Yaskawa JAPMC-CP2230-E Product Description
Product Overview
The Yaskawa JAPMC-CP2230-E is a high-performance programmable motion controller designed for advanced automation systems requiring precise multi-axis coordination. As part of Yaskawa’s MP3000 series, this controller delivers exceptional real-time control capabilities for complex motion applications in robotics, semiconductor manufacturing, and precision assembly lines.
Featuring a 64-bit RISC processor with 1ms control cycle time, the JAPMC-CP2230-E supports up to 32 axes of synchronized motion control through MECHATROLINK-IV communication. Its modular architecture allows flexible expansion with various I/O modules, while the EtherCAT master functionality enables seamless integration with third-party devices.
The controller’s predictive vibration suppression and adaptive tuning algorithms ensure optimal performance even with varying mechanical loads. With dual Ethernet ports for daisy-chaining and built-in safety functions (STO, SS1), the Yaskawa JAPMC-CP2230-E meets the demanding requirements of modern smart factories and Industry 4.0 applications.
Technical Specifications
| Parameter | Specification |
| Model | JAPMC-CP2230-E |
| Manufacturer | Yaskawa |
| Type | Programmable Motion Controller |
| Processor | 64-bit RISC (800MHz) |
| Control Axes | Max 32 axes |
| Control Cycle | 1ms (minimum) |
| Memory | 512MB Flash, 256MB RAM |
| Communication | MECHATROLINK-IV, EtherCAT, Ethernet/IP |
| I/O Capacity | 2048 points (expandable) |
| Safety Functions | STO, SS1, Safe Limit, Safe Position |
| Operating Temperature | 0°C to 55°C |
| Dimensions | 60 × 120 × 110mm |
| Weight | 0.9kg |
Yaskawa JAPMC-CP2230-E
Key Features
High-Speed Precision Control
1ms control cycle for nanosecond-level synchronization
Advanced trajectory planning (spline, NURBS interpolation)
32-axis coordination with MECHATROLINK-IV
Advanced Motion Algorithms
Predictive vibration suppression
Adaptive filter tuning
Dual-loop feedback capability
Network Connectivity
Dual Ethernet ports (1Gbps)
EtherCAT master functionality
OPC UA server capability
Safety & Reliability
Integrated safety functions (PLd/SIL2)
Redundant power supply option
Built-in diagnostics and condition monitoring
Yaskawa JAPMC-CP2230-E
Applications
Industrial Robotics: Complex articulated arm control
Semiconductor: Wafer handling and inspection systems
Automotive: High-speed assembly and testing
Packaging: Synchronized multi-axis machines
Machine Tools: 5-axis CNC control
Related Products
MP3300iec: Modular motion controller platform
SGD7S servo drives: For Sigma-7 motor control
MECHATROLINK-IV compatible devices
MotionWorks IEC programming software
YRC1000 robot controller (for integrated systems)
Installation & Maintenance
Installation:
Mount in well-ventilated control panel
Maintain minimum 50mm clearance around unit
Use shielded cables for all signal connections
Maintenance:
Regular firmware updates via MotionWorks
Annual inspection of cooling system
Backup parameters before maintenance
Warranty & Support
Yaskawa provides a 36-month warranty with lifetime technical support. The controller is designed for 10+ years of operation in industrial environments. Global support network includes:
24/7 technical assistance
On-site commissioning services
Predictive maintenance programs
