1. Product Introduction

The PROSOFT MVI56E – MNET is a high – performance Ethernet communication module developed by ProSoft Technology. Engineered to meet the demands of modern industrial automation, this module serves as a crucial bridge between Rockwell Automation’s ControlLogix Programmable Automation Controllers (PACs) and Modbus TCP/IP – based networks.

In the complex ecosystem of industrial control systems, seamless communication between different devices and protocols is essential. The MVI56E – MNET addresses this need by enabling ControlLogix PACs to interface with a wide array of Modbus TCP/IP – compatible instruments and devices. This includes Modicon Programmable Automation Controllers (PACs), as well as various sensors, actuators, and other industrial equipment that adhere to the Modbus TCP/IP standard. By facilitating such connections, the module unlocks enhanced control and monitoring capabilities, allowing for more efficient operation of industrial processes.

2. Functional Features

2.1 Modbus TCP/IP Client/Server Functionality

At its core, the MVI56E – MNET offers comprehensive Modbus TCP/IP client and server functionality. As a client, it can initiate communication with multiple Modbus TCP/IP servers, enabling the ControlLogix system to read data from and write data to various devices across the network. For example, in a manufacturing plant, the module can be configured as a client to access data from Modbus – compliant temperature sensors, pressure gauges, and motor drives. This data can then be used by the ControlLogix PAC for process control, such as adjusting production rates based on real – time sensor readings.

Conversely, when operating as a server, the MVI56E – MNET allows other Modbus TCP/IP clients to access data from the ControlLogix system. In a power distribution substation, the module can act as a server, providing information about the status of circuit breakers, transformers, and other electrical equipment to a SCADA system. This two – way communication capability makes the module highly versatile and adaptable to different industrial scenarios.

2.2 User – Definable Data Memory Mapping

The module supports user – definable module data memory mapping of up to 5000, 16 – bit registers. This flexibility allows engineers to tailor the data exchange between the ControlLogix PAC and Modbus devices according to the specific requirements of their applications. In a food and beverage production facility, for instance, operators can map the data registers to monitor and control variables such as ingredient flow rates, tank levels, and conveyor speeds. This custom – mapping ensures that only the relevant data is transferred, optimizing network traffic and improving the overall efficiency of the control system.

2.3 CIP Connect – Enabled Network Configuration and Diagnostics

Leveraging CIP Connect technology, the MVI56E – MNET enables seamless network configuration and diagnostics monitoring. When used in conjunction with Rockwell Automation’s ControlLogix 1756 – ENXT and 1756 – CNB modules, the module can bridge ControlNet and Ethernet/IP networks. In a large – scale industrial complex with multiple network segments, this functionality allows for unified management and monitoring of devices across different network types. Technicians can use the CIP Connect feature to easily configure the module, troubleshoot network issues, and ensure reliable communication between the ControlLogix system and Modbus – based devices.

2.4 ProSoft Configuration Builder (PCB) Software Support

The MVI56E – MNET is fully compatible with ProSoft Configuration Builder (PCB) software, a Windows – based graphical user interface (GUI). The PCB software simplifies the product and network configuration process, even for users with limited technical expertise. A plant maintenance team can use the PCB software to quickly set up the module, define network parameters, and configure data mappings. The intuitive GUI provides a step – by – step wizard for configuration, reducing the time and effort required for installation and commissioning. Additionally, the software allows for easy import and export of configuration files, making it convenient for backup and replication of settings across multiple modules.

2.5 Internal Web Server for Access to Documentation and Diagnostics

The module features an internal web server that provides users with access to product documentation, module status, diagnostics, and firmware updates. By simply connecting a web browser to the module’s IP address, users can view detailed manuals, troubleshooting guides, and the current status of the module. In a remote mining operation, maintenance staff can use the web server to remotely check the status of the MVI56E – MNET module, view diagnostic information in case of issues, and update the firmware without the need for on – site visits. This remote access capability significantly improves the maintainability and supportability of the module.

2.6 ProSoft Discovery Service (PDS) for IP Address Assignment

Configuring the initial IP address of network devices can be a challenging task, especially in large – scale deployments. The MVI56E – MNET addresses this issue through the ProSoft Discovery Service (PDS) software. With PDS, users can easily locate the module on the network and assign a temporary IP address without the need to change their PC’s IP settings to match the module’s default subnet. In a new industrial plant installation, where multiple MVI56E – MNET modules are being deployed, technicians can use PDS to quickly assign unique IP addresses to each module, streamlining the deployment process and reducing the risk of IP conflicts.

PROSOFT MVI56E-MNET

3. Technical Specifications

PROSOFT MVI56E-MNET

4. Application Scenarios

4.1 Industrial Automation in Manufacturing

In manufacturing plants, the MVI56E – MNET plays a vital role in integrating different devices into a unified control system. It can connect ControlLogix PACs with Modbus – compliant robots, PLCs from other manufacturers, and various sensors and actuators on the production line. In an automotive assembly plant, the module enables the ControlLogix system to communicate with Modbus – based torque wrenches, ensuring that bolts are tightened to the correct specifications. It also allows for the integration of conveyor systems and robotic arms, optimizing the flow of materials and parts on the assembly line. By facilitating seamless communication between different devices, the MVI56E – MNET helps improve production efficiency, reduce downtime, and enhance product quality.

4.2 Power Generation and Distribution

In the power industry, the module is used to interface ControlLogix systems with Modbus – compatible power monitoring devices, such as energy meters, power quality analyzers, and circuit breakers. In a power generation plant, the MVI56E – MNET can collect data from multiple power sensors and meters, providing real – time information about power generation, consumption, and quality. This data can be used by the ControlLogix system to optimize power generation, manage load distribution, and ensure grid stability. In a power distribution substation, the module enables the ControlLogix PAC to monitor and control the status of circuit breakers, transformers, and other electrical equipment, enhancing the reliability of power supply to end – users.

4.3 Water and Wastewater Treatment

Water and wastewater treatment plants rely on a variety of sensors and control devices to ensure the proper treatment and distribution of water. The MVI56E – MNET can connect ControlLogix systems with Modbus – based flow meters, pH sensors, level sensors, and pumps. In a water treatment plant, the module allows the ControlLogix PAC to collect data from these sensors, monitor the water treatment process in real – time, and control the operation of pumps and valves. This helps optimize the treatment process, reduce energy consumption, and ensure that the treated water meets the required quality standards. In a wastewater treatment plant, the module enables the ControlLogix system to manage the collection, treatment, and disposal of wastewater, improving the efficiency and effectiveness of the treatment process.

5. Installation, Commissioning, and Maintenance

5.1 Installation

Mounting: Install the MVI56E – MNET into a single – slot 1756 ControlLogix backplane. Ensure that the backplane is properly grounded and has sufficient power capacity to support the module. Leave a minimum clearance of 10 mm around the module to facilitate proper ventilation, which is crucial for maintaining optimal operating temperatures, especially in high – density installations.

Wiring: Connect an Ethernet cable (Cat5 or higher) to the module’s RJ45 Ethernet port. For power, connect the appropriate power supply wires to the terminal block on the module, making sure that the voltage levels match the module’s requirements (5 VDC and 24 VDC). To minimize electromagnetic interference, which can disrupt communication signals in industrial environments, use shielded cables.

Initial Setup: Use the ProSoft Discovery Service (PDS) software to set the module’s initial IP address. Connect a PC to the same local network as the module and run the PDS software. Follow the on – screen instructions carefully to assign a unique IP address to the module that is compatible with the overall network infrastructure. This step is essential for establishing communication between the module and other devices on the network.

5.2 Commissioning

Software Installation: Install the ProSoft Configuration Builder (PCB) software on a PC if it is not already installed. This software is the primary tool for configuring the module’s settings, including network parameters, data mappings, and communication protocols.

Configuration: Open the PCB software and create a new project for the MVI56E – MNET module. Define the module’s parameters, such as its role as a Modbus client or server, the number of data registers to be mapped, and the network addresses of the devices it will communicate with. Use the intuitive GUI to set up the module’s I/O mappings, ensuring that data is transferred correctly between the ControlLogix system and the Modbus devices.

Testing: Use a network analyzer or a Modbus – compliant testing tool to verify the module’s communication with other devices on the network. Send test commands to the module and check if the responses are correct. Monitor the module’s LED indicators during the testing process. The “OK” LED should be steadily lit to indicate normal operation, the “APP” LED should blink periodically to show application activity, and the “ERR” LED should remain off. If any issues are detected, use the PCB software’s diagnostic tools to troubleshoot the problem.

5.3 Maintenance

Regular Checks: Periodically inspect the module’s LED indicators to ensure normal operation. Clean the module’s exterior with a dry, lint – free cloth to remove dust and debris, especially in dusty industrial environments. Dust accumulation can affect the module’s performance and lead to overheating.

Troubleshooting: If communication issues arise, first check the Ethernet cable for any signs of damage or loose connections. Use the module’s 4 – character LED display to view error codes and refer to the user manual for troubleshooting guidance. If the problem persists, use the PCB software’s advanced diagnostic tools to analyze the module’s internal status and communication logs. These tools can help identify issues such as network latency, incorrect data mappings, or hardware failures.

Firmware Updates: Regularly check ProSoft Technology’s website for firmware updates for the MVI56E – MNET. Download the latest firmware and use the PCB software to update the module. Firmware updates often include bug fixes, performance improvements, and new features. Before performing a firmware update, ensure that the module is in a non – critical operation state to avoid any disruptions to the control system.

6. Service and Warranty

ProSoft Technology offers a standard 1 – year warranty for the MVI56E – MNET, covering defects in materials and workmanship. For customers with mission – critical applications, such as those in power generation, large – scale manufacturing, or water treatment, ProSoft provides an optional Extended Support Package. This package extends the warranty to 3 years and includes:

24/7 technical support with a guaranteed response time of 30 minutes for critical issues. This ensures that customers can quickly get the help they need in case of emergencies, minimizing downtime and potential losses.

Annual on – site maintenance visits by ProSoft – certified technicians to perform hardware and software checks. These visits help proactively identify and address any potential issues, ensuring the long – term reliability of the module.

Priority access to replacement modules in case of failure, with a maximum delivery time of 24 hours. This rapid replacement service helps customers quickly restore normal operations in the event of a module failure.

Customers also have access to a range of free resources:

Online user manuals and technical documentation that provide in – depth information on installation, configuration, and troubleshooting. These resources are available 24/7 and can be easily accessed by customers from anywhere in the world.

A knowledge base with frequently asked questions and solutions contributed by ProSoft’s technical team and other users. This community – driven resource allows customers to learn from the experiences of others and find solutions to common problems.

A user community forum where customers can share experiences, ask questions, and get advice on using the MVI56E – MNET in different applications. The forum fosters a sense of community among users and promotes knowledge sharing.

For out – of – warranty repairs, ProSoft offers a fixed – rate repair service starting at $200 per module. The repair process includes a comprehensive diagnostic check, replacement of faulty components, and full functionality testing. Repaired modules come with a 3 – month warranty for added peace of mind, ensuring that customers can rely on the repaired module for a reasonable period after the repair.
