brief

• Model: PSCDM024DCBAN
• Brand: YOKOGAWA
• Series: ProSafe-RS Critical Discrete Module (CDM)
• Core Function: 24 V DC safety-rated discrete I/O module used for critical on/off signal acquisition and control within Yokogawa ProSafe-RS safety instrumented systems.
• Product Type: Critical Discrete Module (CDM)
• Key Specs: 24 V DC discrete application | 16-channel configuration | ProSafe-RS SCS/SNU compatible | Safety-rated I/O
• Condition: New Original / New Surplus
• Status: Limited availability; confirm revision and channel configuration before ordering

Key Technical Specifications

• Product type: Yokogawa ProSafe-RS Critical Discrete Module (CDM)
• Model code:
• Signal level: 24 V DC discrete signals
• Channel configuration: 16 channels (listed in surplus references; confirm from nameplate)
• System compatibility: Yokogawa ProSafe-RS Safety Control Station (SCS) / Safety Node Unit (SNU)
• Safety function: Supports safety-related discrete input/output for emergency shutdown, fire & gas, burner management, and other SIL-rated applications
• Diagnostics: Built-in module diagnostics typical of ProSafe-RS I/O; exact coverage depends on firmware and configuration
• Handling: ESD-sensitive safety module; verify revision, slot type, and project configuration before installation

Note: Public surplus listings identify PSCDM024DCBAN as a ProSafe-RS CDM for 24 V DC discrete applications, but the exact I/O direction (DI/DO/mixed), channel count, terminal type, and revision should be confirmed from the module nameplate or Yokogawa hardware manual.



Product Introduction

The PSCDM024DCBAN is a Yokogawa ProSafe-RS Critical Discrete Module used for 24 V DC safety-related discrete signal processing. ProSafe-RS is Yokogawa’s SIL-certified safety instrumented system, designed for emergency shutdown, fire and gas monitoring, burner management, and other high-integrity safety functions.

As a CDM, this module handles critical on/off signals between the safety controller and field devices such as limit switches, pressure switches, relay contacts, solenoid valves, and indicator circuits. Because ProSafe-RS I/O modules are safety-rated and tightly integrated with the controller configuration, the PSCDM024DCBAN is mainly used for replacement, maintenance, and spare-parts provisioning in existing SIS installations.



QA & Inspection SOP

Each module is inspected before release:

1. Nameplate verification: Confirm the model reads PSCDM024DCBAN and record revision/serial information.
2. Visual inspection: Check the housing, connectors, terminals, and mounting hardware for damage.
3. Connector check: Inspect system-side and field-side connectors for bent pins, corrosion, or loose contacts.
4. Module detection test: Install in a compatible ProSafe-RS SCS/SNU rack and verify normal module recognition.
5. Diagnostic check: Confirm the module starts without critical faults.
6. Channel check: Verify discrete input/output status if loop access and configuration are available.
7. Configuration match: Confirm slot position, channel assignment, and safety logic mapping match the original setup.
8. Packaging: Use anti-static packaging and protect connectors during shipment.

Full safety validation requires a compatible ProSafe-RS controller, correct project configuration, and authorized loop testing.



Installation Pitfalls & Guide

❗ Confirm the ProSafe-RS platform. PSCDM024DCBAN belongs to the ProSafe-RS safety system family. It is not a standard CENTUM VP or FCN discrete I/O module.

❗ Verify I/O direction and channel count. CDM variants may differ between discrete input, discrete output, or mixed configurations. Confirm the exact function from the nameplate before replacement.

❗ Match the revision code. The suffix and revision may affect firmware compatibility, terminal assignment, or diagnostic behavior.

❗ Do not bypass safety procedures. SIS module replacement should follow plant change management, loop documentation, and pre-commissioning test requirements.

Installation steps:

1. Pre-install: Record the original module model, revision, slot position, and channel configuration.
2. Isolate the loop: Follow site safety procedures before removing or replacing safety I/O.
3. Install: Seat the PSCDM024DCBAN firmly in the correct ProSafe-RS slot.
4. Configure: Verify or load the correct module configuration in the safety engineering station.
5. Verify: Check module status LEDs, diagnostic messages, and discrete channel status.
6. Test: Perform loop checks and functional tests according to the site SIS test procedure.

Technical FAQ

What is ?
It is a Yokogawa ProSafe-RS Critical Discrete Module for 24 V DC discrete signal processing in safety instrumented systems.

Which system does it belong to?
It belongs to the Yokogawa ProSafe-RS safety controller family, used in SCS/SNU racks for SIL-rated applications.

Is it a DI or DO module?
The exact I/O direction should be confirmed from the nameplate or hardware manual. Surplus references list it as a 16-channel 24 V DC discrete module, but DI/DO/mixed configuration must be verified.

Can it be replaced with a non-safety discrete module?
No. ProSafe-RS CDM modules are safety-rated and integrated with the controller diagnostics and logic. Substitution with non-safety I/O may compromise safety certification and system behavior.

What should I check before ordering?
Confirm the full model code, revision, channel count, I/O direction, slot type, ProSafe-RS controller model, and original configuration. A nameplate photo is the most reliable way to verify compatibility.
