Description
YOKOGAWA YHC5150X Product Overview
The YOKOGAWA YHC5150X is a high-performance handheld communicator specifically designed for field configuration, calibration, and diagnostics of Yokogawa and other HART/Fieldbus compatible field instruments. This rugged, portable device serves as a powerful tool for maintenance engineers and technicians working with industrial automation systems.
Key Features
✔ Full HART 7 and FOUNDATION Fieldbus support
✔ Large color touchscreen display (5.7″ LCD)
✔ Bluetooth® wireless connectivity
✔ Intrinsically safe design (ATEX/IECEx certified)
✔ Long battery life (up to 16 hours continuous use)
Technical Specifications
| Parameter | Specification |
| Model | YHC5150X |
| Manufacturer | YOKOGAWA |
| Type | Handheld Field Communicator |
| Display | 5.7″ color LCD (640×480) touchscreen |
| Communication Protocols | HART 7, FOUNDATION Fieldbus, Bluetooth 4.2 |
| Hazardous Area Certification | ATEX/IECEx (Zone 1/21) |
| Battery | Li-ion (7.4V, 5200mAh) |
| Operating Temperature | -20°C to +50°C |
| Storage Temperature | -30°C to +60°C |
| Ingress Protection | IP54 |
| Dimensions | 190mm × 100mm × 50mm |
| Weight | 600g (including battery) |
YOKOGAWA YHC5150X
Main Features & Benefits
1. Advanced Communication Capabilities
Simultaneous HART and Fieldbus support
Wireless Bluetooth® connection to host systems
USB and IR interfaces for data transfer
2. Powerful Configuration Tools
Pre-loaded device description files for major brands
Graphical parameter trending
Custom script creation for complex tasks
3. Rugged Field Design
Drop-tested to 1.5m onto concrete
Sunlight-readable display
Glove-compatible touchscreen
YOKOGAWA YHC5150X
Application Field
Maintenance & Calibration
✔ Field instrument configuration
✔ Loop testing and diagnostics
✔ Troubleshooting instrument issues
Commissioning
✔ Device parameter setup
✔ Loop verification
✔ Documentation generation
Asset Management
✔ Field data collection
✔ Condition monitoring
✔ Predictive maintenance
Related Products
| Model | Description |
| YHC4150X | Previous generation model |
| YHC5150X-IS | Enhanced intrinsically safe version |
| FieldMate | PC-based device management software |
| PRM | Plant Resource Manager |
Installation & Maintenance
Initial Setup
Charge battery fully before first use
Install latest device description files
Configure wireless settings
Maintenance Recommendations
Regularly update firmware
Clean screen with approved materials
Store in protective case when not in use
