Yaskawa JRMSI-120XBP01200

1. High Torque & Dynamic Performance

3.82 Nm rated torque with 11.46 Nm peak torque for demanding applications

Low vibration & smooth operation even at low speeds (<0.5% torque ripple)

Optimized rotor inertia for rapid acceleration/deceleration

2. Ultra-Precise Positioning

24-bit absolute encoder (±1 arc-minute accuracy)

Adaptive vibration suppression for stable motion control

Compatible with dual-loop feedback (rotary + linear encoder)

3. Robust Industrial Design

IP65 protection (dustproof & water-resistant)

High-grade bearings (50,000+ hours lifespan)

Corrosion-resistant coating for harsh environments

4. Smart Connectivity & Integration

MECHATROLINK-III/IV & EtherCAT support

Compatible with Yaskawa SGD7S servo drives

Predictive maintenance via condition monitoring



In Stock
Manufacturer:
Part number: Yaskawa JRMSI-120XBP01200
Our extensive catalogue, including : Yaskawa JRMSI-120XBP01200 , is available now for dispatch to the worldwide. Brand:

Description

Yaskawa JRMSI-120XBP01200 Product Description

Product Overview

The Yaskawa JRMSI-120XBP01200 is a high-performance, medium-inertia servo motor designed for industrial automation applications requiring high torque and smooth motion control. Part of Yaskawa’s Σ-7 (Sigma-7) series, this motor delivers exceptional dynamic response and precision, making it ideal for CNC machinery, robotics, and high-speed production lines.

With a rated power of 1.2kW (1200W) and optimized electromagnetic design, the JRMSI-120XBP01200 provides high torque density while minimizing energy loss. Its IP65-rated enclosure ensures durability in harsh environments, resisting dust, oil, and water ingress. The motor features a high-resolution 24-bit absolute encoder, enabling ultra-precise positioning (±1 arc-minute) and smooth operation at low speeds.

Designed for seamless integration with Yaskawa’s Σ-7 servo drives (e.g., SGD7S series), this motor supports MECHATROLINK-III/IV and EtherCAT communication, ensuring fast, synchronized motion in multi-axis systems.

Technical Specifications

Parameter Specification
Model JRMSI-120XBP01200
Manufacturer Yaskawa
Type AC Servo Motor (Medium Inertia)
Rated Power 1.2 kW (1200W)
Rated Torque 3.82 Nm
Max Torque 11.46 Nm (300% overload)
Rated Speed 3000 rpm
Max Speed 5000 rpm
Encoder 24-bit absolute (Hiperface DSL)
Protection Rating IP65 (dust & water-resistant)
Frame Size 120 mm
Shaft Type Keyway shaft (standard)
Weight 9.5 kg
Insulation Class Class F (155°C)
Yaskawa JRMSI-120XBP01200

Yaskawa JRMSI-120XBP01200

Key Features & Advantages

1. High Torque & Dynamic Performance

3.82 Nm rated torque with 11.46 Nm peak torque for demanding applications

Low vibration & smooth operation even at low speeds (<0.5% torque ripple)

Optimized rotor inertia for rapid acceleration/deceleration

2. Ultra-Precise Positioning

24-bit absolute encoder (±1 arc-minute accuracy)

Adaptive vibration suppression for stable motion control

Compatible with dual-loop feedback (rotary + linear encoder)

3. Robust Industrial Design

IP65 protection (dustproof & water-resistant)

High-grade bearings (50,000+ hours lifespan)

Corrosion-resistant coating for harsh environments

4. Smart Connectivity & Integration

MECHATROLINK-III/IV & EtherCAT support

Compatible with Yaskawa SGD7S servo drives

Predictive maintenance via condition monitoring

Yaskawa JRMSI-120XBP01200

Yaskawa JRMSI-120XBP01200

Typical Applications

CNC Machinery (spindle drives, multi-axis milling)

Industrial Robots (articulated arms, heavy payload handling)

Packaging Machines (high-speed filling, labeling)

Semiconductor Manufacturing (wafer handling, precision stages)

Automotive Automation (welding, assembly lines)



Related Products

SGD7S-1R6A20A (1.6kW Σ-7 servo drive)

JRMSI-080XBP00800 (800W medium-inertia motor)

JRMSI-150XBP01500 (1.5kW motor, higher torque)

MP3300iec Motion Controller (for multi-axis coordination)

MotionWorks IEC (programming & tuning software)



Installation & Maintenance

Installation Guidelines

Ensure proper shaft alignment (≤0.02mm radial/axial misalignment)

Use flexible couplings to minimize mechanical stress

Maintain minimum 20mm clearance around motor for ventilation

Maintenance Recommendations

Annual inspection of bearings & seals

Monitor temperature (max 90°C winding temp)

Regular encoder cleaning (non-contact method)



Warranty & Support

Yaskawa provides a 24-month warranty with lifetime technical support. The JRMSI-120XBP01200 is designed for 10+ years of operation under normal conditions. Support includes:

Free firmware updates

Global service network (on-site repairs available)

Predictive maintenance tools via SigmaWin+ software

Why Choose the Yaskawa JRMSI-120XBP01200?

✔ High torque & precision for demanding automation
✔ IP65-rated durability in harsh environments
✔ Seamless integration with Σ-7 servo systems
✔ Industry-leading reliability (50,000+ hour bearing life)
