Product Core Brief

• Brand: ABB
• Exa: .0KN
• OEM Part Number: 3BSE019050R1000
• Series: Mini Pressductor PillowBlock
• Core Function: Horizontal-only web tension force measurement via magneto-elastic Pressductor technology
• Type: PillowBlock mounting load cell (horizontal force isolation)
• Rated Capacity: 1.0 kN / 225 lbf nominal horizontal load
• Condition: New Original (New Surplus), factory sealed anti-static packaging
• Stock Status: On-hand inventory, ships within 7–10 working days
• Primary Use Cases: Paper mills, plastic film extrusion, textile weaving, thin foil converting lines



Key Technical Specifications

• Nominal Horizontal Load: 1.0 kN (225 lbf)
• Safe Overload Capacity: 1.5x rated load (1.5 kN horizontal; 2.5 kN vertical transverse limit)
• Max Deflection at Full Load: 0.05 mm
• Spring Constant: 8 kN/mm
• Construction Material: AISI 316 stainless steel housing
• Ingress Protection: IP67 (dust-tight, temporary liquid immersion resistant)
• Operating Temperature Band: -20 °C to +70 °C
• Excitation Input (mV/V variant): 5–12 V DC
• Signal Output: Passive mV/V or active 4–20 mA integrated transmitter
• Compliance Certifications: CE, RoHS, EMC 2014/30/EU
• Mounting Standard: Drop-in footprint matching legacy vertical pillow block load cells



Product Introduction

Most standard pillow block force sensors combine roll dead weight with web tension readings, forcing operators to recalibrate when empty spools swap to full heavy rollsB .0KN eliminates this drift by isolating only horizontal web reaction force, ignoring vertical roll mass entirelyABB Group. This unit mounts directly beneath roll bearing housings without modifying existing machine frames, built for low-tension thin web processing lines.

This component delivers consistent linear signal output with zero thermal drift across 0–100% rated load. Field benchmark data shows 62% fewer mid-shift calibration stops compared to vertical strain-gauge alternatives, a measurable uptime gain for continuous converting lines running paper, BOPP film, or lightweight textile substrates.



Key Selling Points & Differentiators

1. Horizontal force isolation design removes roll weight signal contamination; only tension values feed to PLC control logic
2. New surplus units pass full 24-hour bench load testing; printed test report included with every shipment
3. 12-month supplier warranty covering factory manufacturing defects; excludes ESD or installation damage
4. Direct mechanical drop-in replacement for older vertical load cells; no frame rework required
5. Not recommended for vertical load-only weighing applications; transverse vertical overload limit caps at 2.5 kN to prevent internal Pressductor element failure
6. Magneto-elastic sensor architecture outperforms strain gauges in dusty, washdown environments with 3x higher vibration resistance



Mandatory Quality Transparency SOP

• Incoming Verification: Cross-reference serial numbers against OEM batch logs for anti-counterfeit validation; full visual scan for housing dents, cable jacket abrasion, and missing mounting fasteners
• Live Bench Test: Dedicated tension test rack applies incremental 0.2 kN load steps to full 1.0 kN rating; completes full I/O handshake with ABB PFEA111 tension controller
• Electrical Validation: 500 V megger insulation test (pass threshold >10 MΩ); ground continuity check across mounting base
• Firmware & Hardware Logging: Record factory-calibrated signal offset values; seal factory DIP jumper configuration to avoid field tampering
• Final QC & Packaging: Sign-off sheet affixed to unit; anti-static foam shock protection, sealed OEM plastic bag, QC Passed sticker visible on exterior label
• Transparency Note: Raw bench test photos or short video clips available upon buyer written request; no unit carries a zero-failure performance guarantee



Technical Risk Avoidance Section

Risk 1: Firmware Mismatch with Tension Controllers

• Risk: Pairing this unit with unupdated PFEA110 controller firmware generates offset tension readings up to ±8%
• Prevention: Confirm controller firmware rev V2.4 or newer before wiring; download ABB official firmware patch via OEM portal
• Field Anecdote: A textile integrator skipped this step, leading to uneven fabric stretch across 3 production shifts before root cause identification

Risk 2: Misaligned Mounting Creates Cross-Load Noise

• Risk: Uneven torque on mounting bolts introduces vertical force bleed into horizontal signal, causing oscillating tension control
• Prevention: Torque mounting fasteners to OEM specified 12 N·m in crisscross sequence; use precision level tool to verify flat base contact
• Field Anecdote: A film extrusion line recorded 14% scrap rate from misaligned installation until mount torque procedure was standardized

Risk 3: ESD Damage During Wiring

• Risk: Un-grounded technicians touching internal cable terminals degrade Pressductor magnetic elements, permanent signal attenuation
• Prevention: Wear certified ESD wrist strap bonded to machine earth ground before disconnecting factory cable glands
• Field Anecdote: Three replacement units failed within 30 days on an ungrounded paper slitter due to static discharge during maintenance

Risk 4: Exceeding Vertical Transverse Overload Limit

• Risk: Vertical shock loads above 2.5 kN crack internal sensor laminations, irreversible calibration loss
• Prevention: Install mechanical hard stops to limit vertical roll deflection during spool changeovers
• Critical Bold Warning: Never use this unit to support roll weight as primary vertical bearing support

Practical Summary

Map controller firmware versions first, follow torque-aligned mounting procedure, enforce ESD protocols, and install vertical travel stops to eliminate 95% of field failure events reported for this series. Always cross-check the official ABB datasheet 3BSE019050 before final installation.



FAQ

1. Q: I run a small paper slitter line with low web tension—will this transducer deliver stable readings with light substrate loads?A: Yes. Horizontal isolation lets the sensor operate in its optimal upper measurement band even with minimal web pull; strain-gauge alternatives suffer low-signal noise at matching tension levels. Verify your maximum line tension stays below 1.0 kN nominal rating.
2. Q: What controller models natively interface witB .0KN?A: Primary compatible hardware includes ABB PFEA111 and PFEA112 tension control modules; passive mV/V output also connects directly to standard PLC analog input cards with scaling logic configured in program code.
3. Q: Does the new surplus condition affect calibration accuracy out of the box?A: No. Every unit undergoes full load bench testing post-stock intake, matching OEM factory calibration tolerances. A signed test report ships with each order to validate performance before installation.
4. Q: Can I use this load cell in a high-humidity washdown food packaging film line?A: IP67 ingress rating resists splashing and dust accumulation; avoid continuous full submersion. Add a sealed cable junction box if daily caustic wash cycles are standard for your line.
5. Q: How long is the lead time if I place an order today?A: Standard lead time for in-stock units is 7–10 working days to North America, UK, Australia, and Southeast Asia ports; expedited air freight options available for emergency machine downtime orders upon request.
6. Q: What separates this Pressductor design from generic strain-gauge horizontal load cells on the market?A: Magneto-elastic technology eliminates foil fatigue drift common to strain gauges under constant vibration; horizontal force isolation is exclusive to the ABB series, removing roll weight interference without additional mechanical compensation hardware.
