Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
| Product model | REXROTH PPC-R22.1N-T-Q2-G2-NN-FW |
| Manufacturer | Bosch Rexroth |
| Product category | Logic and Motion Controller |
| Operating Voltage | 24 VDC |
| Communication Interface | ARCNET, SERCOS, Profibus, Ethernet |
| Operating Temperature Range | 0°C to 55°C |
| Storage Temperature Range | -25°C to 70°C |
| Dimensions (W x H x D) | 120 mm x 120 mm x 60 mm |
| Weight | 1.3 kg |
| Certifications | CE, RoHS |
| I/O Interfaces | 4-digit alphanumeric display, fiber-optic emitter, fiber-optic receiver |
| Mounting | DIN rail or panel |
| Protection Rating | IP20 |
| Diagnostics | H2 distortion display, switchover key, earthing bolt, X15 BT bus |
Product Introduction
The REXROTH PPC-R22.1N-T-Q2-G2-NN-FW is a high-performance logic and motion controller designed for complex automation systems. It is part of the PPC Series by Bosch Rexroth Indramat, known for its robustness and versatility. This controller is designed to work seamlessly with various drives and motors, providing precise control and monitoring capabilities.
Core Advantages and Technical Highlights
High Precision and Reliability:
The REXROTH PPC-R22.1N-T-Q2-G2-NN-FW achieves ±0.5% torque accuracy and ±0.01 mm position repeatability, ensuring consistent performance in high-precision applications.
Robust Industrial Design:
The controller features an IP20 protection rating, safeguarding it from dust and dirt, making it suitable for harsh industrial environments.
Versatile Applications:
The REXROTH PPC-R22.1N-T-Q2-G2-NN-FW is suitable for a wide range of applications, including manufacturing, energy, material handling, and robotics.
Easy Integration:
The controller features industry-standard communication protocols such as SERCOS, Profibus, and Ethernet, ensuring seamless integration with existing systems.
Advanced Safety Features:
The controller includes a holding brake with a holding torque of 1 Nm, ensuring enhanced safety and ease of troubleshooting.
REXROTH PPC-R22.1N-T-Q2-G2-NN-FW
Typical Application Scenarios
The REXROTH PPC-R22.1N-T-Q2-G2-NN-FW is widely used in various industrial sectors:
Manufacturing: For precise control in assembly lines and machine tools.
Energy: For pump control in water treatment plants.
Material Handling: For conveyor speed control in automotive assembly lines.
Food and Beverage Production: For controlling motion equipment on production lines.
Related Model Recommendations
REXROTH PPC-R22.1N-T-Q2-G2-NN-NN-FW: A similar model with additional Profibus interface, suitable for applications requiring more advanced communication capabilities.
REXROTH PPC-R22.1N-T-Q2-V2-NN-FW: A model with a DeviceNet fieldbus slave interface, suitable for applications requiring more advanced communication capabilities.
Installation, Commissioning, and Maintenance Instructions
Installation Preparation:
Ensure the installation environment meets the specified temperature and humidity requirements. The controller should be installed in a location with adequate ventilation to dissipate heat. Verify that the power supply voltage is within the specified range (24 VDC) to avoid damage to the controller.
Maintenance Suggestions:
Regularly inspect the installation to ensure the controller is securely mounted and all connections are tight. Monitor the operational status of the controller to detect any signs of malfunction early. Conduct functional testing on the controller at least once a year to ensure optimal performance.
Service and Guarantee Commitment
Bosch Rexroth provides comprehensive support for the REXROTH PPC-R22.1N-T-Q2-G2-NN-FW, including a robust warranty that ensures product quality and reliability. The company offers extensive after-sales services such as technical support, repair services, and spare part supply. Bosch Rexroth’s global network of service centers ensures prompt assistance and expert guidance, demonstrating the company’s commitment to customer satisfaction and product excellence.
