Product Overview
The YOKOGAWA AFV30D-S41252 is a high-performance fieldbus power supply and signal conditioner designed specifically for Foundation Fieldbus H1 networks in industrial automation systems. As part of Yokogawa’s comprehensive field communication solutions, this advanced device provides reliable power conditioning, signal isolation, and network protection for fieldbus segments in critical process control applications. The AFV30D-S41252 represents an evolution in fieldbus technology, offering enhanced capabilities for modern industrial networks in oil & gas, petrochemical, power generation, and other process industries.
Engineered for maximum reliability, this fieldbus power conditioner features state-of-the-art protection mechanisms and superior signal integrity preservation. Its robust construction meets the demands of harsh industrial environments while maintaining compliance with Foundation Fieldbus specifications. The AFV30D-S41252 delivers exceptional performance in terms of power capacity, noise immunity, and diagnostic capabilities, making it an ideal choice for both greenfield installations and system upgrades in existing facilities.
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | AFV30D-S41252 |
| Manufacturer | YOKOGAWA |
| Product Type | Fieldbus Power Conditioner |
| Fieldbus Standard | Foundation Fieldbus H1 (IEC 61158-2) |
| Input Voltage | 18-32V DC |
| Output Voltage | 15-17.5V DC (fieldbus segment) |
| Maximum Current | 450mA (per segment) |
| Isolation | 1500V AC (field to system) |
| Short-circuit Protection | Automatic recovery |
| Termination | Built-in 100Ω (configurable) |
| Operating Temperature | -40°C to +85°C |
| Humidity Range | 5-95% RH (non-condensing) |
| Housing Material | Aluminum alloy |
| Dimensions | 60mm (W) × 120mm (H) × 130mm (D) |
| Mounting | DIN rail (TS35/7.5) or panel mount |
| Certifications | ATEX, IECEx, FM (for hazardous areas) |
