Product Core Brief

• Model: F3XD64-3N
• Brand: YOKOGAWA
• Series: FA-M3 Range-free Controller
• Core Function: 64-point discrete input module for reading 24 V DC field signals into the FA-M3 PLC system.
• Product Type: Digital Input Module
• Key Specs: 64 input channels | 24 V DC input | High-density FA-M3 I/O card
• Condition: New Original / New Surplus



Key Technical Specifications

• Product type: Digital input module for FA-M3 PLC
• Series compatibility: FA-M3 range-free controller
• Number of inputs: 64 points
• Input voltage: 24 V DC
• Input type: DC discrete input, consistent with F3XD64-3 series specification
• Mounting: FA-M3 base module slot
• Typical applications: Sensor monitoring, machine status feedback, limit switches, pushbuttons, and relay contacts
• System integration: Scanned by FA-M3 CPU through the FA-bus backplane
• Handling: ESD-sensitive industrial control module

Note: Exact input current, response time, isolation type, and terminal layout should be confirmed against the FA-M3 Basic I/O module manual before final installation.



Product Introduction

The F3XD64-3N is a 64-point 24 V DC digital input module for the YOKOGAWA FA-M3 range-free PLC platform. It allows the CPU to read large numbers of discrete field signals such as proximity switches, limit switches, pushbuttons, and relay contacts within a single module slot.

For maintenance teams, this module is useful when replacing failed input cards or expanding I/O density without adding extra racks. Because it carries 64 points in one slot, a single faulty module can affect a large portion of the system’s input signals, making a verified spare an effective way to reduce troubleshooting time.

QA & Testing SOP

Each unit is treated as a controlled DCS/PLC spare. Before release:

1. Visual and label inspection: Confirm the model plate reads F3XD64-3N and check the housing, connectors, and PCB for damage.
2. Connector and pin check: Input terminal connectors are inspected for bent pins, oxidation, or loose contacts.
3. Backplane seating check: The module is checked for proper alignment and fit in an FA-M3 base slot.
4. Power-up test: The module is energized on a compatible FA-M3 rack to confirm normal startup and CPU recognition.
5. Input status verification: Selected channels are checked to confirm the CPU can read input states correctly.
6. ESD-safe packaging: Units are packed in anti-static materials with connector protection for shipment.

Full channel testing requires a compatible FA-M3 CPU, base unit, and 24 V DC signal source. If a site-specific loop test is required, confirm the test setup before dispatch.



Installation Pitfalls & Guide

❗ Confirm the suffix before replacement. The F3XD64 family includes multiple variants such as F3XD64-3F, F3XD64-4F, and F3XD64-6M, which differ in voltage level or terminal arrangement. Always match the original part number.

❗ Check input polarity and common wiring. Incorrect common wiring or reversed polarity can cause entire groups of inputs to read incorrectly even when the module is healthy.

❗ Verify the CPU I/O map. After replacement, confirm that the slot address and I/O assignment match the existing program. A correct hardware replacement will not help if the CPU is scanning the wrong address.

❗ Do not exceed the module’s input rating. External field voltage higher than 24 V DC can damage the input circuitry. Use proper interposing relays if field signals are outside the rated range.

Replacement steps:

1. Pre-install: Back up the CPU program, record the slot number, and note the original wiring layout.
2. Removal: De-energize the rack if required, disconnect field wiring, and remove the module from its slot.
3. Install: Seat the replacement module firmly, reconnect field wiring, and verify terminal alignment.
4. Power-on test: Restore power, confirm CPU recognition, check input status for key channels, and validate normal operation.



Technical FAQ

he a direct replacement fo64-3F?
Not automatically. Both are 64-point 24 V DC input modules in the FA-M3 F3XD64 family, but the suffix can indicate differences in terminal layout, common configuration, or regional specification. For maintenance replacements, always match the original model number.

Can this module read both NPN and PNP sensors?
FA-M3 DC input modules typically support discrete 24 V DC signals, but whether the common is positive or negative depends on the specific module variant. Confirm the wiring method against the FA-M3 hardware manual before connecting sensors.

What should I check if some inputs do not respond after replacement?
First verify field voltage at the terminal, then check the common wiring, CPU I/O assignment, and slot address. If only one group fails, the issue is often wiring or common configuration rather than the module itself.

Is this module still available?
The FA-M3 platform is a mature product line. New-original and surplus stock are commonly available through industrial spare channels, but availability varies by batch. Confirm stock condition and warranty terms before ordering.

Do you offer warranty on surplus units?
Surplus and new-original modules are typically covered by a limited functional warranty. Exact terms depend on stock source, so confirm warranty length and return conditions before purchase.
