Description
YOKOGAWA ANB10D-425/CU2T Product Overview
The YOKOGAWA ANB10D-425/CU2T is a high-performance analog signal conditioning module specifically designed for temperature measurement applications in industrial automation systems. As part of Yokogawa’s comprehensive signal conditioning product line, this unit provides precise signal conversion and isolation for thermocouple (TC) and resistance temperature detector (RTD) inputs in demanding process environments.
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | ANB10D-425/CU2T |
| Manufacturer | YOKOGAWA |
| Product Type | Temperature Signal Conditioner |
| Input Types | TC (J,K,T,E,R,S,B,N), RTD (Pt100, JPt100) |
| Output Signal | 4-20mA (isolated) |
| Isolation | 1500V AC (input-output-power) |
| Accuracy | ±0.1% of span (RTD), ±1°C (TC) |
| Cold Junction Compensation | ±0.5°C |
| Operating Temperature | -20°C to +60°C |
| Power Supply | 24V DC ±10% |
| Response Time | <500ms (TC), <1s (RTD) |
| Hazardous Area Certification | ATEX, IECEx (Zone 2) |
| Dimensions | 22.5mm (W) × 100mm (H) × 115mm (D) |
| Mounting | DIN rail (TS35) |
YOKOGAWA ANB10D-425/CU2T
Main Features and Advantages
The ANB10D-425/CU2T offers:
Universal temperature input supporting all major TC and RTD types
High accuracy conversion with advanced cold junction compensation
Complete 3-way isolation for noise-free signal transmission
Flexible configuration via DIP switches for various sensor types
Diagnostic LEDs for power and signal status monitoring
Compact design saving panel space in control cabinets
Robust construction for reliable operation in harsh environments
YOKOGAWA ANB10D-425/CU2T
Application Field
This temperature signal conditioner is widely used in:
Process industries (oil refineries, petrochemical plants)
Power generation (boiler temperature monitoring)
Pharmaceutical manufacturing (sterilization processes)
Food processing (pasteurization control)
HVAC systems (building automation)
Related Products
ANB10D-425/CU2N: Current signal conditioning version
ANB20D-425/CU2T: Dual-channel temperature conditioner
YTA320: Temperature transmitter with direct field mounting
YTMX580: Multi-input temperature monitor
DPharp EJX: Differential pressure transmitters
Installation and Maintenance
Installation: Mount on standard DIN rail, ensure proper sensor connections matching DIP switch settings, and verify grounding.
Maintenance: Periodically check connection tightness and verify calibration. Clean unit surface annually to ensure proper heat dissipation.
Product Guarantee
Yokogawa provides a 24-month warranty with global technical support. The ANB10D-425/CU2T is designed for continuous operation with MTBF exceeding 100,000 hours, meeting rigorous industrial standards for reliability and performance.
