Product Core Brief
- Model: 1X00416H01
- Brand: EMERSON (WESTINGHOUSE OVATION)
- Series: Ovation Distributed Control System (DCS)
- Core Function: Provides stable and reliable DC power to Ovation control modules and field I/O devices.
- Product Type: Power Supply Module
- Key Specs: 110V Input | High Efficiency | Overload/Overvoltage Protection
- Condition: New Original (New Surplus)
EMERSON 1X00416H01
Product Introduction
EMERSON 1X00416H01 is a high-performance power supply module designed for the Ovation DCS platform. It serves as the critical power backbone for the control rack, converting incoming AC power (typically 110V) into the precise DC voltages required by the system’s electronic modules.
Engineered for harsh industrial environments, this module features a wide voltage input range and comprehensive protection mechanisms, including overload, overvoltage, and undervoltage safeguards. Its compact, high-efficiency design ensures minimal energy loss and reliable operation for communication, network, and industrial control applications.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Module Type | Power Supply Module |
| Part Number | 1X00416H01 |
| System Compatibility | Emerson Ovation / Westinghouse DCS |
| Input Voltage | 110V AC (Wide Voltage Range) |
| Output Type | Regulated DC Power |
| Protection Features | Overload, Overvoltage, Undervoltage Protection |
| Design | Compact, High-Efficiency Conversion |
| Compliance | Ovation DCS Standard |
Quality Control Process (Engineer’s Perspective)
- Incoming Verification: We check source traceability and verify serial numbers against anti-counterfeit databases. Visual inspection confirms no physical damage or connector corrosion.
- Live Functional Test: Power-on self-checks validate basic operation. We run continuous load tests exceeding 24 hours with temperature logging to ensure stability.
- Electrical Parameter Test: Insulation resistance is verified using a 500 V Megger, requiring >10 MΩ. Ground continuity is also strictly checked.
- Firmware Verification: We read and record internal firmware versions. DIP switch and jumper settings are photographed for future reference.
- Final QC & Packaging: The unit is sealed in an anti-static bag. A QC Passed label with the inspection date is applied before shipping.
Replacement Pitfall Guide
❗ Voltage Rating Verification: This module is typically rated for 110V AC input. Always verify your field power supply matches this specification before installation to prevent catastrophic failure.
❗ Protection Mechanism Reset: If the module has tripped due to an overload or overvoltage event, you must identify and resolve the root cause on the DC bus before replacing the power supply.
❗ Base Plate Compatibility: Verify that your Ovation I/O base matches this module’s mechanical keying. Older Westinghouse bases may require specific carrier boards.
❗ Firmware Version Lock: Older Ovation controller firmware may not recognize newer 1X00416H01 revisions. Always verify firmware compatibility prior to hot-swapping modules.
❗ ESD Damage: Use an anti-static mat during installation. Dry environments significantly increase electrostatic discharge risks to sensitive electronics.
Keep these in mind and you’ll cut 90% of rework time.
EMERSON 1X00416H01
Compatibility Matrix & Benchmarks
- 1X00416H01 → 1X00024H01 : Companion — Alternate Ovation Power Supply Assembly
- 1X00416H01 → 1X00163H01 : Companion — Pluggable Power Supply Variant
- 1X00416H01 → 1C31206G01 : Companion — Requires Ovation I/O Base Plate
- Power Efficiency: High-efficiency AC to DC conversion (minimal energy loss)
- Reliability: Continuous operation with integrated fault protection
Need the matching Ovation I/O base plate or verifying your system’s controller firmware version? I can confirm the exact load ratings and configuration requirements for your power supply application.
